Page 4: Turning Off The Camera
Operations 1.1 Turning On the Blueline Body Camera Hold the Power button for 3 seconds, after a beep, the camera will be turned on and automatically enter preview mode and the status light will turn green. In the preview mode, the following screen will appear: Video icon- Turns Yellow when recording has started Photo icon- flashes Yellow when a still photo is taken... -
Page 5: Audio Recording
1.4 Taking a Photo In preview mode, press the photo button once to take a photo; hold the photo button to take more than one photo continuously (Burst shooting). The photo icon will flash every time a photo is taken and it will be saved as a .Jpeg. 1.5 Recording a Video In preview mode, press the video button to begin recording video, the status light will... - Page 6 1.9 Playback on Camera In preview mode, press the playback button to enter playback mode. Icons indicating video, photos, and audio will appear as shown below. Use the video button to move your selection to the left, use the photo button to move to the right. Select an option using the playback button and go backwards or return to preview mode with the sound button.
- Page 7 Connect a mini-HDMI to HDMI cable to your camera to display your video playback on a HDMI compatible screen such as an HD TV or a computer monitor. 1.12 Camera Settings From preview mode press the multi-function button to bring up the camera’s settings menu.
- Page 8 on the body cam IR Sensitivity: Adjust the sensitivity of the auto IR sensor for detecting when to switch on IR. 2.1 Charging the Battery The Blueline Body Camera has a built-in rechargeable battery. It can be charged via the USB connection.
- Page 9 Installing Body Worn Camera Tool (for pc) 3.2 Operating Systems The Body Worn Camera Tool (BWC) is compatible with Windows 2000 SP4/ Windows XP SP2/ Windows Vista/ Windows 7 (32-bit version)/ Windows 7 (64-bit version)/ Windows 8/ Windows 10. 3.3 Installing Software The Blueline Body Camera includes a CD-ROM which contains the BWC Tool software.
- Page 10 From the main screen you have 3 tabs, operation, media data, and System...
- Page 11 4.2 Operations THE DEFAULT DEVICE PASSWORD TO ENTER ANY OF THE OPERATION MODES IS 000000 From the Operation tab You can log into the camera in three modes Data Import, Parameter Setting, or Movable Disk. Data input is for a quick bulk file import of all the files on the camera to the location selected under options.
- Page 13 You will have access to following settings: Video Resolution: Adjust the frame size and frame rate of video Auto IR: Select manual for IR light to be triggered by button press on/off Select Auto for the camera to turn on IR automatically when camera senses low light Watermark: If turned on recorded video will have a time/date, camera id and user id stamped onto the video.
- Page 14 You will also be able to change the camera’s password and set up user information for the camera. Removable Disk Mode Once this camera is set as a removable disk, it can be viewed in “my computer” as a removable drive, much like any USB storage device. Browse the files and folders, will find...
- Page 15 4.3 Media Data THE DEFAULT PASSWORD TO ENTER MEDIA DATA IS 110801 The Media data tab allows you to sort through files in the import folder on your computer. It is mostly for users who have multiple body cameras or cameras with many users to manage. You can search by date, user number, user name, device number, import date, or record date.
- Page 16 4.4 System The System tab will allow you to change the password and change the destination for imported files saved...
- Page 17 THE DEFAULT PASSWORD TO ENTER SYSTEM IS 110801...
- Page 18 Zetronix Corporation (“Zetronix”) warrants this product against defects in material or workmanship as follows: PRODUCT: Zetronix will repair this product with new or refurbished parts, free of charge, for a period of one (1) year from the date of original purchase in the event of a defect in materials or workmanship. REPAIRS: Zetronix will repair...
