Summary of Contents for SAE 8300
- Page 3 SAFETY INSTRUCTIONS Read all the safety and operating instructions before connection or using the SAE 8300. All warnings on the unit and in this operating manual should be adhered to. • All operating instructions should be followed. • Do not place/use the unit near water; for example, near a bathtub, washbowl/sink, •...
- Page 4 In the unlikely event that you have to return your 8300 to the factory or dealer for service or updating, the original packaging will best protect the unit from shipping damage.
- Page 5 CONGRATULATIONS. You have just acquired one of the most advanced audio components ever developed. Your SAE 8300 8-channel amplifier was designed to set new standards in virtually every perfor- mance category. Each channel uses a dual-differential balanced design with a 4-quadrant input stage to nudge the...
-
Page 6: Table Of Contents
INTRODUCTION Getting to know your SAE 8300 This SAE 8300 amplifier has been put through a rigorous and unique testing procedure that ensures that it will last for many years with minimal service requirements. This procedure includes the following: •... -
Page 7: Front Panel Layout
Front Panel Layout 1. ILLUMINATED LOGO. Illuminates when the amplifier exits the STANDBY Mode. 2. STANDBY SWITCH. After the rear panel MAIN POWER switch(es) are turned on, touch the front panel button to exit the standby mode and enter the operational mode. Press again to return to STANDBY. 2 ... -
Page 8: Rear Panel Layout
7. FAN OUTLET. Forced air used for cooling exits the amplifier here. 8. VOLTAGE INDICATORS The 8300 amplifier is equipped with circuitry that automatically detects the AC voltage and sets the amplifier appropriately. These indicators show the discovered voltage. 120VAC is shown for line voltage of 100 to 130V;... -
Page 9: Operation
Connect the amplifier’s output to the input of the speaker that is intended to be driven. Please refer to figure 5. Connect a 12V trigger source to the STANDBY trigger input of the 8300 using a cable with a 3.5 mm monophonic plug to enable remote turn-on and turn-off. -
Page 10: Appendix A Troubleshooting Guide
Appendix A Troubleshooting Guide If the 8300 should function abnormally during operation, please review the items in the following checklist. Please be sure to thoroughly check all other connected components such as speakers and preamplifiers, as well as cables. If the problem persists, please consult your dealer or distributor. -
Page 11: Appendix B Specifications
Appendix B Specifications Analog Audio Inputs One Balanced (XLR) jack per channel Input Impedance 47 kΩ. Balanced for each phase Input Sensitivity 2.82V RMS input for 300W into 8 ohms Gain 27.8 dB Polarity Balanced; Pin-2 = Positive, Pin-3 = Negative for Non-Inverting Output Speaker Outputs Binding posts 2 per channel Modes /Process... -
Page 12: Warranty
SAE factory service facility. SAE shall not be held liable for incidental or consequential damages of any kind arising from the sale or use of its prod- ucts. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
