RuggedCom RuggedMAX WiN7200 Installation Manual

Small form factor base station
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RuggedMAX™
WiN7200 Small Form
Factor Base Station
Installation Guide
Version 1.0 - June 18, 2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RuggedMAX WiN7200 and is the answer not in the manual?

Questions and answers

Summary of Contents for RuggedCom RuggedMAX WiN7200

  • Page 1 RuggedMAX™ WiN7200 Small Form Factor Base Station Installation Guide Version 1.0 - June 18, 2012...
  • Page 2 ROX™, RuggedRated™, eRSTP™, RuggedBackbone™ and RuggedMAX™ are trademarks of RuggedCom Inc. RuggedRouter® is a registered trademark of RuggedCom Inc. Other designations in this manual might be trademarks whose use by third parties for their own purposes would infringe the rights of the owner.

  • Page 3: Table Of Contents

    RuggedMAX™ WiN7200 Small Form Factor Base Station Table of Contents FCC Statement And Cautions ....................7 1. About This Guide ........................8 1.1. Safety Information ....................... 8 1.1.1. General ......................8 1.1.2. Equipment Installation ..................8 1.1.3. Radio Frequency (RF) Exposure ..............8 1.1.4.
  • Page 4 RuggedMAX™ WiN7200 Small Form Factor Base Station C. IDU to ODU Cable Specifications ..................34 D. Console Connector Specifications ..................36 E. WiN7200 Small Form Factor Base Station Base Station Mechanical Drawing ....37 F. Warranty ..........................38 RuggedMAX™ Installation Guide Rev 1.0...
  • Page 5 RuggedMAX™ WiN7200 Small Form Factor Base Station List of Figures 2.1. WiN7200 Small Form Factor Base Station ............... 11 2.2. Power Over Ethernet Block Diagram ................12 2.3. WiN7200 Small Form Factor Base Station Interface Panel ..........13 2.4. WiN7200 Small Form Factor Base Station Top Panel GPS Antenna ....... 14 4.1.
  • Page 6 RuggedMAX™ WiN7200 Small Form Factor Base Station List of Tables 2.1. WiN7200 Small Form Factor Base Station Interface Connectors ........13 4.1. ODU/IF Port Pinout ......................18 4.2. Data Adaptor LED Indicators .................... 25 A.1. List of Acronyms ....................... 31 C.1.

  • Page 7: Fcc Statement And Cautions

    This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void. Changes or modifications not expressly approved by RuggedCom Inc. could invalidate specifications, test results, and agency approvals, and void the user’s authority to operate the equipment.

  • Page 8: About This Guide

    1. About This Guide 1. About This Guide This user guide provides essential product functionality with all the information necessary to professionally install and configure the RuggedMAX™ WiN7200 Small Form Factor Base Station. This guide is intended for experienced technicians and operators. It is assumed that the customers installing, operating and maintaining this product are familiar with WiMAX technologies and procedures.

  • Page 9: Power Cord Protection

    Refer all repairs to qualified service personnel. Removing the covers or modifying any part of this device voids its warranty. RuggedCom does not endorse or support the use of proprietary third-party outdoor cable assemblies not supplied by RuggedCom .
  • Page 10 1. About This Guide To reduce the risk of fire, only use a No. 24AWG or larger telecommunication line cord between the indoor and outdoor units. RuggedMAX™ Installation Guide Rev 1.0...

  • Page 11: Introduction

    WiMAX coverage and capacity. The unit is easily installable by one person, is powered by Power over Ethernet (PoE), and supports remote management. The WiN7200 Small Form Factor Base Station is supported by RuggedCom’s RuggedNMS™ Network Management System software.

  • Page 12: Capabilities And Features

    2. Introduction 2.2. Capabilities and Features • All-outdoor, one-box base station solution. • GPS synchronization. • MIMO (2×2) support. • Non-Line-of-Sight (NLOS). • Small footprint and light weight enables simple installation and deployment by a single person. • IEEE802.16e Wave2 Standard Compliance. •...

  • Page 13: Interfaces

    2. Introduction 2.4. Interfaces Install the unit vertically, with the integrated GPS antenna located on the top panel (facing the sky). All other connections, including the optional GPS external antenna connections are located on the bottom panel. 2.4.1. Bottom Panel The interface panel supports the antenna, power and Ethernet connections.

  • Page 14: Top Panel

    2. Introduction 2.4.2. Top Panel The top panel supports the built-in GPS antenna. (An external GPS antenna can be connected to the bottom panel GPS connector). See Section 3.1.3, “External GPS Antenna Installation Location” for more information on GPS antennae and installation criteria. The figure below shows the base station mounted on a pole.

