MING JONG M6820 User Manual

Wireless/wired mpeg-4 pan & tilt surveillance camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Wireless/Wired MPEG-4 Pan & Tilt
Surveillance Camera
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M6820 and is the answer not in the manual?

Questions and answers

Summary of Contents for MING JONG M6820

  • Page 1 Wireless/Wired MPEG-4 Pan & Tilt Surveillance Camera User’s Guide...

  • Page 2: Table Of Contents

    Wireless/Wired MPEG-4 Pan & Tilt Surveillance Camera able of onTenTs 1. OVERVIEW 1.1 PRODUCT DESCRIPTION 1.2 PRODUCT FEATURE 1.3 PRODUCT SPECIFICATION 1.4 PRODUCT ACCESSORIES INCLUDE 1.5 SYSTEM REQUIREMENT 1.6 EXTERIOR FUNCTION INTRODUCE 1.7 PRODUCT SET-UP . UTILITIES AND TOOLS 2.1 IPCAMFINDER 2.2 USE IP-CAM AND TEST THE IMAGE FUNCTION FOR THE FIRST TIME 2.3 HOW TO SET UP IP CAM 2.4 SETTING THE WAY TO OBTAIN THE IP ADDRESS OF IP-CAM...

  • Page 3: Overview

    User’s Guide verview 1.1 PRODUCT DESCRIPTION This device is the most simple and effective IP Camera product for remote monitoring and management. The installation is easy and the built-in Web server allows users to carry out the work of remote monitoring and management through web browser (i.e., Microsoft IE) by typing IP address of the IP-Cam device.

  • Page 4: Product Accessories Include

    Wireless/Wired MPEG-4 Pan & Tilt Surveillance Camera • Storage temperture : -0˚C~55˚C • Humidity : 5 %~85% 1.4 PRODUCT ACCESSORIES INCLUDE 1.P-Camera 2.Power adaptor, 5V/ 2A Switching Power adaptor 3.Ethernet Cable(red), used to connect to the network card of PC for testing and configuring the product 4.Ethernet Cable (blue), used to connect to Hub, ADSL modem, IP Share 5.Setup CD 6.This User’s Guide...

  • Page 5: Exterior Function Introduce

    User’s Guide 1.6 Exterior Function introduce ※ Description for power-on After plugging DC5V/2A power adapter into the power socket, please wait for IP-CAM to finish motor homing. When the Status LED lights on, the initialization for the device will be done. ※...

  • Page 6: Utilities And Tools

    Wireless/Wired MPEG-4 Pan & Tilt Surveillance Camera TiliTies and Tools .1 IP SEARCH TOOL Search Tool is the IP search application provided by this product. It can search all the IP CAMs connected in LAN. Through sending out the inquiry of broadcasting packets and receiving responses from IP CAMs, the window will display a list of all IP CAMs in the network.

  • Page 7: Use Ip-Cam And Test The Image Function For The First Time

    User’s Guide 2.2 USE IP-CAM AND TEST THE IMAGE FUNCTION FOR THE FIRST TIME he following connection is suitable for IP-CAM test / DHCP& fixed IP&PPPoE setting / program code upgrade (strongly recommended): The operation steps are listed below: Installing the Product for the first time : •You computer must be equipped with network card and RJ-45 network connector.

  • Page 8: How To Set Up Ip Cam

    Wireless/Wired MPEG-4 Pan & Tilt Surveillance Camera .3 HOW TO SET UP IP CAM Before you set up IP CAM, you have to know the network environment and if the IP address is fixed or float that provided by your ISP. If you do not know, please contact with your ISP. Section 2.5 will list the common network structure (1 ~ 7 types).
  • Page 9 User’s Guide Example: 1.Set up the IP CAM with fixed IP address. 2.Turn on your computer and open IE browser. Type 211.78.174.94 in the Address line. Now you can access into the monitoring screen of network. .4. DHCP - IP Address Setting: •...
  • Page 10 Wireless/Wired MPEG-4 Pan & Tilt Surveillance Camera • Open and execute Search Tools (as below) The system will scan the IP-CAM that you just installed automatically. Then, you will find MP4_ IPCam 192.168.24.17 in the column of IP Cam List. (as shown in Figure 5) Step 1.
  • Page 11 User’s Guide Example : 1. IP-CAM had been installed on to Hub in LAN (also the PC has been installed here). Refer to 2.5 (the sixth network framework) 2. Turn on your PC and open any browser for typing DDNS website, such as...

