FISCHER AMPS
MANUAL
2
DRUM IN EAR AMP
Dear customer:
You have decided to buy a FISCHER AMPS product. Thank you.
Please read this manual carefully prior to the first use. These safety and operating instructions
should be retained for future reference.
Should you have further questions, please do not hesitate to contact FISCHER AMPS.
Product Description:
The Drum In Ear Amp 2 has been developed for supplying in ear systems of drummers. Most drummers
need additional bass support to get the feeling for the beat of the bass drum while using in ear monitoring.
Using a bass shaker which is mounted to the drummer seat allows to feel the bass without noise. The
Drum In Ear Amp 2 in combination with the corresponding bass shaker is a low-cost monitoring solution for
drummers with high demands. The supplied mounting bracket allow direct fastening to the drum set for
convenient control.
Basic information on the use of in-ear monitoring systems:
Caution:
Using this system at too high sound levels may cause permanent hearing defects. Adjust the
volume so that you can hear sufficiently. Ringing in the ears can indicate that the adjusted
hearing level is too high. Use headphone systems with good fitting which suppress the
ambient noise well. This allows that the required listening volume can be low which is kind to
your ears.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DRUM IN EAR AMP 2 and is the answer not in the manual?

Questions and answers

Summary of Contents for FISCHER DRUM IN EAR AMP 2

  • Page 1 Product Description: The Drum In Ear Amp 2 has been developed for supplying in ear systems of drummers. Most drummers need additional bass support to get the feeling for the beat of the bass drum while using in ear monitoring.
  • Page 2 Controls at the Front Description of the Actuators (front side): Channel 1/2 Volume control: Preset of volume for channel 1 and 2 Channel 1/2 Pan (Balance) Control In stereo mode: Adjust balance of volume between channel 1 and 2 channel 1 (left), channel 2 (right) In mono-mix mode: Adjust volume level ratio between channel 1 and channel 2.
  • Page 3 Channel 3/4 Volume control: Presetting of volume for channel 3 and 4 Channel 3/4 Pan (balance) control In stereo mode: Adjust balance of volume between channel 3 and 4 Channel 3 (left), channel 4 (right) In mono mix mode: Adjust volume level ratio between channel 3 and channel 4. Channels 3 and 4 are output to both earphones.
  • Page 4 Actuators at the Back Side Description of the actuators (back side): (1 / 2) Combined XLR/Jack Inputs Channel 1 (left) Connections for the input signals from the mixing console. Channel 2 (right) Assignment of the combined XLR/jack female connection: 1 = Ground = Sleeve 2 = Signal + = Tip 3 = Signal - = Ring...
  • Page 5 Shaker Output Jack/Speakon 1+/1- Connection for the bass shaker or the ButtKicker LFE. Max. RMS output power 65W with Low Power , and 250W in High Power mode; minimum output impedance 4 ohms. In High Power mode, only use the Speakon connection because of the strain on the plug-in system.
  • Page 6 Adjustment of the optimum working level: When all required connections are made and the Drum In Ear Amp 2 is switched on, make sure that the input signals have contact with the Drum In Ear Amp 2. Turn channel 1-2 volume control until the green and yellow signal LEDs light.
  • Page 7 WARRANTY: The manufacturer grants a warranty of 24 months from the date of purchase by the original owner for defects in materials or workmanship. When the appliance has been subject to misuse or has been altered, the warranty expires. When returning the defective unit, enclose the receipt, pack the unit to avoid transit damage, and return the unit carriage prepaid.
  • Page 8 2.5 AT with 115V mains voltage SPECIFICATIONS BASS SHAKER: Nominal impedance: 4 Ohm Maximum power: 50 W RMS (Bass Pump 3) 400W RMS (ButtKicker LFE) FISCHER AMPS Hans-Ulrich-Breymann-Str. 3, DE-74706 Osterburken / Germany Tel. +49 (0)6291–648 79-0, Fax 648 79-19 E-MAIL: , Internet: info@fischer-amps.de www.fischer-amps.de...
