OC1135 Programmable Multifunction Counter
6

SPECIFICATIONS

DISPLAY:
INPUTS:
OUTPUTS:
PRESET:
SCALE:
SAMPLING TIME:
RTESOLUTION:
FILTER:
SUPPLY:
CABINET:
TERMINALS:
7 PRESET and RESET
Programmed as a Quadrature counter quAd or Up/Down Counter Udic the Preset can be entered into
the display forcing the display to start counting at this value. The selected value in the menu Step PrESE
can be inserted into the display with the key SET or with external control signal at the input Z. By
selecting 00000 the display will reset to Zero.
Operator's Manual
0 ... ± 99999, red, 7 segments, 8 mm.
Inputs A, B, Z:
Frequency Range:
Quadrature Counter: Inputs A and B, Reset Input Z. The counting direction is
automatically determined bat he phase shift between signals A and B.
The display increments with each signal edge A and B.
UP-DOWN Counter: Input A:
Tachometer:
Set Point SP1 and SP2, two isolated open collector outputs (Optocoupler Type
PC357). Maximum switching values: 35V and 30mA. The both emitters are
internally tied to the (-) terminal of the supply.
Additive display constant programmable from 0 to ± 9.9.9.9.9. The Preset can be
entered into the display with the key SET or with external log. Signal at the
terminal Z. When the value is set to Zero, the display will reset to 00000.
SCALE: 5 digit multiplicative constant with decimal point and sign
dSCALE: Dividing constant selectable from :1 to :99999.
FbASE: Measuring Time (Tacho-Frequency measurements) programmable from
OFF, 0.22 to 120 Sec.
ObASE: Reset Time (Tacho-Frequency measurements) programmable from
OFF, 0.22 to 120 Sec.
OrdEr: Selection of the display resolution, decimal point of the floating arithmetic.
FILtER: Average Filter with programmable constants OFF, 1 ... 99.
24VDC ± 10%, 2W. Option: 9 - 36 V DC, 3 W.
DIN 24x48 mm, depth behind the front is 65 mm. Panel cut-out 21x42 mm.
Pluggable screw terminals.
Positive logic 5V CMOS, protected to 28V.
0 ...100 kHz.
Pulses to be counted
Input B: Counting direction UP (log. 0 or open)
Counting direction DOWN (log.1)
Frequency measurement from 0.01 Hz to 100 kHz
Accuracy: 0.05% from value
