Aqua-Cycle Water Trikes—AC6
Assembly Instructions and Maintenance
Send us some photos and interesting experiences
of you with your Aqua-Cycle Water Trike. With
your permission, we will add them to our website.
Send to photos@aquatic-adventures.com
Aquatic Adventures International, Inc.
5348 Vegas Dr.
Las Vegas NV 89108
800-970-2688 Toll Free
(888-970-0467 Fax)
www.aquatic-adventures.com
Email: assembly@aquatic-adventures.com
Made in the U.S.A.
Page 12
Rev 6/18/2014
For assistance contact us at 800-970-2688
Aqua-Cycle Water Trikes—AC6
Assembly Instructions and Maintenance
ASSEMBLY INSTRUCTIONS
This section will guide you through the assembly process. The second half of this
booklet covers maintenance to keep your Aqua-Cycle Water Trike in tiptop shape.
Please read all assembly instructions before you begin.
NEED HELP? Give us a call. It is better to get your questions answered rather
than hope what you are doing is correct. Your Aqua-Cycle Water Trike will last for
many years if assembled correctly.
These instructions are in the order that works best for quick assembly. Complete
each step before going to the next. As you start each new step re-read all the in-
structions for that section before proceeding.
If you have several Aqua-Cycle Water Trikes to assemble, do them one at a time. It
is much better to assemble and check out each one before proceeding to the next
one. Assembly line work does not give the best results nor is it any faster.
ECO-FRIENDLY—We do not market recreation products that have been chemically
"brightened". Our manufacturing processes meet the three-fold criteria of biodegradability,
zero (net) environmental impact and full scope reuse/renewability. We have long been con-
cerned with protecting both our customers and the ecosystems in which customers enjoy our
products. This policy is based upon our continuing commitment to responsible, earth friend-
ly business practices.
NOTES AND CAUTIONS
SAFETY—Never allow an Aqua-Cycle Water Trike to be operated without the
fork guard and belt guard properly installed for the protection and safety of your
users.
ANTI-SEIZE COMPOUND—Included with the assembly parts is a small quantity
of anti-seize compound. Put a small dab along the full length of the thread before
screwing on the nut. As the nut is turned the compound will be spread around the
thread to keep the nut from seizing up (galling) on the bolt. Galling is a common
problem with stainless steel lock nuts and bolts unless anti-seize compound is used.
If the nut and bolt seize up there is no way to separate them. Cutting, grinding or
twisting the bolt apart is the only solution. It is very important to use this com-
pound.
REAR WHEELS—Do not over-tighten the nuts and bolts when mounting the rear
wheels onto the axle. Follow the directions carefully. Tightening the wheel bolts
and nuts is not like tightening the lug nuts on a car wheel—do not over-tighten.
FRONT WHEEL—Carefully tighten the hex nuts against the front wheel bushings
on the front axle. Do not force the bushings into the center tube by over-tightening.
PEDAL SCREWS—Do not over-tighten the pedal screws.
For assistance contact us at 800-970-2688
Forcing the pedal
Page 1
Advertisement
Summary of Contents for Aquatic Adventures Aqua-Cycle AC6
-
Page 1: Assembly Instructions
NOTES AND CAUTIONS SAFETY—Never allow an Aqua-Cycle Water Trike to be operated without the fork guard and belt guard properly installed for the protection and safety of your Aquatic Adventures International, Inc. users. 5348 Vegas Dr. ANTI-SEIZE COMPOUND—Included with the assembly parts is a small quantity of anti-seize compound. - Page 2 Aqua-Cycle Water Trikes—AC6 Aqua-Cycle Water Trikes—AC6 Assembly Instructions and Maintenance Assembly Instructions and Maintenance screws tight on new pedals can create stress in the plastic and shorten their life. SAFETY INFORMATION PLATE A Safety Information plate is attached to the center tube of the frame in a position NOTES ABOUT FUTURE MAINTENANCE for each rider to see.
- Page 3 Aqua-Cycle Water Trikes—AC6 Aqua-Cycle Water Trikes—AC6 Assembly Instructions and Maintenance Assembly Instructions and Maintenance squeezes and crushes the wheel center area. The nuts should be snug, but not tight. these same tools will be used for repair and maintenance. Good quality tools will make assembly easier.
- Page 4 Aqua-Cycle Water Trikes—AC6 Aqua-Cycle Water Trikes—AC6 Assembly Instructions and Maintenance Assembly Instructions and Maintenance front-middle hole toward the back. Take a second strap, push it through the back FRONT WHEEL hole and aim it to hit and slide under the first strap. The first strap should guide the Inspect the front wheel for cracks along the center seam.
- Page 5 Aqua-Cycle Water Trikes—AC6 Aqua-Cycle Water Trikes—AC6 Assembly Instructions and Maintenance Assembly Instructions and Maintenance can be repaired before they become major. Check all bolts and nuts to be sure they on the handle bar and the top edge of the seat back. are tight.
-
Page 6: Maintenance
Aqua-Cycle Water Trikes—AC6 Aqua-Cycle Water Trikes—AC6 Assembly Instructions and Maintenance Assembly Instructions and Maintenance Slide the axle through the center tube to be sure the passage is clear. Sometimes MAINTENANCE during manufacturing plastic gets into the center tube. Excess plastic can be forced out using the front axle as a pusher.
