Summary of Contents for Blueone BTW28
- Page 1 Web server Software User Manual Bluetooth and WiFi Proximity Marketing - 1 -...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Introduction.......................................- 3 - 2. Hardware Set-up....................................- 4 - 3. Webserver Software Login................................- 4 - 4. Create Campaigns...................................- 8 - 4.1 Add Files for Bluetooth Campaign..........................- 8 - 4. 2 Create Bluetooth Campaign............................. - 10 - 4.3 Create WiFi Campaign.................................- 12 - 4.4 Setup WiFi Route................................ -
Page 3: Introduction
Our Bluetooth and WiFi Proximity Marketing device includes Hardware and Software. Web server is web management platform for managing Bluetooth marketing and WiFi marketing device. Users can operate multiple devices on-line remotely. It is an easy way to configure the campaigns and manage the Proximity Marketing Devices. Model BTW28 BTW21 BTW Pro2 BTW14... -
Page 4: Hardware Set-Up
2. Hardware Set-up Install antennas and power on device. POWER INPUT: DC 12V 3A power adapter. USB INTERFACE：1. Used to connect WiFi Dongle or 3G dongle to device; 2. Used to connect USB memory stick for offline management. NETWORK INTERFACE：Used to connect to Ethernet (Router) with Ethernet cable. LED Lights：Indicate working status of the Device. - Page 5 Installation Notes 1. Away from very high or extremely low temperature place. 2. Do not put it on a humid place. 3. Do not place other equipment above the Bluetooth and WiFi Marketing device. 4. To increase transmitting range and avoid Bluetooth and WiFi signal blocked by other obstacles, hereby advise installation height to be 2.5-3.5 meters;...
-
Page 6: Webserver Software Login
3. Web-server Software Login Login URL: http://www.wireless-marketing.net Enter your user name and password which you received via e-mail. If you lost your password, please click "Forgot your password" to get it back by email or contact our sales department. - 6 -... - Page 7 You can also reset the password. After logging in, click on your username, a windows will pop up and you can reset the password now. - 7 -...
-
Page 8: Create Campaigns
4. Create Campaigns 4.1 Add Files for Bluetooth Campaign Click "Campaign" "Bluetooth Files" "Add New Files" " Choose Files" "OK". “html 5” uploading method for Chrome and FireFox browser. - 8 -... - Page 9 Bluetooth Campaign file format The device does not limit file formats by itself. You can send virtually every kind of files to your customers, just taking care that those files are easy for mobile phone to open. Most popular kinds of file format, Image Audio Video...
-
Page 10: Create Bluetooth Campaign
4. 2 Create Bluetooth Campaign Click "Campaign" "Bluetooth Campaign" "New Bluetooth Campaign" Input campaign name Select Campaign files Click "Apply", after that a new Bluetooth campaign will be listed under "Campaign List". - 10 -... - Page 11 Campaign Work Modes Sequence: All campaign files will be sent out to a Bluetooth-enabled device at once. Schedule: Each campaign file will be sent at a specific period. Lottery: Campaign files will be sent in Random to different Bluetooth-enabled devices. Lottery mode is especially designed for sending lottery and prized information.
-
Page 12: Create Wifi Campaign
send the campaign again to it after one hour later. 4.3 Create WiFi Campaign Method 1: Add New Campaign Click "Add New Campaign" Fill in “WiFi Campaign Name” Click "Choose File" Fill in remarks/information about the campaign file Fill a Specific Website in “Internet” Fill in the browsing time of images Select file and click "... - Page 13 “html 5” uploading method is for Chrome and FireFox browser. “Internet” is for a redirected website. “Time” is for displaying the ad files before you can enter the website.. - 13 -...
- Page 14 Method 2: Upload Campaign Click “Upload Campaign” Fill in “Webpage Name” Fill in the index page name“index.html” or “index.php” Upload webpage in zip format by clicking “html5” or “ flash” - 14 -...
-
Page 15: Setup Wifi Route
4.4 Setup WiFi Route Click "Campaign" "WiFi Route" "New WiFi Route" Name the WiFi Essid Select Advertising Approach Set lease time Click "OK" . “WiFi Route Setting” and “Internal DHCP Server Setting” can be kept default settings. Three Approach Options: 1. - Page 16 Notes: Redirect to Internet: Users can surf the Internet immediately after they view the advertising webpage. Redirect to specific web: Users will be redirected to the specific website and be locked on this website for the setting period of time( redirect time). When the redirect time arrives, they can surf the Internet freely.
-
Page 17: Update Bluetooth Campaign
5. Operate 5.1 Update Bluetooth Campaign via the Internet Switch to Operate page Select the online device(one or multiple devices) to update Tick command "Update Time" and "Update BT Campaign", then select the Bluetooth campaign, Click "Operate". When status of this command displayed as "Success", this command is updated to device successfully. Offline Online - 17 -... -
Page 18: Update Wifi Campaign
5.2 Update WiFi Campaign via the Internet Select the online device(one or multiple devices) to update Tick command "Update Time", "Update Multi-WiFi Campaign", select the Route Name and Webpage. Click "Operate". When status of this command displayed as "Success", means this command is updated to device successfully. - 18 -... -
Page 19: Update Bluetooth Campaign And Wifi Campaign Simultaneously
5.3 Update Bluetooth Campaign and WiFi Campaign simultaneously On "Operate" page Select online device Tick "Update Time", "Update BT Campaign" and select a Bluetooth campaign Tick "Update Multi-WiFi Campaign", Select a Route Name and Webpage. Click "Operate". When status of those commands are displayed as "Success", the commands are updated to device successfully. - 19 -... -
Page 20: Update Via Usb
5.4 Update via USB Select the Operate commands Plug a USB flash drive to your PC Click "Save to Removable USB" (As the file is in zip, please decompress the files from the zip first) Copy the decompress files to USB flash drive Plug the USB flash drive to the device The device will be updated automatically. -
Page 21: Sending Statistics
6. Sending Statistics 6.1 Get sending Statistics from Device 6.1.1 Get sending statistics of Bluetooth Campaign On Operate page, choose the online devices, tick commands "Get blacklist" and "Get statistics", click "Operate". Status success means the statistics have been accessed from the device to the Web-based software. 6.1.2 Get sending statistics of WiFi Campaign On Operate page, choose devices to update (device must be online), tick command "Get WiFi Statistics", click "Operate". -
Page 22: Analyse Statistic
6.2 Analyze Statistics Switch to "Statistics" page, click Bluetooth Statistics, you may click "Access" to view all sending statistics of all devices and the corresponding campaigns. You also can access the statistics by time period, the device, or the campaign. Click "Data" button to view the detailed statistics, and you may click "XLS REPORT"... -
Page 23: Device Account Management
7. Device Account Management 7.1 Create a Sub-account Switch to "Manager" page "Device Manager" Select "Create New User" Set a user name, password and an email address. NOTE: Please input a valid email address here for getting back the password in case that you forget it. - 23 -... -
Page 24: Sell Device To A User
7.2 Sell device to a new user After you create sub-accounts, click "Sell" button of this device, select a user from your user list, the device will be sold to this user once you click “ Sell Device to “. From then on, you could log into the web server software with the new User name and password to manage this device. After you sell the device, you would not be able to manage this device from the owner account any longer. - Page 25 Note: When this lease account is expired from this user account, the user can not update this device any more. Owner can get the device back whenever even the lease account is not expired by clicking "Give Back" button. - 25 -...
