Installation / User Manual
APsystems YC500A/I (240V)
Photovoltaic Grid-connected Microinverter
Rev 1.1
ALTENERGY POWER SYSTEM Inc.
www.APsystems.com
APsystems Shanghai
Rm.B403, No.188 Zhangyang Road, Pudong, Shanghai 200120, P.R.C
TEL: 021-33928205
EMAIL:info@altenergy-power.com
(For Mexico)
© All Rights Reserved
Advertisement
Table of Contents
Troubleshooting
Summary of Contents for AP systems YC500A-NA-MX
- Page 1 Installation / User Manual APsystems YC500A/I (240V) Photovoltaic Grid-connected Microinverter Rev 1.1 ALTENERGY POWER SYSTEM Inc. www.APsystems.com APsystems Shanghai Rm.B403, No.188 Zhangyang Road, Pudong, Shanghai 200120, P.R.C TEL: 021-33928205 EMAIL:info@altenergy-power.com (For Mexico) © All Rights Reserved...
-
Page 2: Table Of Contents
Table of Contents Important Safety Instructions........................2 Safety Instructions..............................2 Radio interference statement..........................3 APsystems Microinverter System Introduction..................4 APsystems Microinverter YC500 Introduction..................6 APsystems Microinverter System Installation..................7 Additional Installation components from APsystems..................7 Required Parts and Tools from you........................7 YC500A Installation Procedures..........................8 Step 1 - Installing the AC Branch Circuit Junction Box..................8 Step 2 - Attaching the APsystems Microinverters to the Racking or the PV Module Frame...... -
Page 3: Important Safety Instructions
SAVE THESE INSTRUCTIONS! This manual contains important instructions for models YC500A-NA-MX/YC500I-NA-MX that must be followed during installation and maintenance of the Photovoltaic Grid-connected Inverter. Specifications subject to change without notice - please ensure you are using the most recent update found at www.APsystems.com... -
Page 4: Radio Interference Statement
Radio interference statement FCC Compliance：The equipment can comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules, which are designed to protect against harmful interference in a residential installation. The equipment could radiate radio frequency energy and this might cause harmful interference to radio communications if not following the instructions when installing and using the equipment. -
Page 5: Apsystems Microinverter System Introduction
APsystems Microinverter System Introduction The APsystems Microinverter is used in utility-interactive grid-tied applications, comprised of three key elements: APsystems Microinverter APsystems Energy Communication Unit (ECU) APsystems Energy Monitor and Analysis (EMA) web-based monitoring and analysis system Figure 1 APsystems YC500A/I Installation/User Manual... - Page 6 For YC500I-NA-MX, the Ground wire (PE) of the AC cable is connected to the chassis inside of the Microinverter, eliminating the installation of grounding wire. For YC500A-NA-MX, the Ground wire is installed outside of the Microinverter. As the following figures:NA Figure 2...
-
Page 7: Apsystems Microinverter Yc500 Introduction
APsystems Microinverters: www.APsystems.com Model Max. # AC grid PV Module Module Connector Number Per branch YC500A-NA-MX 7 for 20A breaker 60Hz/220V 60,72 Cell MC-4 Type or Customize YC500I-NA-MX 8 for 25A breaker APsystems YC500A/I Installation/User Manual... -
Page 8: Apsystems Microinverter System Installation
APsystems Microinverter System Installation A PV system using APsystems Microinverters is simple to install. Each Microinverter easily mounts on the PV racking, directly beneath the PV module(s). Low voltage DC wires connect from the PV module directly to the Microinverter, eliminating the risk of high DC voltage. Installation MUST comply with local regulations and technical rules. -
Page 9: Yc500A Installation Procedures
YC500A Installation Procedures APsystems Microinverters are designed to only operate when they can sense power coming from the grid. Even if they are plugged into the solar array, they will not turn themselves on until they can read power from the grid. Do NOT connect APsystems Microinverters to the WARNING: utility grid or energize the AC circuit until you have completed... -
Page 10: Step 2 - Attaching The Apsystems Microinverters To The Racking Or The Pv Module Frame
YC500A Installation Procedures Step 2 - Attaching the APsystems Microinverters to the Racking or the PV Module Frame Attach to the racking a. Mark the location of the Microinverter on the rack, with respect to the PV module junction box or any other obstructions. b. -
Page 11: Step 3 - Connecting The Apsystems Microinverter Ac Cables
YC500A Installation Procedures Step 3 - Connecting the APsystems Microinverter AC Cables Figure 8 Male Female Connector Connector Best Practice: Use screwdriver to split the Main connectors. Figure 9 a. Check the Microinverter technical data page (P.23) for the maximum allowable number of Microinverters on each AC branch circuit. -
Page 12: Step 4 - Ground The System
YC500A Installation Procedures Step 4 - Ground the System If you already use grounding washers (WEEB) to ground the Microinverter chassis to the PV module racking as described in Step 2, skip this step. Figure 12 Each APsystems Microinverter comes with a ground clamp that can accommodate a single #6 awg strand and #4 awg solid conductor. -
Page 13: Step 6 - Complete The Apsystems Installation Map
YC500A Installation Procedures About A and B Sides corresponding the location of modules, NOTE: EMA registration show acquiesce in this installation. if there are different connection methods, please email the detail installation drawings to us to register, or the A, B Sides corresponding component location will not correspond to the EMA position. - Page 14 YC500A Installation Procedures APsystems Microinverter&Energy Communication Unit Warranty Card The APsystems Installation Map is a diagram of the physical location of each microinverter in your PV installation. Each APsystems microinverter has a removable serial number label located on the mounting plate. Pee l the label and affix it to the respective location on the APsystems installation map.
