Reference Manual
ATV Logo
pantone151
(DIC120)
Multiformat switcher
MS-8
Start Up Manual
Please use your MS-8 only after reading and understanding the content of this
manual.
In particular, please be sure to read all precautions related to the safe use of this
device.
Please be sure this manual is stored in a place where it is readily available to the
operator for reference.
Ver.2.0
Introduction
Functionality and specifications
Names and functions of parts
Mounting to a rack
Connecting external devices
Basic operation
Video and audio operation
Troubleshooting
Support
1
2
3
4
5
6
7
8
9
Advertisement
Table of Contents
Related Manuals for ATV MS-8
Summary of Contents for ATV MS-8
- Page 1 Basic operation Video and audio operation Troubleshooting Support Please use your MS-8 only after reading and understanding the content of this manual. In particular, please be sure to read all precautions related to the safe use of this device. Please be sure this manual is stored in a place where it is readily available to the...
- Page 2 Indicates that the user should unplug the AC adapter from the Unplug the adapter and wall socket or the USB cable from the computer. Refer to the cable illustration for detailed instructions. Multiformat switcher MS-8 Start Up Manual...
- Page 3 • Places exposed to rainfall. • Places where dust and sand accumulate easily. • Places subject to constant vibration or movement. • Tables, benches, or other places that are off-level, wobbly, or otherwise unstable. Multiformat switcher MS-8 Start Up Manual...
- Page 4 ■ Store small parts out of the reach of children. Store spare attachment screws or plastic legs not attached to the main unit out of the reach of children. Failure to do so could result in accidental ingestion. Multiformat switcher MS-8 Start Up Manual...
-
Page 5: Precautions For Use
• When transporting an MS-8, wrap it in packing material and place it in its box or otherwise provide equivalent protection. • If you do dispose of the box and packing that came with the MS-8, be sure to follow all local regulations pertaining to the sorting of waste materials. -
Page 6: Table Of Contents
Other connections --------------------------------------------20 Basic operation ----------------------------------------21 Turning the power on and off. ----------------------------21 Output format settings ---------------------------------------22 Video and audio operation ------------------------23 Switching video ------------------------------------------------23 Adjusting video ------------------------------------------------25 Switching audio -----------------------------------------------27 Troubleshooting --------------------------------------29 Support ---------------------------------------------------31 Multiformat switcher MS-8 Start Up Manual... -
Page 7: Introduction
Introduction Overview • The MS-8 is a presentation switcher that is capable of switching eight separate video signals of differing formats. • It is also capable of simultaneous switching and mixing of audio embedded in video. • It is equipped with input for two SDI channels, two HDMI channels, two RGB/component channels, and two analog video channels. -
Page 8: Functionality And Specifications
Connect to CPU Connect to CPU Connect GPI 1 to CPU Connect GPI 2 to CPU Connect GPI 3 to CPU Connect GPI 4 to CPU GPI 5 GPI 6 GPI 7 GPI 8 Multiformat switcher MS-8 Start Up Manual... -
Page 9: Product Specifications
(without AC adaptor & Electrical power cord & Rack mount brackets & Screws) +0 to +40 degrees Celsius Operation Temparature +41 to +104 degrees Fahrenheit AC adaptor Electrical power cords x 5 Accessories Startup Manual Rack mount brackets x 2 Screws x 6 Multiformat switcher MS-8 Start Up Manual... -
Page 10: Connection Specifications
60 (Conforms to VESA DMT) 1920x1200 60 Reduced Blanking (Conforms to VESA DMT) Color Format 10/12 bits YCC4:2:2, 8/10/12 bits YCC/RGB4:4:4 Audio Format Linear PCM, 16 to 24 bits, 32 to 48 kHz, 2 to 8 ch Multiformat switcher MS-8 Start Up Manual... -
Page 11: Output Connectors
59.94i (Conforms to ITU-R BT.656-5) 720x576 50i (Conforms to ITU-R BT.656-5) Color Format 10 bits YCC4:2:2, 10 bits YCC/RGB4:4:4 Audio Format Linear PCM, 24/20 bits, 48 kHz, 2 ch (Conforms to SMPTE ST299, ST272-C) Multiformat switcher MS-8 Start Up Manual... -
Page 12: Other Connectors
USB 2.0 High Speed (HS) Connector RJ45 Standards 10/100Base-T Power Voltage 12 to 20 V DC IN Power Consumption 35 W Processing Item Description Video Processing 10 bits YCC4:4:4 Audio Processing 24 bits 48 kHz Multiformat switcher MS-8 Start Up Manual... -
Page 13: Names And Functions Of Parts
Refer to P.23 Switch video. EXT INPUT LEVEL knob OUTPUT LEVEL knob Adjust audio volume input from Audio In connector. Adjust audio output level. Refer to P.27 Adjust the audio volume. Refer to P.27 Adjust the audio volume. Multiformat switcher MS-8 Start Up Manual... -
Page 14: Names And Functions Of Rear Panel Parts
Output 6G/3G/HD/SD-SDI signals. Refer to P.18 Connecting to a video output connector Refer to P.20 Other connections USB (UVC+UAC) connector Output USB video and USB audio signals. Refer to P.18 Connecting to a video output connector Multiformat switcher MS-8 Start Up Manual... -
Page 15: Onscreen Menu Names And Functions Of Parts
