KEC LSM64 Operating Instructions Manual

6.4" tft lcd television

Advertisement

Quick Links

"THIS PRODUCT HAS BEEN DESIGNED, MANUFACTURED
AND INSPECTED IN COMPLIANCE WITH THE ISO9001 QUALI-
TY ASSURANCE SYSTEM."
MOBILE
APPLICATIONS
6 . 4 " TFT LCD TELEVISION

OPERATING INSTRUCTIONS

PROFESSIONAL INSTALLATION ONLY
MODEL : LSM64
FOR RV-SPECIFIC DC-ONLY OPERATION
IMPORTANT NOTE :
WHEN USED IN A VEHICLE, THIS SYSTEM IS INTENDED PRIMARILY AS A MONITOR FOR A VIDEO
CASSETTE PLAYER, VIDEO GAME, OR CAMERA.
TELEVISION BROADCAST RECEPTION WILL BE ADVERSELY AFFECTED BY CONDITIONS SUCH AS
MOTION, CHANGE OF DIRECTION, ATMOSPHERIC ACTIVITY, AND LOCAL SURROUNDINGS.
IT IS THEREFORE LIKELY THAT BROADCAST PICTURE QUALITY WILL BE MARGINAL WHEN THIS
SYSTEM IS USED IN A MOBILE ENVIRONMENT.
PLEASE READ THIS ENTIRE OWNER'S
MANUAL BEFORE USING THIS LCD TV.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSM64 and is the answer not in the manual?

Questions and answers

Summary of Contents for KEC LSM64

  • Page 1: Operating Instructions

    APPLICATIONS Ⓡ 6 . 4 " TFT LCD TELEVISION OPERATING INSTRUCTIONS PROFESSIONAL INSTALLATION ONLY MODEL : LSM64 FOR RV-SPECIFIC DC-ONLY OPERATION PLEASE READ THIS ENTIRE OWNER’S MANUAL BEFORE USING THIS LCD TV. IMPORTANT NOTE : WHEN USED IN A VEHICLE, THIS SYSTEM IS INTENDED PRIMARILY AS A MONITOR FOR A VIDEO "THIS PRODUCT HAS BEEN DESIGNED, MANUFACTURED...
  • Page 2: Cautions

    CAUTIONS I M P O RTANT SAFEGUARDS 1 . Read Instructions-All the safety and operating instructions should be read before the appliance CAUTION : is operated. ・ANY CHANGES OR MODIFICATIONS IN CONSTRUCTION OF THIS DEVICE WHICH ARE NOT 2. Retain Instructions-The safety and operating instructions should be retained for future refer- EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE e n c e .
  • Page 3: Table Of Contents

    We strongly recommend that you carefully read all of the descriptions and operation procedures con- service personnel under the following conditions: tained in this Owner's Manual prior to operating your new LSM64. a. When the power-supply cord or plug is damaged.
  • Page 4: Features

    A/V and External Speaker Out, External Antenna Input, Ready for CAR Set Up Memory Back Up (10 Years) Extension Cable for KEC Mobile Application VCP The Remote Controller that is packaged with this unit will also control any KEC Mobile Applications VCP N O T E S : Automatic Power Off Function: This System will automatically turn off approximately 15 minutes after it last receives a video signal.
  • Page 5: Remote Control

    (Contrast, Brightness, Sharpness, Color, Tint). 14. SLEEP BUTTON Sets the TV to automatically power off in 15-180 minutes. 15. CONTROL BUTTONS FOR VCP These 8 buttons will control KEC Mobile Applications Video Cassette Players. WARRANTY CARD OWNERS MANUAL 16. BATTERY COVER...
  • Page 6: Remote Control Use

    REMOTE CONTROL USE SIGNAL CONNECTION •Connect the antenna lead to the ANTENNA Input terminal of the TV set. VHF/UHF 75-ohm ANTENNA Coaxial Cable EXT.Speaker (4 ohm) VIDEO GAME or VCP or DVD etc. <A/V 2 INPUTS> <A/V OUTS> Remote control Mobile Applications Sensor...
  • Page 7: Power Connection

    AUDIO SYSTEM Red, Brown, White and Leads These leads provide power for the dome light circuit. The LSM64 is configured to be •Audio output is Monophonic when receiving on-air broadcast signals. used with vehicles that use a “negative” type door dircuit. However, the LSM64 can be •Audio output is Stereo when a stereo audio signal is fed from external audio equipment that is con-...
  • Page 8: Set Up For Car Use

    SET UP FOR CAR USE TV OPERATION INITIAL PREPARATIONS 1. LCD TV ASSEMBLY • Insert batteries into the Remote Control unit by following the "REMOTE CONTROL USE" section in this manual. •Install LCD A ssembly with 4 screws. • Connect the DC Cord to 12-Volt Power by following the "POWER CONNECTION" section in this manual.
  • Page 9: Set Up Button

    SET UP BUTTO N SET UP BUTTON (1) AUTO PROGRAM On-Screen Display This function allows automatic memorization of all the active TV or Cable channels in your viewing • When the on-screen display appears on the screen, it will disappear after several seconds. area.
  • Page 10: Picture Button

    SET UP BUTTON PICTURE BUTTO N (3) FM MODE & FM FREQUENCY • The PICTURE button on the Remote Control selects the modes for picture adjustment. • Press the PICTURE button on the Remote Control • Fuction to be able to listen to audio signal captured by TV set with car radio through FM antenna •...
  • Page 11: Status Button

    S TATUS BUTTON MORE USEFUL FUNCTIONS (1) QUICK VIEW Button By pressing the STATUS button on the Remote Control, you can sequentially select any one of four possible preferred picture settings. Press the Q. VIEW button Q. VIEW on the Remote Control. •...
  • Page 12: Reception Disturbance

    MORE USEFUL FUNCTIONS RECEPTION DISTURBANCE The most common types of television interference are as follows : (4) MUTE Button Press the MUTE button on the Remote Control. The audio from the program being viewed will be reduced almost to zero IGNITION NOISE: and "VOLUME 0"...
  • Page 13: Troubleshooting Guide

    13 • If using antenna, check UHF antenna connections. N OTICE : If you need any information, please contact KEC/KTV directly at: N O T E: THE DEVICE DOES NOT FULLY COMPLY WITH THE FEDERAL COMMUNICATIONS Outside New Jersey : (800) 524-1216 From New Jersey : (973) 470-9191...
