Sinopine N2 Instructional Manual

INSTRUCTION MANUAL
ALL-IN-ONE GSM Home Alarm – N2
Product diagram
1. Top Solar Panel
2.Night Vision Light
3.Camera
4.Indication Light
5.PIR detector
6.Microphone
7.Siren
8. Power Switch
(Left on / Right off )
9.Power Interface
10. Indication Light
11.SD Card Slot
12.USB interface
13.SIM Card slot
14.Learn Code
1. IR extender
2. Indication Light
3. Arm Button
4. Disarm Button
GSM Function Setup
A:Set up GSM alarm ,below notice :
1. Pls make sure SIM Card connect with GSM network, When
Indication Light flashing 3times every 2.5Seconds means SIM
card connect successful.
2. Setup alarm parameters by sending SMS message to phone
number of the SIM Card in the alarm.
3. SMS message start with Password. the default Password
258000 , if you change new password, SMS message should
start with new password.
4.If setup successfully, you will receive a message notification
from alarm SIM card.
B.Edit SMS Message for GSM Alarm Setting :
Password Setting :
1. :
SMS message "258000#01*6 digit new password# "
For Example, Set new password 123456 :
258000#01*123456#
Remark: default password:258000, if you set new
password 123456, all below sms setting message
should start with new password 123456, not 258000 .
2. GSM Alarm Timer Setting:
a. Alarm System Time Setup
SMS message "258000#03* time #
For Example, Set alarm current time 11:45
258000#03*1145#
(Time range:
0000~2359, hours 00~23 minute: 00~ 59)
b. Alarm Arm and Disarm Time Setup
SMS message "258000#05*arm time*disarm time # ".
For Example, if you want to arm on 20:30 ,and disarm on
08:30, sms message as below:
258000#05*2030*0830#
(Time range:
0000~2359, hours 00~23 minute: 00~ 59)
