01
Technical Manual
Star Pergola 120x70
Exclusively designed by METAFORM AVEE, this is
the ideal solu on for covering professional spaces
with a large area and featuring unique elements.
Retractable, 100% manufactured from aluminium,
with the motor that provides mo on to the axle
being incorporated within the axle with no
addi onal parts.
metaform
shading systems
Advertisement
Summary of Contents for Metafor Star Pergola 120x7
- Page 1 Technical Manual Star Pergola 120x70 Exclusively designed by METAFORM AVEE, this is the ideal solu on for covering professional spaces with a large area and featuring unique elements. Retractable, 100% manufactured from aluminium, with the motor that provides mo on to the axle being incorporated within the axle with no addi onal parts.
- Page 3 Star Pergola 120x70 Contents General image of Star 120x70 pergola Profile cross-sections Pergola dimensions (max axis - max overhang) Support choices (Wall/Roof) Details of parapet pergola support Motion transmission (motor) General information on pergola installation Custom applications Lighting system/installation instructions...
- Page 5 Star General view of the pergola metaform shading systems...
- Page 6 Star Profile cross-sec ons 70 mm 38 mm 90 mm 90 mm guide broad counterweight, bo om broad counterweight narrow counterweigh 100 mm 100 mm axis gu er parapet gu er parapet column (not shown in diagram) metaform shading systems...
- Page 7 Star Maximum pergola overhang & maximum rail distance 2 rails 3 rails 4 rails The Star pergola with a 120x70 rail can reach an overhang of up to 6 metres and an axis of up to 20 metres with six rails.
- Page 8 Star Pergola support op ons Α Β wall base roof base 56 mm 52 mm metaform shading systems...
- Page 9 Star Details of the connec on of a parapet pergola Details of rail-parapet connec on Details of parapet column and extrac on of rainwater 1 cm 20 cm 12 cm Α-1 Β-1 Α Β 20 cm 12 cm Α-2 Β-2 15 cm 20 cm Α-3...
- Page 10 Star Mo on transmission motor 7 cm Motor cover detail s transmi ed in the Star pergola by a tubular motor. For pergolas with large areas and special requirements, two tubular motors can be installed. metaform shading systems...
- Page 11 Star General informa on on pergola installa on Star Pergola 120X70 Β Overhang Distance of Retracted Counterweights Gradient Depth 32,5 43,25 42,00 45,5 41,17 45,33 58,5 44,14 43,25 71,5 42,56 42,00 Measurements are in cen meters metaform shading systems...
- Page 12 Star Special pergola applica ons metaform shading systems...
- Page 13 Star ligh ng system / installa on instruc ons metaform shading systems...
- Page 14 Star ligh ng system / installa on instruc ons metaform shading systems...
- Page 15 Star ligh ng system / installa on instruc ons metaform shading systems...
- Page 20 Star Pergola 120Χ70 Metaform S.A Shading systems 18th km of Thessaloniki - Kavala Road PO Box 81, 57200 Langadas Tel. No: 23940 20300 Fax No: 23940 20300 e-mail: mf@metaform.gr website: www.metaform.gr metaform ligh ng systems...
