OPERATING AND
Systematic ventilation.
4
COMFORT
VENTILATION
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pichler PKOM4 Classic
Summary of Contents for Pichler PKOM4 Classic
- Page 1 OPERATING AND INSTALLATION INSTRUCTIONS SYSTEM VENTECH PKOM COMFORT VENTILATION 250 m 1.300 Watt 1.300 Watt 4 persons PKOM .S/F -80% -60% -40% -20% 1112 kWh/annum 1112 kWh/annum 1112 kWh/annum 2015 812/2013 Systematic ventilation.
- Page 2 Karlweg 5, Postfach 32 +43 (0)463 32769 Changes reserved: J.Pichler GmbH reserves the right without prior notice to change details and specifications of the unit in the interest of ongoing development. In the light of possible setting and printing errors but also in view of the need for ongoing technical changes, please understand...
-
Page 3: Table Of Contents
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 3 Contents GENERAL 1. Introduction Page 6 1.1 CUSTOMER SERVICE PAGE 6 2. -
Page 4: O P Erat In G An D Insta Ll At Ion I N Str Ucti On S Syst E M V E N Te C H Pko M
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 4 SPECIALIST 12. Scope of supply, transport, storage and disposal Page 21 12.1 SCOPE OF SUPPLY PAGE 21 12.2 TRANSPORT AND PACKAGING... - Page 5 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 5 18. Electrical connection Page 29 18.1 ELECTRICAL CONNECTION DIAGRAM PKOM (LEFT VERSION) MAIN PCB &...
-
Page 6: Introduction
1.1 CUSTOMER SERVICE Please contact the installer of your ventilation and air conditioning system or contact us directly for any questions J. Pichler Gesellschaft m.b.H. pertaining to the supplied heat pump 9021 KLAGENFURT combi unit PKOM System VENTECH. Karlweg 5, Postfach 32 +43 (0)463 32769 2. -
Page 7: Designated Use
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 7 3. Designated use 3.1 PURPOSE The System Ventech PKOM type heat Designated use shall also include servi- pump combi unit is intended for in- cing as prescribed in the Operating and... -
Page 8: Requirements For Operation With Fireplaces
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 8 3.2 REQUIREMENTS FOR OPERATION The safety regulations and of similar size containing fireplaces WITH FIREPLACES standards must be heeded drawing in room air provided... -
Page 9: Warranty
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 9 4. Warranty Our General Terms and Conditions shall In the event of a warranty claim, the PKOM strictly apply. -
Page 10: Setting Up The Unit
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 10 5.1 SETTING UP THE UNIT Regulations: All national and local regula- tions must be complied with when installing and setting up the unit. -
Page 11: Safety During Operation
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 11 5.3 SAFETY DURING OPERATION To guarantee safe plant operation, Spare parts: safety devices and covers may must Attaching or installing additional com- remain functional and may not be by-... -
Page 12: Product Description
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 12 6. Product description One device, 4 benefits: dity. To prevent overly high summer Ventilating –... -
Page 13: Functional Diagrams
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 13 7. Functional diagrams 7.1 PKOM CLASSIC Outdoor air / ODA Extract air / ETH Exhaust air / EHH Supply air / SUP... -
Page 14: View Of Unit
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 14 8. View of unit Filter inspection flap 735 mm 735 mm 741 mm 741 mm 9. - Page 15 Item Item number Extract air filter M5 synthetic 40LG050280 Outside air filter F7 glass fibre 40LG050290 3. Then remove the dirty filter. J. Pichler Gesellschaft m.b.H. 9021 KLAGENFURT Karlweg 5, Postfach 32 +43 (0)463 32769 filter@pichlerluft.at Changes reserved...
-
Page 16: Control Unit
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 16 10. Control unit PKOM heat pump combi unit operation is simple and clear via a TFT touch dis- play. - Page 17 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 17 2 – CURRENT OPERATING MODE (DIS- Press the button to change Vacation: PLAY = CURRENT OPERATING MODE) The heat pump will heat in this operating...
- Page 18 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 18 4 – ROOM TEMPERATURE The room temperature may be (DISPLAY = CURRENTLY MEASURED adjusted quickly by pressing ROOM TEMPERATURE) this button.
- Page 19 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 19 1 – INFORMATION This sub-menu contains all the Energy balance: Information on the electrical energy con- relevant information for opera- tion of the heat pump unit.
- Page 20 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 20 d) Cooling: f) Additional function: • Enabling cooling: Cooling by the heat •...
