- Page 1 4-731-821-11(1) Television Reference Guide KDL-49W800F / 43W800F...
-
Page 2: Table Of Contents
Introduction Table of Contents Thank you for choosing this Sony product. Before operating the TV, please read this manual thoroughly and retain it for future reference. Note • Before operating the TV, please read the “Safety Information” (page 3). • Instructions about “Installing the TV to the Wall” are included within this TV’s instruction manual. -
Page 3: Safety Information
• For safety reasons, it is strongly recommended that you use Safety Information Sony accessories, including: Wall-Mount Bracket SU-WL450 WARNING • Be sure to use the screws supplied with the Wall-Mount Bracket when attaching the Wall-Mount Bracket to the TV set. - Page 4 AC power outlet (mains socket). Use only Sony supplied AC power cords (mains lead), not those Disconnect the TV set from AC power outlet (mains socket) and antenna (aerial) during lightning storms.
-
Page 5: Precautions
Optional Equipment immediately if any of the following problems occur. Keep optional components or any equipment emitting Ask your dealer or Sony service centre to have it checked by electromagnetic radiation away from the TV set. Otherwise qualified service personnel. - Page 6 You may contact our company’s toll free number in India for assistance. Toll Free: 1800-103-7799 Visit: www.sony.co.in for product recycling Reduction in the Use of Hazardous Substances in Electrical & Electronic Equipment (Applicable in Republic of India)
-
Page 7: Parts And Controls
Parts and Controls Controls and Indicators (Power) /+/- When the TV is off, Press to power on. When the TV is on, Press and hold to power off. Press repeatedly to change the function, then press + or – button to: •... -
Page 8: Using Remote Control
Using Remote Control Remote Control Parts Description The remote control shape, location, availability and function of remote control buttons may vary depending on your region/country/TV model. (Microphone) Use Voice Search. (e.g., Search various content by voice.) EXT.BOX MENU Display the connected External Box (cable/satellite box) menu. - Page 9 ACTION MENU Display a list of contextual functions. GUIDE/ Display the digital programme guide. APPS Access various services and applications. BACK Return to the previous screen. HOME Display the TV Home Menu. +/– (Volume) Adjust the volume. (Jump) Jump back and forth between two channels or inputs.
-
Page 10: Connection Diagram
Connection Diagram For more information on connections, refer to the Help Guide by pressing HELP on the remote control. Audio Headphone/ System with Audio Optical System/ Audio Input Subwoofer HDMI Device Digital still camera/ Camcorder/USB storage media HDMI Device Audio System with ARC/HDMI Device <... - Page 11 • When connecting a large USB device, connect to the USB 1 port. IR BLASTER* • Use your Sony remote control to control your External Box (cable/satellite box). Connect the IR Blaster Cable* to the IR Blaster port on your TV. Place one or both of the other two ends as shown below.
-
Page 12: Installing The Tv To The Wall
Sufficient expertise is required for installing this product, especially to determine the strength of the wall for withstanding the TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper installation. - Page 13 Make sure that the wall has enough space for the TV and is capable of supporting a weight of at least four times that of the TV. Refer to the following table on installing the TV to the wall. See page 17-18 (Specifications) for the TV’s weight.
- Page 14 Attach the Attachment parts for Wall-Mount Bracket. Check the Attachment parts by referring to “1” of the Wall-Mount Bracket Installation Guide. Note • If using an electric screwdriver, set the torque at approximately 1.5 N·m {15 kgf·cm}. • Be sure to store the unused parts in a safe place for future use. Retain this manual for future reference. Standard mounting ...
- Page 15 Screw (+PSW 6 x 20) Screw (+PSW 6 x 20) Pulley Spacer (20 mm) Soft cloth Belt Connect necessary cables to the TV. Note • You cannot access to any terminal after installing the TV to the wall. Install the TV to the Base.
-
Page 16: Troubleshooting
Refer to the Help menu by pressing HELP on If the problem persists, disconnect the AC power the remote control. cord (mains lead), and contact your dealer or Sony Connect your TV to the Internet and perform service centre with the number of times the illumination LED flashes. -
Page 17: Specifications
USB port 1 and 2 support High Speed USB Specifications (USB2.0). USB port 3 supports Super Speed USB (USB 3.1 System Gen 1) Panel system LCD (Liquid Crystal Display) Panel, LED Backlight 10BASE-T/100BASE-TX connector (Depending on the operating environment of the network, TV system connection speed may differ. -
Page 18: Trademark Information
DVB-T/DVB-T2 (MPEG-2 and H.264/MPEG-4 Bluetooth SIG, Inc. and any use of such AVC) digital terrestrial signals are marks by Sony Corporation is under broadcast. Please confirm with your local license. Other trademarks and trade names dealer if you can receive a DVB-T/DVB-T2 are those of their respective owners. - Page 20 Help Guide http://rd1.sony.net/help/tv/fga1/h_ga/ Customer Support and Contact: © 2018 Sony Visual Products Inc.