  • Page 15: Site And Installation Requirements

    3. Site and Installation Requirements 3. Site and Installation Requirements 3.1. WiN7200 Small Form Factor Base Station Installation Location The WiN7200 Small Form Factor Base Station unit must always be installed vertically and top#down – with the connectors on the underside for protection. This section describes the criteria that should be considered when selecting the WiN7200 Small Form Factor Base Station installation location.

  • Page 16: Installation Procedures

    Examine the shipping container for damage before unpacking the unit. Perform a visual inspection to reveal any physical damage to the equipment. Verify that all of the equipment (listed below) is included. Otherwise contact RuggedCom. The base station is shipped with the following equipment: •...

  • Page 17: Cover The Console Port

    4. Installation Procedures There are two types of installations: • Wall mount: The base station can be attached to any wall that can support the load of the unit. • Pole mount: The base station can be attached to any pipe or pole with a diameter of 1.75" to 10". To install the base station, follow these steps: 1.

  • Page 18: Preparing The Ethernet Cable

    4. Installation Procedures Figure 4.2. Preparing the Ethernet cable Form the braiding into two pigtails. The stripped cable should look like the figure below. Figure 4.3. View of stripped Ethernet cable Place the modular plug over the wire ends, being sure to maintain the color code. Refer to the following table for the ODU I/F connector pinout.

  • Page 19: Inserting The Cable Into The Plug

    4. Installation Procedures Figure 4.5. Inserting the cable into the plug Slide the plug housing up the cable and align the housing with the modular plug. Insert the modular plug into the plug housing and align the latch with the latch slot. Depress the latch (1) and insert the plug into the plug housing (2).

  • Page 20: Attaching The Mounting Bracket

    4. Installation Procedures Figure 4.8. PoE connector secured to base station 4.4.3. Attaching the Mounting Bracket Follow these steps to attach the mounting bracket to the base station. Figure 4.9. Wall Mounting Bracket Procedure 4.3. Assembling the Base Station and Mounting Bracket Align the mounting bracket’s four inner holes with the base station’s installation holes, located on the ribbed side of the unit.

  • Page 21: Mounting The Base Station: Wall Mount

    4. Installation Procedures Figure 4.10. Attaching the Mounting Bracket Secure the bracket to the base station unit with the four screws and washers (supplied). 4.4.4. Mounting the Base Station: Wall Mount The base station can be attached to any wall that can support the load of the unit. Plan the installation so that the interface connections face down, providing more protection against the elements.

  • Page 22: Mounting The Base Station: Pole Mount

    4. Installation Procedures Figure 4.11. Base Station and Wall Mounting Bracket: Rear View Drill four holes in the wall. If required, insert wall anchors (not supplied) in the wall. Align the bracket installation holes with the holes in the wall. Secure with the appropriate screws and washers (not supplied).

  • Page 23: Base Station And Pole Mounting Bracket

    4. Installation Procedures Figure 4.12. Base Station and Pole Mounting Bracket Mount the unit on the pole, using the metal bands. Close the bands tightly around the pole. RuggedMAX™ Installation Guide Rev 1.0...

  • Page 24: Antenna Connections

    4. Installation Procedures Figure 4.13. Base Station Pole Mounting: Rear View 4.4.6. Antenna Connections The part of the antenna that is connected to the central pin of the antenna connector should be covered by isolation material which is sufficiently resistant to degradation by ultraviolet (UV) radiation.

  • Page 25: Weatherproofing

    4. Installation Procedures The Data Adaptor unit includes a single output RJ-45 connector (for connection to an IEEE802.3 compatible device) that provides bi-directional 10/100 Base-T data and power to the outdoor equipment over a Cat5e cable. The unit receives power from 100V to 240V AC using an IEC-320-C14 industry standard connector.

  • Page 26: Hazardous Location Installation

    4.5. Hazardous Location Installation This equipment is suitable for use in Class 1, Division 2, Groups A, B, C, D hazardous locations only when installed using the Class 1, Division 2 installation kit (Ruggedcom P/N MKIT0090). Explosion Hazard! • Do not connect the WIN1010 power supply in hazardous locations.

  • Page 27: Connection Scheme

    4. Installation Procedures Connect a DC cable between the PSU and PoE injector. Figure 4.15. Connection Scheme Connect a Category 5e cable between the PoE injector (Data+Power jack) and the pBST. Connect a Category 5e cable between the Ethernet switch and the PoE injector (Data jack). Connect the AC open-ended cable to the PSU.

