  • Page 1 Instruction Manual RS-301 www.hifirose.com...

  • Page 2: Table Of Contents

    Contents Safety Precautions Warnings Precautions On the Use of Products Before Use 1. List of components 2. Notes on use 3. Instructions for using keys and buttons on the bottom bar 4. Status LED 5. Inserting / Removing an External Memory Card 6.

  • Page 3: Safety Precautions

    • The contents of this instruction manual are based on the initial settings of RS-301. • Execution screens and pictures provided in this instruction manual may differ from actual ones. • In order to improve the performance of RS-301, some functions of the instruction manual may be changed without prior notice to the user.

  • Page 4: List Of Components

    1. List of Components • This product is optimized for the components supplied with the purchase, and some functions may be restricted when used by connecting to non-component products. • The image of the components may differ from the actual product, and the list of components may change according to the manufacturer's policy.

  • Page 5: Status Led

    2. Basic Function Power Button Power ON: Press for 1 second ··Power OFF: Press for 3 seconds ▶ Touch 'End' button ··Restart: Press for 3 seconds ▶ Touch 'Restart' button Wheel key • Turn: Adjust the volume Active standby [Screen ON] Press for 1 second ▶ Stop sound and turn off screen [Screen OFF] Press for 1 second ▶...

  • Page 6: Inserting / Removing An External Memory Card

    Connection on the back of the product 1. AUX input - Symbol for input of the AUX 2. Headphone output - Symbol for the output of the headphone 3. Micro SD card - Symbol for Micro SD card 4. USB A terminal - Symbol for USB A terminal 5.

  • Page 7: Home Screen And Menu Widgets

    3. Home Screens and Menu Widgets Configuration of the Home Screen It is a space to select Shortcut Icon. Home screen menus can be moved using left and right scrolling. Top bar Menu widget Playlist Top bar · Top bar: Display the connection status of 'Time, Product ID, Headset, Aux, iTunes Remote, Bluetooth, Airplay, WiFi'.

  • Page 8: Setting

    Perform Rose's information and basic settings. System Information Turn on the Power of the RS-301 and go to the setup screen as shown in the Picture (A) below. When you go to the setting screen, you can see the system information like a Picture (B).

  • Page 9: Language Settings

    Language settings When you click the language setting (A) in the Picture (A), a pop-up window for setting the language will be displayed like the Picture (B). When you select the language you want to change in the Picture (B), a pop-up window of the notice like the Picture (C) will appear.

  • Page 10: Clock Settings

    Clock screen Turn on the RS-301 and go to the clock screen as shown in the Picture (A) below. After moving to the clock screen, when you click on a blank space in the Picture below (B), the screen will changes in the order of picture (B) - picture (C) - picture (D).
  • Page 11 If you click the Time Setting (C) in the Picture (A), a pop-up window like the Picture (C) will appear and you can set the time for the alarm operation. If you click the Ringtone (B) in the Picture (A), a pop-up window will appear like the Picture (D) and you can set the ringtone with default bell, USB, Micro SD Card and radio.
  • Page 12 If the Ethernet is connected like the Picture (A), it shows the Ethernet information. If you click Static IP in the Picture (B), it will be moved to the window where you can set IP manually. In the Picture (C), enter the IP to be manually entered into the Static IP (A), and then click the IP Setting (B) button to manually set the IP.
  • Page 13 • RS-301 and the device to implement Airplay must be connected to the same AP (wireless network). Turn on the RS-301 and connect the WiFi by selecting the WiFi Icon (A) on the home screen as shown in the Picture (A).

  • Page 14: Itunes Remote

    It is possible to control iTunes of MAC PC on RS-301. • RS-301 and MAC PC must be connected to the same AP (wireless network). iTunes must be running on MAC PC. Click the iTunes Remote Icon in the home of RS-301 as shown in Picture (F).

  • Page 15: Rose Tube

    4. Rose Tube You can enjoy the contents of YouTube without advertising in Rose Tube. Turn on the RS-301 and go to the Rose Tube screen as shown in the Picture (A) below. Recommendation Rose Tube provides popular content by country in rankings.
  • Page 16 Recommendations for Rose You can see the desired videos by category. Recommended YouTube contents by Rose is provided by category. If you click on Rose's Recommendation in Picture (A), it will move to the screen like Picture (B). Also, if you select the category you want to view, it will move to the screen that contains only the relevant videos as shown in Picture (C).
  • Page 17 When you click "OK" in Picture (C), the channel will be added to the subscription. If you click the Subscription Icon (B) in the Picture (A), it will moves to the screen like the Picture (D). Also, when you click Subscribe, a pop-up window like Picture (E) will appear.
  • Page 18 Favorites If you click the Heart Icon of the video you want to add to the favorites from the video list of the Picture (A), the corresponding video will be added to your favorites. If you want to add a video as a favorite on the playback screen of Picture (B), click on the Heart Icon to add it as a favorite. If you click on the play-list in the Picture (C) and move to the Picture (D) screen and click on the Favorite, it will show videos added to Favorites as a Picture (E).
  • Page 19 Play-list To add a play-list, click on the play-list in the Picture (A), go to Picture (B), and click the Add button. If a pop-up window as shown below (C) appears, set the play-list name and click OK. Then a play-list will be created as shown in Picture (D).
  • Page 20 If you want to add to the play-list on the play screen of the Picture (G), click the 'Add Play-list' Icon. Then a pop-up window will appear like Picture (H). In the Picture (H), if you check the play-list you want to add in the play-list (A) and click the ADD button (B), the video will be added to the play-list.
  • Page 21 The videos corresponding to the search you entered show the video lists like Picture (C). If you click the Search Icon again, it will be shown like the Picture (D) screen. The most recent search term is shown as a Picture (D), and if you click on the latest search, the video list is automatically displayed.
  • Page 22 (B). If you click on a discovered device at this time, pairing will be attempted. As shown in the Picture (C), if you press the "Allow device search" (A) button and the light is on, RS-301 will appear in the...
  • Page 23 When pairing is attempted, a pop-up will appear on the mobile device for the pairing request. When you press OK, the • pairing will take place. When the pairing is completed as shown in the Picture (D) below, the registered device will be added to the list (A). Also, when you click on the device, it will try to connect.

