SapphireScientific Upholstery Pro User Instructions

The Upholstery Pro cleaning tool provides deep, rapid penetration of cleaning solution and
simultaneous high volume extraction. Lightweight, easy to use, and adjustable for a wide range
of fabrics and soiling conditions, the Upholstery Pro produces cleaner, drier fabrics.
R E A D A N D S A V E T H E S E I N S T R U C T I O N S

KEY FEATURES

• Comfortable handle and highly flexible vacuum hose
provides relaxed balanced handling and
substantially reduces operator fatigue
• In-line solution strainer helps prevent clogging
• High pressure injector glide provides deep, even
penetration of solution into fabric surface
• Unique dual extraction slots permit full extraction in
both directions across fabric surfaces
• Solution control valve provides precise control for
widest range of fabric types and soiling conditions
• Sliding vacuum release allows for easy vacuum
adjustments on the fly
• Clear housing for easy monitoring of water flow,
fabric or carpet dryness, and cleaning effectiveness,

INITIAL SETUP

Connect the front quick-connect solution line to the wand
coupling and slide the front vacuum hose cuff (Fig. A, 5)
firmly over the ribbed hose receiver. The Upholstery Pro
is now ready to be attached to your extraction
equipment.
FIG. A: HEAD, VACUUM HOSE AND
SOLUTION LINE ASSEMBLY
2. Front solution line
quick-connect coupling
1. Vacuum
release slide
07-01713B
Upholstery Pro
User Instructions
Patent Pending
4. Flow adjustment
valve (inside cover)
3. Insulated adjustment
valve wrap
5. Front vacuum
hose cuff
1
USING THE UPHOLSTERY PRO
1. Connect the rear quick-connect solution line to the
extractor solution line
2. Attach the rear hose coupling either to 1½ in i.d.
(coupling fits over hose) or to a 2 in. i.d. (coupling fits
inside hose).
3. Turn on extractor.
4. Squeeze the trigger lever to release the solution and
begin cleaning. The sliding trigger lock may be used
to hold the trigger valve in the open position.
5. Use the flow adjustment valve (Fig. A, 4) to adjust
solution flow and the vacuum release slide (Fig. A,
1) to adjust the strength of the vacuum.
WARNING: Flow adjustment valve assembly can
become extremely hot during use.
Keep valve wrap closed.
Tips for Use
Solution control. Adjust flow according to the fabric
type, absorbency and degree of soiling. Lightweight or
delicate fabrics require less solution volume than
6. Rear solution line
quick-connect
coupling (not shown)
7. Rear vacuum hose
cuff. Cuff fits over
1½ in. hose or inside
2 in. hose.
