- Page 1 MINING OPERATIONS Access Point 360A Technical Reference Manual Software Version: v1.19 Version No.2.0 Issued October 2015 English...
- Page 3 Devex Mining delivers leading solutions for fleet management and production optimization, machine maintenance, business intelligence and analytics. Devex Mining is part of Hexagon Mining, the only global provider of surface and underground smart mining solutions that integrate design, planning, and operations technologies for safer, more productive mines.
- Page 4 Revision History Date Document Software Author Revision Version Version 21 JUL 1.19 Gustavo Initial Document Release 2015 Henrique L.Severino 13 OCT 1.19 Marco Modifications in label 2015 Antonio documentation Santuci Carvalho © Devex Mining...
-
Page 5: Table Of Contents
Table Of Contents Document Introduction ................1 Contacting Support ...................... 1 Document Conventions ....................1 Access Point 360 Overview ............... 2 System Information ...................... 2 Product Faceplate Description ..................2 Labels ........................... 2 2.3.1 Labels Location ....................2 2.3.2 Access Point 360 FCC Certification Label ............4 2.3.3 Access Point 360 Serial Number Label ............. -
Page 7: Document Introduction
Document Introduction The AP360 (Access Point) Technical Reference Manual is part of the Devex Mining´s reference manual suite. This manual is for internal use only and is intended to serve as a commissioning and maintenance guide for the AP360 product when used within a Smartmine system. The AP360 Technical Reference Manual is to be used as a supplement to the AP360 User Reference Manual. -
Page 8: Access Point 360 Overview
Access Point 360 Overview The Access Point 360 is a communication controller between static and remote device (Data head End - DHE and Trackers360) and the management system SmartMine|UG. System Information Note: The document uses generic images to show general layout and generic information for various procedures. - Page 9 © Leica Geosystems Commercial in Confidence...
-
Page 10: Access Point 360 Fcc Certification Label
2.3.2 Access Point 360 FCC Certification Label 2.3.3 Access Point 360 Serial Number Label © Devex Mining... -
Page 11: Ap Commissioning
AP Commissioning Commissioning Workflow 1. See Chapter 4 Hardware Installation. 2. See Chapter 5 Software Installation. © Leica Geosystems Commercial in Confidence... -
Page 12: Hardware Installation
Hardware Installation Before Installation Installation requires specialized knowledge and must be installed by a Hexagon Mining Authorized Installer. Hexagon Mining recommends that installation of the Access Point 360 equipment be performed by a qualified technician because installation requires marking electrical connections and software development. -
Page 13: Rear View
4.2.2 Rear View © Leica Geosystems Commercial in Confidence... -
Page 14: Data Head End - Dhe
Data Head End – DHE as shown in the figure below. The AP360 must be fixed near to DHE, Power Cable Installation Caution The Access Point 360 is a 110 – 220 Volts AC system only. 1. Connect the supplied power cable to a reliable power source, for example, the rack’s main power system. -
Page 15: Communication Cable Installation
Communication Cable Installation Connect the communication cable (Part number: DVXHW_CBL0056R02 - Cabo AP360 – DHE) in the middle AP360’s connector and other cable extremity in the DHE’s connector, as shown in the figure below. Ethernet Cable Installation Connect one side of the ethernet cable in the connector of the Access Point 360, show in the figure below. -
Page 16: Final Assembly
Final Assembly The figure X.XX shows the back view of AP360 installed in the rack with the DHEs. The figure shows the three cables installed. Network Cable Power Suplly Cable Communication Cabo de Cable Rede © Devex Mining... -
Page 17: Software Installation
Software Installation The following procedure is used for software upgrades of AP360. Note: Contact Hexagon Mining | Devex for the required files. Update Accesst Point 360 using debug cable WARNING: Do not turn off the unit, or remove the debug cable while the software upgrade is under way. - Page 18 port. In the "Speed" field set "38400", as shown in figure below. Finally click "Open" and connect the power supply cable to the AP360. 7. Configure the serial interface of your desktop or laptop and open the software “putty” and configure which are serial port and communication speed, as show in figure below: 8.
-
Page 19: Installation And Configuration Verification
> root 11. Wait the process finalization and the AP360 will be restarted automatically, as show in figure below: Installation and Configuration Verification 12. Connect the AP360's power cable into the power supply, 110 or 220VAC (50/60 Hz) and Ethernet cable. Wait this boot, as shown figure below. ©... - Page 20 13. Press the center button, highlighted in Figure below. This prodedure displays the AP360 menu. Press the center button. Note that the device's network settings are displayed. © Devex Mining...
-
Page 21: Technical Data
Technical Data Design Industrial metal housing 6.1.1 User interface Display 20x4 Characters Console RS232 serial 6.1.2 Dimensions Length (cm) Width (cm) Height (cm) 23,85 48,26 4,44 6.1.3 Weight Wieght (Kg) 3,300 6.1.4 Power Consumption External Supply Voltage Voltage Range 110 to 220 VCA Envionmental Specifications 6.2.1 Temperature Operating Temperature (ºC) -
Page 22: Fcc Statement (Applicable For U.s.)
Ethernet K-Line J1708 Display Digital Outputs FCC Statement (Applicable for U.S.) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-vide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 23: Glossary
Glossary Term Definition Access Point Data head End Federal Communications Commission Hirose Protection Index Universal Serial Bus voltage current alternate SOPs Standard Operating Procedures SWPs Safe Work Procedures © Leica Geosystems Commercial in Confidence... - Page 24 Hexagon Mining is the only company to solve surface and underground challenges by integrating design, planning, and operations technologies for safer, more productive mines. Headquartered in Tucson, Arizona, with more than 30 offices across five continents, the company is a dynamic network of talented mining professionals delivering technology, service, and support.