-
Page 15: Yc500I Installation Procedures
YC500I Installation Procedures Step 1 - Position the AC bus cable Step 2 - Install the AC branch circuit junction box Figure 17 a. Install an appropriate junction box at a suitable location on the PV racking system ((typically at the end of a branch of modules). b. -
Page 16: Stpe 4 - Connect The Apsystems Microinverter To Ac Bus Cable
YC500I Installation Procedures Attach to the PV module frame. Drill holes on the PV module frame before installing YC500I. Please check with the module manufacturer the compatibilty of such installation process. Figure 20 Prior to installing any of the microinverters, verify WARNING: that the utility voltage at the point of common connection matches the voltage rating on microinverter label. -
Page 17: Step 5 - Install A Ac Bus Protective End Cap At The End Of Ac Bus Cable
YC500I Installation Procedures AC connector interface as follows. Figure 22 Cover any unused connectors with sealing caps to protect the connectors. Figure 23 Do NOT exceed maximum number of Microinverters WARNING: in an AC branch circuit, as displayed on the Technical Data page (p.23) of this manual. -
Page 18: Step 7 - Complete The Apsystems Installation Map
YC500I Installation Procedures Double check to make sure all of the AC and DC wiring WARNING: has been correctly installed. Ensure that none of the AC and/or DC wires are pinched or damaged. Make sure that all of the junction boxes are properly closed. -
Page 19: Yc500I Installation Procedures
YC500I Installation Procedures Figure 27 APsystems Microinverter&Energy Communication Unit Warranty Card The APsystems Installation Map is a diagram of the physical location of each microinverter in your PV installation. Each APsystems microinverter has a removable serial number label located on the mounting plate. Pee l the label and affix it to the respective location on the APsystems installation map. -
Page 20: Apsystems Microinverter System Operating Instructions
APsystems microinverter system operating instructions To operate the APsystems microinverter PV system: 1. Turn ON the AC circuit breaker on each microinverter AC branch circuit. 2. Turn ON the main utility-grid AC circuit breaker. Your system will start producing power after a five-minute waiting time. 3. -
Page 21: Troubleshooting
Troubleshooting Qualified personnel can use the following troubleshooting steps if the PV system does not operate correctly: Status Indications and Error Reporting Start up LED One quick red light followed by three short green blinks when DC power is first applied to the Microinverter indicates a successful Microinverter startup. -
Page 22: Troubleshooting A Non-Operating Apsystems Microinverter
Troubleshooting Troubleshooting a non-operating APsystems Microinverter There are two possible overall areas of trouble: A. The Microinverter itself may be having problems. B. The Microinverter itself is working fine but it is having trouble communicating with the ECU. The items below refer to Microinverter issues, not communication issues (addressed in the ECU manual). -
Page 23: Replace A Microinverter
Replace a microinverter Follow the procedure to replace a failed APsystems Microinverter. A. Disconnect the APsystems Microinverter from the PV Module, in the order shown below: 1. Disconnect the AC by turning off the branch circuit breaker. 2. Disconnect the first AC connector in the branch circuit. 3. -
Page 24: Technical Data
Technical Data Be sure to verify the voltage and current specifications WARNING: of your PV module match with those of the Microinverter. Refer to the APsystems website www.APsystems.com for a list of approved PV modules. You must match the DC operating voltage range of WARNING: the PV module with the allowable input voltage range of the APsystems Microinverter. -
Page 25: Apsystems Yc500 Microinverter Datasheet
APsystems YC500 Microinverter Datasheet Region Mexico Model YC500A-NA-MX YC500I-NA-MX Input Data (DC) MPPT Voltage Range 22V-45V Operation Voltage Range 16V-52V Maximum Input Voltage Startup Voltage Maximum Input Current 12A x 2 Output Data (AC) Nominal Output Voltage 220V Maximum Continuous Output Power... -
Page 26: Yc500A Wiring Diagram
YC500A Wiring Diagram Sample Wiring Diagram - 110V/240V Split Phase Figure 29 APsystems YC500A/I Installation/User Manual... -
Page 27: Yc500I Wiring Diagram
YC500I Wiring Diagram Sample Wiring Diagram - 120V/240V Split Phase Figure 30 APsystems YC500A/I Installation/User Manual... - Page 28 APsystems Microinverter &Energy Communication Unit Warranty Card The APsystems Installation Map is a diagram of the physical location of each microinverter in your PV installation. Each APsystems microinverter has a removable serial number label located on the mounting plate. Peel the label and affix it to the respective location on the APsystems installation map.