  • Page 12: Ip-Cam Network Framework Installation

    Wireless/Wired MPEG-4 Pan & Tilt Surveillance Camera .5 IP-CAM NETWORK FRAMEWORK INSTALLATION I. IP-CAM Network Framework Installation 1 Way to access Internet Use Permanent ADSL or Cable Modem Physical IP Address Owns several physical IP addresses IP Share or LAN Hub General model is OK Network Setup for IP -CAM LAN Enable / Manually...
  • Page 13 User’s Guide II. IP-CAM Network Framework Installation 2 Way to access Internet Use Permanent ADSL or Cable Modem Physical IP Address Owns one physical IP address IP Share or LAN Hub Must be equipped with DHCP & NAT function Network Setup for IP -CAM LAN Enable / Manually Web Server Port Number, need to be adjusted Users with one physical fixed IP addresses, IP Share and several IP- Suitable Objects...
  • Page 14 Wireless/Wired MPEG-4 Pan & Tilt Surveillance Camera III. IP-CAM Network Framework Installation 3 Way to access Internet Use dial-up ADSL or Cable Modem Physical IP Address Owns one float IP address (dispatched by ISP dynamically) IP Share or LAN Hub Must be equipped with DHCP and NAT functions Network Setup for IP -CAM LAN Enable / Manually Web Server Port Number, need to be adjusted...
  • Page 15 User’s Guide IIII. IP-CAM Network Framework Installation 4 Way to access Internet Use Permanent ADSL or Cable Modem Physical IP Address Owns one physical IP address IP Share or LAN Hub Not necessary LAN Enable / Manually Web Server Port Number, no need to be Network Setup for IP -CAM adjusted Users with permanent ADSL, one fixed physical IP address and one...
  • Page 16 Wireless/Wired MPEG-4 Pan & Tilt Surveillance Camera V. IP-CAM Network Framework Installation 5 Way to access Internet Use dial-up ADSL or Cable Modem Physical IP Address Owns one float IP address (dispatched by ISP dynamically) IP Share or LAN Hub Not necessary PPPoE function should be set, LAN Enable Web Server Port Number, Network Setup for IP -CAM...
  • Page 17 User’s Guide VI. IP-CAM Network Framework Installation 6 Way to access Internet Use dial-up ADSL or Cable Modem Physical IP Address Owns several float IP addresses(dispatched by ISP dynamically) IP Share or LAN Hub Must be equipped with DHCP and NAT functions Network Setup for IP -CAM LAN Enable / Manually Web Server Port Number, need to be adjusted Suitable Objects...
  • Page 18 Wireless/Wired MPEG-4 Pan & Tilt Surveillance Camera VII. IP-CAM Network Framework Installation 7 Way to access Internet Use Permanent ADSL or Cable Modem Physical IP Address Owns one physical IP address IP Share or LAN Hub Must be equipped with DHCP and NAT functions Network Setup for IP -CAM LAN Enable / Manually Web Server Port Number, need to be configured Suitable Objects...

  • Page 19: Installation For Ip Share

    User’s Guide .6 INSTALLATION FOR IP SHARE When IP-CAM is installed under IP Share, it can obtain a dynamic IP address from DHCP server. If you want to install the IP-CAM in WAN interface, you have to set a fixed IP address for the device. No matter whether your IP Share has the function of virtual server, it is necessary for IP-CAM to set a fixed IP address.

  • Page 20: Installation For Wireless Ip Share

    Wireless/Wired MPEG-4 Pan & Tilt Surveillance Camera (E) Three sets of virtual servers with the same IP address should be added with RTST Por: t554 Contorl Port:21 and HTTP Port:81. From the virtual servers list, the IP address for these three servers must be set with the same value.
