Summary of Contents for AWIN Technology Corp. AW-ET350

Page 1 World’s Best Ni-MH Electric Tricycle ASSEMBLY MANUAL AW-ET350...
Page 2: Table Of Contents
Table of Contents I. Table of Contents ……………………………………… Parts Description … … … … … … … … … … … … … …2 III. Installation ……………………………………………3 IV. Attentions… … … … … … … … … … … … … … … … …8 V.
Page 3: Parts Description
Parts Description 1. GRIP 2. BRAKE LEVER 3. HANDLE BAR 4. CONTROL CABLE 5. HANDLE STEM 6. REFLECTOR 7. FRONT BRAKE 8. FENDER 9. TIRE 10. FRONT FORK 11. RIM 12. SPOKE 13. MOTOR 14. FENDER BRACE 15. CHAIN WHEEL 16.
Page 4: Installation
Installation Carton A Rear Wheel Fender Saddle & Charger Group A Seat post Carton B Other Components Foldable Group B Battery Pack Basket AWIN TECHNOLOGY CORP.
Page 5 Installation 1. Rear wheels assembly (a) Both wheels are the same. The hub has three holes that fit the pins on the axle. Install the drive wheel first (right side), and let the bolt of axle snug down locking nut. (b) Put the idler wheel on the left side.
Page 6: Basket Assembly
Installation 3. Rear frame end chassis To mount rear frame end onto front frame: (a) Remove bolts from slide-in bracket of rear end of chassis. (b) Slide rear end of chassis onto frame making sure the fixed bracket is on right side of bike frame. (c) Re-insert 4 bolts through bike frame onto rear end of chassis and secure finger tight.
Page 7 Installation 5. Rear band brake Insert the spring into brake wire and the fixed screw hole of band brake, then tighten up the screws. 6. Seat post and seat (a) Insert seat post into frame. Penetrate at least to minimum insertion line.
Page 8 Installation 9. Battery pack (a) sockets The method of p lugging in sockets are descirbed in p.11 “ the usage of Twin Battery “. AWIN TECHNOLOGY CORP.
Page 9: Attentions
Attentions AWIN Only the exclusively designed use "Awin" ONLY battery pack and "Awin" Charger . The user shall not modify or dismantle any parts of the battery pack to avoid danger. Read the operation manual carefully before using the electrical bike and the charger. Keep the charger out of reach of children .
Page 10: Charge Mode
Charge Mode A. On-bike charging A. On-bike charging Before charging , make sure that power supply of both the electric bike and the charger are off.And Then follow charging procedure. Battery pack B. Off-bike charging B. Off-bike charging Before charging, unlock the padlock Carrier Battery pack of the carrier and peel off the connection...
Page 11: Charge Procedure
Charge Procedure Connect tightly the charging plug of the charger to the charging socket on the bike. Use 110V or 220V AC Power for the charger. Make sure that the plug is correctly inserted into the socket then turning on the power switch of charger. Charging time: Charging will be completed in 2~3 hours.
Page 12: Usage Of Twin Battery
Usage of Twin Battery Electric Tricycle of AWIN is equipped with TWIN Battery Pack(24V). You should choose to use only single or twin battery. Twin battery 1. Put the two battery packs into carrier, keep the pack holder upside, and check the position of battery packs are correct or not. Battery A 2.
Page 13: Check Before Riding
Check Before Riding Note Check and adjust the following points before riding the electric scooter. Stop riding the electric bike when any abnormality is found during the riding. Contact us at 886-3-597-3688 or e-mail to tsengww@ms54.hinet.net or any one of our authorized service centers. Front handles: Make sure that the front handles are fixed well.
Page 14 Check Before Riding Note Check and adjust the following points before riding the electric scooter. Stop riding the electric bike when any abnormality is found during the riding. Contact us at 886-3-597-3688 or e-mail to tsengww@ms54.hinet.net or any one of our authorized service centers. Break lever: Make sure that the tension of the break lever is proper.
Page 15: Riding Instructions
Riding Instructions Power switch: To ride the electric bike, turn on the switch and hold on the break lever for more than 6 seconds. The power will shut off automatically when the electric bike is not ridden within 3 consecutive minutes. Battery Capacity Indicator Indications: Three indicators light...
Page 16: Trouble Shooting
Trouble Shooting Assembly Possible Causes Measures Fault Power switch 1. Make sure the power switch is turned on. Capacity indicator doesn't light Controller and pack 2. Make sure the c onnection between the controller and pack is tight 3. If it doesn't work, contact with us or our authorized service centers for repair.
Page 17 AWIN TECHNOLOGY CORP. No. 15, TA TUNG RD., HSINCHU INDUSTRIAL PARK HSINCHU 303, TAIWAN, R.O.C. TEL: 886-3-5973688 FAX:886-3-5973699 http://www.awintech.com.tw...
