- Page 1 ELEGANCY ELJ-1400 User’s Guide Product Name : ELJ-1400 Manual Reversion : 1.0 Release Date : DEC. 2001...
- Page 2 Copyright 2000 All rights Reserved- Printed in Taiwan Notice We make no warranties with respect to this documentation either express or implied and provide it "as it". This includes but is not limited to any implied warranties of merchantability and fitness for a particular purpose. The information in this document is subject to change without notice.
-
Page 3: General Safety Guidelines
General Safety Guidelines DO NOT place the ELJ-1400 on DO NOT expose ELJ-1400 to dirty or dusty environments. uneven or unstable work surfaces. Seek servicing if the casing has been damaged. DO NOT expose ELJ-1400 to DO NOT expose ELJ-1400 to liquids, rain, or moisture. - Page 4 About your User’s Guide Welcome to your ELJ-1400 Storage System User’s Guide. This manual covers everything you need to know in learning how to install or configure your system on an assumption that you know the basic concepts of FC-AL storage technology.
-
Page 5: Table Of Contents
Contents Chapter 1. INTRODUCTION Feature Highlight Chapter 2. GETTING STARTED Unpacking & Checking The Equipments Identifing Parts Of The Elegancy Front View Rear View Drive cartridge Installing the disk Installing the disk cartridge Chapter 3. CONFIGURING THE FIBRE CHANNEL Cabling Setting Fibre ID Chapter 4. -
Page 6: Chapter 1. Introduction
CHAPTER 1. INTRODUCTION The Elegancy ELJ-1400 is the latest generation full fault-tolerant 19” rackmount Fibre JBOD storage solution in a dense 3 U height form factor. The dual fibre channel host interface provides the means of transferring data over long distance with the error checking at an outstanding rate of 1Gbit/sec. -
Page 7: Chapter 2. Getting Started
l Expandale system, up to 8 enclosure for very high capacity configuration. CHAPTER 2. GETTING STARTED... -
Page 8: Unpacking & Checking The Equipments
UNPACKING & CHECKING THE EQUIPMENT Before unpacking the ELJ-1400, prepare a clean, stable surface to put on the contents of your ELJ-1400 shipping container . Altogether, you should find the following items in the package : Remove all the items from the container. If anything is missing or broken, please inform your dealer. - Page 9 3. 4. 10. 11. 12. Fibre Channel Interface Module A. Power Module 1. Power Module 2. Power Module 3. Power Switch Fibre Channel Interface Module B. Blower A. SES Module or I 2C module Power Inlet 10. Fibre ID setting switch 11.
- Page 10 Location of devices in ELJ-1400 Release button Hard disk driver Device Status Indicator Latch Handle Latch LOCK UNLOCK Device Status Indicator Colors Indicate Green HDD On Line...
-
Page 11: Installing The Disk
Green & HDD Access Flash HDD Error Installing the disk Insert HDD into the cartridge. Fasten the screws to mount the drive in the disk cartridge. Make sure the drive is properly tightened Installing the disk cartridge Make sure the handle is up and the latch is on the position of unlock . Gently slide the disk cartridge to the end of the slot then firmly push until the face plate of the disk cartridge is flush with the front panel of the ELJ-1400. -
Page 12: Cabling
CHARPER 3. CONFIGURING THE FIBRE CHANNEL This Chapter provides a detail information for the cabling of ELJ-1400 and the device ID setting. Cabling Port A In/Out Port B In/Out Port A In/Out Port B In/Out 0-7 Thumbwheel 0-15 Thumbwheel ID ID switch switch The Fibre channel Interface module at the rear panel provide the connectivity... -
Page 13: Setting Fibre Id
Setting Fibre ID There are two thumbwheel switches located on the rear panel. These switches set the drive IDs within the enclosure. 0-7 thumbwheel switch, control the drive ID addresses which is multiplied by 16, the 0-15 thumb wheel switch is using to set the offset to the 0-7 thumb wheel switch. -
Page 14: Chapter 4. Environment Monitoring
Chapter 4. Environment Monitoring The ELJ-1400 supports two type of monitoring module, one is the SES monitoring module, another is I2C module, this chapter covers all the information require for both modules : I2C monitoring module : The I2C monitoring module is an interface that enables the communications between the ELJ-1400 and the RAID controller. -
Page 15: Chapter 5. Hot Swap Components
CHAPTER 5. HOT SWAP COMPONENTS The BROWNIE ™ supports the hot -swappable disk cartridges, power supply modules and cooling fan unit. The following sections describe how to use the hot swap feature. Hot Swapping the Disk Drive To hot swap a disk, perform the following steps ( Refer “Installing the disk” ). Slide the latch to the position of unlock. -
Page 16: Hot Swapping The Cooling Fan Module
Power Status Indicator Green : Power Okay : Power Fail Power “Alarm” Reset Screw Button Hot Swapping The Cooling Fan Module Once the system cooling fans module has defective, the LCD on front panel will display “Fail Fan” and audible alarm will be sound. To hot swap a system cooling fan module perform the following steps. - Page 17 Thumb screw Fan Fail LED...
-
Page 18: Appendix A. Specification
APPENDIX A. SPECIFICATION Specifications ELA-1400FC-R ELJ-1400FC ELC-1400FC ELA-1400FC-D Same Same RAID Controller 0, 1, 0+1, 3, 5, 10, 30, 50, NRAID, JBOD RAID Level Up to 1GB maximum cache size on single SDRAM DIMM socket with ECC support Catch Memory per controller board Multiple host support and host-LUN mapping for multiple server environments,...
