Rittling RH-24 Installation Operation & Maintenance

General Information:

Installation and service instructions in this manual are
applicable to the steam/hot water unit heaters which should
be installed in their proper applications for their most
effective function as overhead heating units. The copper coils
are warranted for operation at steam or hot water pressures
up to 180 psig, and/or temperatures up to 360°F. National
Electric Code (NEC) or Canadian Electric Code (CEC)
ignition temperature rating T3B for grain dust.
DO NOT REMOVE OUTLET FAN GUARD FROM
MODEL RV UNITS.
Rittling Unit Heaters - Installation, Operation & Maintenance
For Steam or Hot Water
Installation, Operation & Maintenance
Inspection on Arrival:
1. Inspect unit upon arrival. In case of damage, report
immediately to transportation company and your local
Rittling Sales Representative.
2. Check rating plate on unit and motor to verify that power
input and motor specification meet available electric
power at point of installation.
3. Inspect unit received for conformance with description
of product ordered (including specifications where
applicable).
INSTALLER'S RESPONSIBILITY
Installer Please Note: This equipment has been test fired
and inspected. It has been shipped free from defects from
our factory. However, during shipment and installation,
problems such as loose wires, leaks, or loose fasteners
may occur. It is the Installer's responsibility to inspect
and correct any problems that may be found.
1
UNIT HEATERS
