  • Page 1 Quick Guide MDAS -10 KC Certified : MSIP-CMM-MVN-MDAS10...
  • Page 2 If recorded videos are broken due to users mishandling, the damaged video is not guaranteed to recover. Do not touch the screen directly with sharp objects. Movon is not liable for damage of the screen. Operating temperature is -20~65℃(4~149 ℉). MDAS-10 may not operate properly and be damaged in excess of the temperature parameters.

  • Page 3: Table Of Contents

    Table of contents 1) Introduction 1. About MDAS-10 4) Operation 1. Set-up menu 2. Specification 3. Components 4. Part description 5) Warranty information 2) Installation 1. Cabling overview 2. Installing 2.1 Installing rear-view cameras 3. Calibration 3) Function 1. Lane departure warning 2.
  • Page 4 1.Introduction - 1) Introduction MDAS-10 is a single camera-based driver assistance system. The product focuses on assisting drivers by preventing drowsy or reckless driving, and recording driving information with the three functions listed below Major functions Lane departure warning(LDW) Provides Lane Departure Warning (LDW) for safe driving. It alerts the driver with sound and visual warnings and helps to regain direction if the driver departs lanes unintentionally.

  • Page 5: Specification

    1.Introduction - 2) Specification Cortex A8 Series Screen 4.3 inch, 480x272 pixel, touch screen panel Camera 1M pixel, Diagonal 103.2°C Power DC 12V/24V support (Consumption: 900mA) Video MP4(H.264 codec: Front-720P, 30fps, Rear: 480P, 15~30fps) Format Audio AAC/MP3 Storage 4~32GB Micro SD card support Input Power port (Micro USB or Rear Connector), Camera port(micro USB) Camera...

  • Page 6: Components

    1.Introduction - 3) Components Micro SD card 8G MDAS camera MDAS main User manual MDAS cable & reader GPS module Universal 4-pin Rear-view camera (Option) mount (Option) (Option)

  • Page 7: Part Description

    1.Introduction - 4) Part description Micro SD card slot Double sided tape Reset hole Screen On/Off button Camera cable Lens Angle adjuster Main cable port Touch LCD MINI USB...
  • Page 8 2.Installation - 1) Cabling overview...

  • Page 9: Installing

    2.Installation - 2) Installing Step : 1 Remove the adhesive tape from the camera and attach to the center of front windshield from inside. And connect camera cable to the main cable * The location of camera that should be within +/-5cm from the center.

  • Page 10: Installing Rear-View Cameras

    2.Installing - 2.1) Installing rear-view cameras After attaching the optional rear camera to preferred location on the rear windshield, connect camera cable to the main cable’s 2.5ø slot. Caution : If using an external rear camera outside of the car, ensure that the external rear camera’s connector is following MDAS-10’s cable pin specification indicated on the picture.

  • Page 11: Calibration

    2.Installation - 3) calibration Entering calibration mode After the car engine’s on, press Calibration icon after MOVON logo disappears Initial calibration screen is the same as the picture on left. Press Calibration once more to proceed to configuration. -10-...
  • Page 12 2.Installation - 3) calibration Select the auto maker (ex: GM, Ford, etc.), and then select Adjust the camera knob to locate the yellow line on the the vehicle model in accordance with year of manufacture. horizon or between the red lines. You can enlarge the If the vehicle model is not listed, go to www.mdas.co.kr and image by clicking the scene frame.
  • Page 13 2.Installation - 3) calibration If the camera is attached away from the center line of Lane departure warning(LDW) sensitivity adjustment. the vehicle, please adjust how far it is located from the If you want to change the warning timing, please click the center.
  • Page 14 2.Installation - 3) calibration * If the vehicle’s signal is not correct, you can modifty the data by clicking “modify” in the final screen. So, if a car signal is not received from the supposed data connection, you can select a different type of data you need.

  • Page 15: Lane Departure Warning

    3.Function - 1) Lane Departure Warning Lane Departure Warning 062 Km Speed Distances between the wheels 0.81 m 1.24 m 1. LDW alerts the driver with sound and visual warnings when the vehicle departs from its lane unintentionally when driving over 60km/h(38 mph). 2.

  • Page 16: Dash Cam

    3.Function - 2) 2CH Dash cam 1. Normal mode: Records front and rear driving scenes simultaneously in real-time and recorded videos can be found in ory_rec folder. If REC button shows blue color , it indicates video is not recorded. So, please ensure that the icon is red before using. 2.

  • Page 17: Digital Tachograph

    4. DTG viewer needs to be downloaded from http://www.mdas.co.kr in order to check the stored driving information. 5. You can check the moving route and location in real time via Fleet Management Service by MOVON provided. If you need the Fleet Managements Service, please call (+82) 2-2050-4676 6.

  • Page 18: 4) Operation

    4.Operation - 1) Set-up menu Record Setting The image shows all available menu settings. However, Basic : Video quality and recording hour unit change. You may have limited access to menu settings on MDAS-10. Advanced : Ordinary or event recording On/Off. Voice recording On/Off.
  • Page 19 4.Operation - 1) Set-up menu Tachograph Setting - 1 Tachograph Setting - 2 ID Number : Car VIN Number Calibration Type : Car type If the current car data(Speed, RPM) is not correct, users Registration : Car registration no. can modify changed values. Provider : Registration no.
  • Page 20 4.Operation - 1) Set-up menu G-Force sensor setting LCD’s display setting / MDAS-10’s Main Screen Change sensitivity of G-Force sensor. The lower numbers Use auto off : Turns off the LCD display 1 minutes after MDAS-10 is powered on. in Step, the more sensitive. Use guide Line : Checks if LDW-related virtual Line is displayed.
  • Page 21 4.Operation - 1) Set-up menu Wi-Fi Setting - 1 Miscellaneous Setting Enable WiFi : Checks if Wi-Fi is activated. Firmware Update : Updates a Firmware. Default Setting : Initializes MDAS-10. -20-...

  • Page 22: Warranty Information

    MDAS-10 is not covered by the limited product warranty. The warranty covers only manufacturing defects only which are occurred within warranty period. Warranty Period / MDAS-10 : 1 year : 20,000Km / Movon-providing microSD card : 3 months Movon-providing rear view camera : 6 months Please download and back up all saved data before sending MDAS-10 to our After-sales Service center.
  • Page 23 FCC Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