  • Page 28: Setup

    5. Setup 5. Setup The initial setup procedure consists of: • Configuring the computer’s network parameters and connecting to the WiN7200 Small Form Factor Base Station Web interface • Verifying IP connectivity 5.1. Connecting to the WiN7200 Small Form Factor Base Station Web Interface This section describes how to configure the network parameters in Microsoft Windows so you can connect a computer to the WiN7200 Small Form Factor Base Station.

  • Page 29: Microsoft Windows Internet Protocol (Tcp/Ip) Properties Dialog Box

    5. Setup In the Items list, select Internet Protocol (TCP/IP) and click the Properties button. The Internet Protocol (TCP/IP) Properties dialog appears. Assign your computer the IP address 192.168.100.99 and the subnet 255.255.255.0. Figure 5.2. Microsoft Windows Internet Protocol (TCP/IP) Properties dialog box On the Internet Protocol (TCP/IP) Properties dialog, click OK.

  • Page 30: Troubleshooting

    6. Troubleshooting 6. Troubleshooting 6.1. No IP connectivity If there is no IP connectivity between the WiN7200 Small Form Factor Base Station unit and the NMS, perform the following steps: 1. Connect the the computer and the WiN7200 Small Form Factor Base Station Console connector (serial connection), located on the unit’s bottom panel.

  • Page 31: List Of Acronyms

    Quality of Service Radio Frequency Service Level Agreements SNMP Simple Network Management Protocol Transmission Control Protocol WiMAX Worldwide Interoperability for Microwave Access RuggedMAX™ RuggedMAX™ WiMAX Product Family RuggedNMS™ RuggedCom® Network Management System Table A.1. List of Acronyms RuggedMAX™ Installation Guide Rev 1.0...

  • Page 32: Win7200 Small Form Factor Base Station Specifications

    Appendix B. WiN7200 Small Form Factor Base Station Specifications Appendix B. WiN7200 Small Form Factor Base Station Specifications Radio and Modem: • Frequency: • WiN7225: 2483 MHz to 2690 MHz • WiN7235: 3400 MHz to 3600 MHz • WiN7237: 3600 MHz to 3720 MHz •...
  • Page 33 Appendix B. WiN7200 Small Form Factor Base Station Specifications • Weight <4kg Power Interface: • Power supply Input 85-265 VAC • Power Consumption 30 W max Environmental: • Operating Temperature: -40°C to +65°C • Operating Humidity 5%-95% non condensing, • Weather protected Standards Compliance: •...

  • Page 34: Idu To Odu Cable Specifications

    Appendix C. IDU to ODU Cable Specifications Appendix C. IDU to ODU Cable Specifications Special 4×2×24 AWG FTP Cat. 5e Outdoor Double Jacket Data Cable UL (1581 VW 1) Applications: Outdoor installations, fixed or portable installations, digital distribution frames in transmission stations, outdoor installations in harsh environments.

  • Page 35: C.4. Idu To Odu Cable Performance

    Appendix C. IDU to ODU Cable Specifications Frequency Range: 1-100 MHz Impedance: 100Ω DC Resistance: 93Ω/km nominal Max. DC Resistance 95Ω/km@20°C Capacitance Unbalance: 1.6pF/m max. Velocity of Propagation: 68% nominal Propagation Delay Skew: 35 ns/100m max. Dielectric Strength: 700 V/minute Dielectric Strength to Shield: 700 V/minute Min.

  • Page 36: Console Connector Specifications

    Appendix D. Console Connector Specifications Appendix D. Console Connector Specifications The Console connector should be closed in normal conditions and is only intended for the use of an authorized technician. The chassis has an RJ-45 maintenance female connector, used by a technician to connect a “console”.

  • Page 37: Win7200 Small Form Factor Base Station Base Station Mechanical Drawing

    Appendix E. WiN7200 Small Form Factor Base Station Base Station Mechanical Drawing Appendix E. WiN7200 Small Form Factor Base Station Base Station Mechanical Drawing Figure E.1. WiN7200 Small Form Factor Base Station Base Station Mechanical Drawing RuggedMAX™ Installation Guide Rev 1.0...

  • Page 38: Warranty

    Appendix F. Warranty Appendix F. Warranty RuggedCom warrants this product for a period of five (5) years from the date of purchase. This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void. For warranty details, visit www.RuggedCom.com...
