INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS FOR THE PLANNING
AND INSTALLATION OF A SOLARFOX® DISPLAY
The following information will provide a brief overview for installing a Solarfox® displays. The instructions are
aimed particularly at installers and planners.
Table of contents
1.
Time and cost estimate ................................................................................................................................................................................................ 2
2.
Work steps ........................................................................................................................................................................................................................... 2
3.
Assembly variants in indoor and outdoor applications ............................................................................................................................... 3
4.
Connectors ........................................................................................................................................................................................................................... 3
5.
Data communication and network integration ................................................................................................................................................ 5
6.
Checklist ................................................................................................................................................................................................................................ 6
7.
Technical specification for wall mounting and dimensions ..................................................................................................................... 7
8.
Interfaces / compatible monitoring systems - version: 03-2016 .................................................................................................... 12
9.
Connection of old systems and photovoltaic systems with no data logger .................................................................................. 13
10.
Display commissioning with subsequent commissioning of the data source ............................................................................ 14
11.
Connection of additional systems and data sources .................................................................................................................................. 14
12.
Timing and power saving feature .......................................................................................................................................................................... 14
13.
Maintenance ...................................................................................................................................................................................................................... 14
14.
Warranty .............................................................................................................................................................................................................................. 14
SOLARFOX® Solar Display Systems
SOLEDOS GmbH
Karl-Gross-Str. 3 - 63584 Gründau - Germany
Tel. +49 (0) 6058 - 91638-0
Email: support@solar-fox.de
Web: www.solar-fox.com
Version: 02/2018
Seite
1/14
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Solarfox SF-300
-
Page 1: Table Of Contents
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS FOR THE PLANNING AND INSTALLATION OF A SOLARFOX® DISPLAY The following information will provide a brief overview for installing a Solarfox® displays. The instructions are aimed particularly at installers and planners. Table of contents Time and cost estimate ........................................ 2 Work steps ............................................ -
Page 2: Time And Cost Estimate
1. Time and cost estimate The following calculation helps you calculate the cost of installing a Solarfox® display and plan. The following calculation assumes that electricity and network connection (LAN or WLAN) are already available at the installation location. Time... -
Page 3: Assembly Variants In Indoor And Outdoor Applications
• 1 x RJ45 network (Ethernet) connection (cable: CAT5e) Instead of a network connection via Ethernet cable, it is possible to use a Wi-Fi network. To do this, Solarfox® offers an optional WLAN stick with an antenna. Alternatively, a UMTS router can also be used for a mobile radio connection. A flat rate is required. The traffic depends on the content and the refresh rate of your slideshow. - Page 4 Connection plan Solarfox® display (example) Network-Switch Ro uter & Firewall INTERNET RJ45 (Ethernet) RJ45 OR WIFI DATALOGGER OR (Ethernet) INVERTER 230V Stromanschluß (bauseits) Solarfox-Display Local network PV SYSTEM Ro uter DATALOGGER OR INVERTER PV SYSTEM Ro uter DATALOGGER OR INVERTER The data connection to the photovoltaic system is always done via the Web interface.
-
Page 5: Data Communication And Network Integration
5. Data communication and network integration An Internet connection is required for the operation of the Solarfox® display. In order to do this, the display gets of yield data from the Solarfox® Web server at regular intervals. You will find below all information that are important for the data connection in company or agency networks. -
Page 6: Checklist
Street: Postal code and city: Contact person: Tel: E-Mail: 2) Information about existing connections for the Solarfox® display ☐ Is there a possibility of accessing the Internet? (LAN/WLAN/etc.) ☐ ☐ Does it consist of a power connector with 2 Sockets at installation? ☐... -
Page 7: Technical Specification For Wall Mounting And Dimensions
7. Technical specification for wall mounting and dimensions Wall panel‘s wall mount for Solarfox® SF100 / SF-300 24“ and 32“ The carrier plate is wall mounted and then holds on the display with the inclinable carrier. Please select the appropriate screws and anchors for your wall (Please pay attention to the weight (see table). These are not included in delivery. - Page 8 332 mm 59 mm 79 mm 3,5 kg SF-100 32“ 740 mm 435 mm 84 mm 135 mm 6,5 kg Solarfox® SF-300 Series: display dimensions and weight Display Length Width Depth without Depth with Weight Wall mount Wall mount SF-300 24“...
- Page 9 Technical drawing: SF-400 32“ (Outdoor-Serie) SOLARFOX® Solar Display Systems Tel. +49 (0) 6058 - 91638-0 Version: 02/2018 Seite SOLEDOS GmbH Email: support@solar-fox.de 9/14 Karl-Gross-Str. 3 - 63584 Gründau – Germany Web: www.solar-fox.com...
- Page 10 Technical drawing: SF-400 43“ (Outdoor-Serie) SOLARFOX® Solar Display Systems Tel. +49 (0) 6058 - 91638-0 Version: 02/2018 Seite SOLEDOS GmbH Email: support@solar-fox.de 10/14 Karl-Gross-Str. 3 - 63584 Gründau – Germany Web: www.solar-fox.com...
- Page 11 Technical drawing: SF-400 55“ SOLARFOX® Solar Display Systems Tel. +49 (0) 6058 - 91638-0 Version: 02/2018 Seite SOLEDOS GmbH Email: support@solar-fox.de 11/14 Karl-Gross-Str. 3 - 63584 Gründau – Germany Web: www.solar-fox.com...
-
Page 12: Interfaces / Compatible Monitoring Systems - Version: 03-2016
Skytron Energy Gmbh Skylog SMA AG Sunny Portal (All types) SOLARFOX® Solar Display Systems Tel. +49 (0) 6058 - 91638-0 Version: 02/2018 Seite SOLEDOS GmbH Email: support@solar-fox.de 12/14 Karl-Gross-Str. 3 - 63584 Gründau – Germany Web: www.solar-fox.com... -
Page 13: Connection Of Old Systems And Photovoltaic Systems With No Data Logger
Zeversolar Monitoring Portal Attention: All Solarfox® data interface are basically free of charge. There are running costs or fees by Solarfox®. Portal operators for monitoring expenses depending on the manufacturer and portal. However, this does not affect the Solarfox® displays. Solarfox® does not charge any ongoing portal fees. -
Page 14: Display Commissioning With Subsequent Commissioning Of The Data Source
Timing and power saving feature Solarfox® displays have a built-in timer, which allows individual day at a certain time to turn on the display and turn off at a specified time. In this way the appliance can be adapted energy-efficient to the desired service life.