  • Page 24: Wired Connection Of Pc

    7 Wired connection of PC PC Audio connection You can listen to the PC sound on RS-301 as a digital sound source. • You must install the driver before using PC Audio. Download Rose_PC_Audio_Driver.zip from Rose homepage (www.hifirose.com). After unzipping the downloaded Rose_PC_Audio_Driver file and running PcAudio.msi, the following screen will appear. Click Next.
  • Page 25 Favorites Turn on the RS-301 and go to the music screen as shown in the Picture (A) below. After moving to the music screen, if you select the song you want to listen to as shown in the Picture (B) below, it will go to the playback screen.
  • Page 26 Play-list To add a play-list, click on the play-list in the Picture (A), go to Picture (B), and click the Add button. If a pop-up window as shown below (C) appears, set the play-list name and click OK. Then a play-list will be created as shown in Picture (D).
  • Page 27 Music folder The Music Folder arranges the folders that contain music on the storage media (USB, Micro SD Card) and plays the songs by folder. When you click music folder in Picture (A), it will show music folders like Picture (B). If you click on a folder, it will go to music playback screen like the Picture (C) and the song will play automatically.
  • Page 28 If you click on the currently connected storage medium (USB, Micro SD Card) folder, the folder list will be displayed like the Picture (c). In the Picture (C), if you click the folder containing the music files, the music list will appear like the Picture (D). Also, if you click it, the corresponding song will play.
  • Page 29 Enter the connection information (A) of the device to be connected in the pop-up window like the Picture (C). If the device is not password-protected, check the "Open" (B) and click the OK button (C). If the information you entered is correct, the folders and files of the shared device, such as Picture (D), will appear. Music and video are played when you select files to use.
  • Page 30 Grid Screen If you click the Grid Icon in the Picture (A), it will show the list as a grid screen like Picture (B). If you click music on the Grid screen of Picture (B), it will move to the playback screen. When you click the Lyric Icon (A) on the playback screen of the Picture (C), the lyrics of the song will be shown as Picture (D).
  • Page 31 Video playback Turn on the RS-301 and go to the video screen as shown in the picture (A) below. After moving to the video screen, if you select a video you want to view as shown in the picture (B) below, the screen will go to the playback screen.
  • Page 32 Video Search When you click the Search Icon in the Picture (A), it will show the video search screen like the Picture (B). In Picture (B), if you click the video you want to view in the video list, it will move to the video playback screen. Folders and Networks Folders import folders on the storage medium (USB, Micro SD Card).
  • Page 33 Radio playback Turn on the RS-301 and go to the radio screen as shown in the Picture (A) below. After moving to the radio screen, when you select the radio you want to listen to as shown in the Picture (B) below, the radio will play.
  • Page 34 Radio settings When you click the Setting in the Picture (A), it will show the settings related to the radio like the Picture (B). In Picture (B), if you reapply ‘Automatic Restart Setting for Last Channel’ (A) to the active radio menu, the last radio heard will automatically restart.
  • Page 35 When you click Country (E) in Picture (B), a pop-up window like Picture (E) will appear. If you click Update in Picture (F) after selecting a country, it will only show a list of selected countries. Radio channel If you click ‘Add Channel’ Icon in Picture (A), pop-up window like Picture (B) will appear. You can then enter the channel information and register the channel.

  • Page 36: Hardware Specifications

    02 Specifications 1. Hardware Specifications Specification Description Main Chipset Quad-core ARM 1.2Ghz Android 5.0 (Lollipop) 1GB DDR3 DRAM Memory Flash 8GB eMMc Video VC-1, H.264, H.265, VC-1, MPEG 1,2,3,4 MPEG 1 Layer 1/2/3, WMA, flac, ape, ogg DSD64 / DSD128 / DSD256 PCM 32Bit / 384kHz Codec 32Bit 384kHz HyperStream Audio DAC Audio...
  • Page 37 Model Name - RS-301 One year from the date of purchase of the warranty period ▪ Name of equipment: Specific low power radio equipment (RS-301) ▪ Name of the company that received the conformity assessment: CITECH Co. Ltd. ▪ Manufacturer / Country of manufacture: CITECK Co., Ltd. / Korea ▪...
  • Page 38 • It is possible to download and use the software. • Through the newsletter, you can get information on Rose's latest news events and new products. Searching a service center It is possible to check the telephone number and location information of the nearest service center from the customer service center or homepage.
  • Page 39 < Product Specification and certification > Contents Description Frequency 2 412 ㎒ ~ 2 472 ㎒ (802.11b/g/n 20 ㎒ BW) Range 2 402 ㎒ ~ 2 480 ㎒ (Bluetooth, Bluetooth Low Energy) 5 180 ㎒ ~ 5 240 ㎒ (802.11a/n 20 ㎒ BW) 5 745 ㎒...
