Summary of Contents for NRSRelief UNHCR Standard
- Page 1 Viva™ Family Tent - UNHCR Standard Tent Assembly Manual Core Relief Items Viva™ Family Tent UNHCR Standard Watch tent assembly videos Tent Assembly Manual - Core Relief Items on our website: www.nrsrelief.com www.nrsrelief.com...
- Page 2 Viva™ Family Tent - UNHCR Standard Components 1 x outer tent 12 x pre-installed guy ropes 2 x 4m ridge pole sections 1 x inner tent 3 x 2.2m standing poles 6 x 1.25m side poles 4 x 1.4m door poles...
- Page 3 Viva™ Family Tent - UNHCR Standard Unpack and unroll the tent 2 x ridge pole sections Place the contents next to the erection site. Connect the ridge pole parts (C) together. 2.2 m 1.25 m 2 x standing poles 6 x side poles Slot two standing poles into the hole at each end of the ridge pole.
- Page 4 Viva™ Family Tent - UNHCR Standard 1.4 m 4 x door poles 1 x Outer tent Place two door poles on the ground on each side of the standing poles Place two door poles on the ground to each side of the standing poles.
- Page 5 Viva™ Family Tent - UNHCR Standard Fold the outer tent in half over the centre line so that the Velcro loops are exposed. Place the outer tent on top of the poles so that the centre line and Velcro loops are aligned with the ridge pole.
- Page 6 Viva™ Family Tent - UNHCR Standard 4 x V-shaped Extend the four corner guy ropes at an angle of 45 degrees from the tent, aiming the 1 x Hammer Hammer V-shaped pegs into the ground and tie guy ropes to them.
- Page 7 Viva™ Family Tent - UNHCR Standard 2 x V-shaped 1 x Hammer Pull out the central rope on either side of the tent. Hammer V-shaped pegs into the ground and tie the ropes to them. 4 x J-shaped 1 x Hammer Pull out the 4 door guy ropes.
- Page 8 Viva™ Family Tent - UNHCR Standard 1.25 m 1.4 m 6 x side poles F 4 x door poles Erect the door poles. Ensure the top pins are inserted through the Erect the side poles from inside. Ensure the top hooks of the pole are eyelets in the outer tent.
- Page 9 Viva™ Family Tent - UNHCR Standard 22 x steel pin 1 x hammer Tie the outer tent to all 10 side and door poles using ribbons. Hammer steel pins through all eyelets of the outer tent mud flaps. 1 x inner tent Carry the inner tent inside.
- Page 10 Viva™ Family Tent - UNHCR Standard Attach the inner tent to the outer tent ceiling using the toggles. Clip the inner tent to the outer tent walls using the black plastic clips and D-rings. 2.2 m 1 x central 4 x steel pin...
-
Page 11: General Usage Notes
Viva™ Family Tent - UNHCR Standard General Usage Notes: • Window flaps can be opened and closed according to user requirements. To open, roll up and secure with the toggles. • To open the front and back door flaps, roll up and secure with the toggles.
