Fireside Furnishings Kenwood Installation Manual

Wall cabinet

Hide thumbs

Kenwood wall cabinet

Assembly / Installation Guide

These instructions apply only to the cabinetry and facing material that will surround the firebox.

PLEASE SEE THE FIREPLACE MANUFACTURER'S INSTALLATION INSTRUCTIONS TO ENSURE THAT ALL CLEARANCE AND

INSTALLATION REQUIREMENTS ARE BEING MET.

fireplace by 9-1/4" above finished floor

level. All dimensional requirements of

For field finishing the following

two products have been

approved for use on this

product:

1. Lacquer - Sherwin Williams

2. Paint - Sherwin Williams

All other products may result

in discoloration or undesired

results.

www.fireplaces.com

Kenwood wall cabinet with optional

base.

Note: Using the base will raise the

fireplace installation should be ad-

justed accordingly.

Notice !!

"Wood Classics A68F90".

"Duration Home A98W151

Interior Latex Paint".

PLEASE READ

Kenwood wall cabinet without optional

• Improper installation,

adjustment, can cause injury

or property damage. For

assistance or additional

information, consult a

qualified installer, service

agency, or the gas supplier.

• Comply with all minimum

clearances to combustibles

as specified in firebox manual.

Failure to comply may cause

house fire.

base.

Warning !!

KENWOOD-WALL-CAB

REV. 1

06.17.2009