-
Page 21: Scope Of Supply, Transport, Storage And Disposal
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 21 12. Scope of supply, transport, storage and disposal 12.1 SCOPE OF SUPPLY The SYSTEM VENTECH PKOM trend scope On delivery of the unit, please check that... -
Page 22: Transport And Packaging
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 22 12.2 TRANSPORT AND PACKAGING The PKOM heat pump combi unit Applicable safety and accident regulati- is delivered on a pallet with transport ons must be complied with during trans-... -
Page 23: Layout Sketch
O PERATI NG A N D I NSTALL ATION I NSTRU CTI ON S SYST EM VEN TECH PKO M PAG E 2 3 13. Layout sketch 13.1 PKOM CLASSIC (RIGHT-HANDED VERSION) 13.2 PKOM TREND (RIGHT-HANDED VERSION) 1 Supply air 2 Extract air 3 Outdoor air 4 Exhaust air... -
Page 24: Dimensions
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 24 14. Dimensions 14.1 PKOM CLASSIC Illustration: PKOM classic (right-handed version) 14.2 PKOM TREND Illustration: PKOM... -
Page 25: Protecting The Counterflow Heat Exchanger From Freezing
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 25 15. Protecting the counterflow heat exchanger from freezing Medium to serious frost will in win- Minimum fresh air temperature for ter pose a danger of freezing in the apparatus type S (standard heat... -
Page 26: System Extension With Auxiliary Heating
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 26 16. System extension with auxiliary heating The heat pump combi unit will already provide a passive house with a large part of its required heating and cooling power. -
Page 27: Heating Circuit Module
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 27 16.2 HEATING CIRCUIT MODULE The heating circuit module allows towel dryer, etc.) delivering up to connection of the PKOM classic 500W heating power. -
Page 28: Demand-Driven Air Volume Control
O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 28 17. Demand-driven air volume control The air volume flow may be eit- her manually set or controlled by a timer –... - Page 29 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 29 18. Electrical connection The heat pump combi unit System VEN- The electrical connection work TECH PKOM is designed for a voltage...
- Page 30 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 30 18.1 ELECTRICAL CONNECTION DIAGRAM PKOM (LEFT VERSION) MAIN PCB & VENTILATION PCB Changes reserved...
- Page 31 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 31 18.2 ELECTRICAL CONNECTION DIAGRAM PKOM (RIGHT VERSION) MAIN PCB & VENTILATION PCB Changes reserved...
- Page 32 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 32 18.3 ELECTRICAL CONNECTION DIAGRAM PKOM HEAT PUMP PCB Changes reserved...
- Page 33 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 33 19. Servicing and Cleaning Always switch off the appa- force or using compressed air for cleaning may damage components ratus for cleaning and maintenance of the heat...
- Page 34 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 34 19.2 CHECKING AND CLEANING THE Soiling of the counterflow heat •...
- Page 35 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 35 19.3 CHECKING AND CLEANING THE • Use only lukewarm water to clean HEAT EXCHANGER AND CONDENSA- the supply air and exhaust air TE TRAYS...
- Page 36 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 36 19.5 INSPECTION OF THE HEAT Refrigerant circulation of the heat functionality of the apparatus in the PUMP CIRCUIT pumps is basically maintenance-...
- Page 37 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 37 20. List of parameters PARAMETER UNIT WORKS COMMENT 0 = Off 1 = Summer A01 Operating mode 2 = Winter...
- Page 38 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 38 Min. storage temperature, Heating °C circuit enabled V03 Heating circuit hysteresis V04 Set-point, heating circuit °C V05 Solar hysteresis...
- Page 39 Changes reserved Responsible for the content: J. Pichler Gesellschaft m.b.H. Photos: Archiv J. Pichler Gesellschaft m.b.H. | Text: J. Pichler Gesellschaft m.b.H. All rights reserved | All photos are symbolic photos | Subject to change without notice | Version: 03/2016...
- Page 40 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 40 22. Technical specifications 22.1 VENTILATION PART WITH HEAT PUMP PKOM classic PKOM trend...
- Page 41 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 41 23. EC Declaration of Conformity Hersteller / Manufacturer: J. Pichler Gesellschaft m.b.H. Anschrift / Address: Karlweg 5 , 9021 Klagenfurt am Wörthersee Bezeichnung / Product description:...
- Page 42 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 42 Notes...
- Page 43 O P ERAT IN G AN D INSTA LL AT ION I N STR UCTI ON S SYST E M V E N TE C H PKO M PAGE 43 Notes...
- Page 44 PASSIVHAUS Responsible for the content: J. Pichler Gesellschaft m.b.H. Photos: Archiv J. Pichler Gesellschaft m.b.H. | Text: J. Pichler Gesellschaft m.b.H. TIROL All rights reserved | All photos are symbolic photos | Subject to change without notice Version: 11/2017 db/kp Netzwerk für Information,...