When a parameter group is selected: Move down one level. When a parameter value is selected: Store the current value. MENU VALUE button When a parameter name is selected: Select an item. When a parameter value is selected: Select the value. Multiformat switcher MS-8 Start Up Manual... -
Page 16: Mounting To A Rack
Rack mount bracket Screws x 3 Rack (sold separately) Attach the rack mount brackets to the rack. Refer to the user manual of the rack for additional details on installation. Screws (sold separately) Screws (sold separately) Multiformat switcher MS-8 Start Up Manual... -
Page 17: Connecting External Devices
For video devices with RCA connectors, use commercially available RCA- a composite BNC conversion. VIDEO IN video device IN8 can be switched to a REF IN connector. See the reference manual for connector (IN8) details on how to use this device. Multiformat switcher MS-8 Start Up Manual... -
Page 18: Connecting To A Video Output Connector
OS X operating systems, making it useful for a wide variety of applications. connector connector * We recommend specifying a 1080p or 720p output format when using a connection USB (UVC+UAC) connector. Only a limited number of applications are available for use with other formats. Multiformat switcher MS-8 Start Up Manual... -
Page 19: Connecting To An Audio/Gpi Input/Output Connector
GPI/AUDIO connectors can be used as GPI connectors based on internal connetor Connecting parameter settings. Also, GPI can be toggled between input and output. GPI devices GPI/AUDIO IN See the reference manual for details on how to use this device. connetor Multiformat switcher MS-8 Start Up Manual... -
Page 20: Other Connections
Connecting the remote USB connector of this device to the USB 2.0 port of REMOTE USB REMOTE USB a PC will enable the user to change parameter values and update software. connector connectors See the reference manual for details on how to use this device. Multiformat switcher MS-8 Start Up Manual... -
Page 21: Basic Operation
AC adapter Remove the electrical power cord from the wall outlet. Wall outlet Remove the output connector of AC adapter the AC adapter from the DC IN connector of this device. Electrical power cord Multiformat switcher MS-8 Start Up Manual... -
Page 22: Output Format Settings
10 seconds or longer. Flashing The MENU EXIT button flashes. Automatically specifies the most suitable format for the connected device. * If the video display does not improve, connect to a different HDMI device. Multiformat switcher MS-8 Start Up Manual... -
Page 23: Video And Audio Operation
(When input signal is alive) alternate video [5] button stops flashing and is a steady red. When switching between IN3, IN5 and IN8 or between IN4, IN6 and IN7, Caution the original video freezes then transition. Multiformat switcher MS-8 Start Up Manual... - Page 24 Refer to P.15 Onscreen menu names and Sync Reference Internal functions of parts H Phase V Phase Switching video Transition Time REF IN ---- Fade out (specified time interval) → several frames → Fade in (specified time interval) Multiformat switcher MS-8 Start Up Manual...
-
Page 25: Adjusting Video
(*1 item) V position Manual H Scale: horizontal Manual V Scale: vertical Press the VIDEO INPUT SELECT button for any of the video input setting levels (*2) to specify video input settings for that button. Multiformat switcher MS-8 Start Up Manual... - Page 26 Scaling RESET per input/output pixels and is available Caution Scaling Type Full up to a 1200% enlargement or a 1200% Manual H Scale reduction. Manual V Scale Zoom H position V position Multiformat switcher MS-8 Start Up Manual...
-
Page 27: Switching Audio
1080 SDI Settings RESET SDI OSD SDI Color G SDI Type LevelB HDMI Settings RESET HDMI OSD HDMI Mode Auto HDMI Color Auto HDMI Color Depth Auto Settings RESET USB OSD USB Audio Level Multiformat switcher MS-8 Start Up Manual... - Page 28 Audio Follow settings Input connector number Settings Description Input connector type Synchronize the audio to the video and Input*(***) switch. Audio Output audio at all times. Audio Follow Channel Level Channel Select Multiformat switcher MS-8 Start Up Manual...
-
Page 29: Troubleshooting
In many of the following cases, the problem is not due to a malfunction. Please double check before requesting repairs to your device. If you are unable to resolve the issue yourself, please visit the ATV website. ( Refer to P.31) Video What should you do if . - Page 30 Is the audio data input from the MS-8 are not compliant with Dolby SDI or HDMI connectors in linear or other non-PCM data. PCM format? There is no sound...
-
Page 31: Support
Support The latest support information is available at the ATV website shown below. ■ ATV Corporation website http://www.atvcorporation.com/ ■ Product page http://www.atvcorporation.com/products/videos/ms-8/ Multiformat switcher MS-8 Start Up Manual... - Page 32 (2) this device must accept any interference received, including interference that may cause undesired operation. COMPLIANCE INFORMATION STATEMENT (DECLARATION OF CONFORMITY) Model Name: MS-8 Type of Equipment: Multiformat switcher Responsible Party: ATV Group Corp. USA Address: 16901 S.Western Ave. #101 Gardena, CA 90247 Telephone: 424-329-3223 For EU Countries This symbol on the product means that used electrical and electronic equipment should not be mixed with general household waste.
