- Page 1 Operating Manual Uninterruptible Power Supply Wärtsilä JOVYTEC PNT 1000VA – 3000VA BAX 3313_en...
- Page 2 Index Date Name Revision 28. March. A.Heller Original 2007 14.May 2007 A.Heller Revision Compass Distances 30.05.2007 Th.Harms 07/277 13.06.2007 A.Heller ID added 15.11.2007 A.Heller Designation X1 added 24.01.2008 A.Heller Software Version added 04.08.2008 A.Heller DNV Certificate added 29.08.2008 Th. Harms 08/308 Relay card removed (Not possible at NT Series) 23.03.2009 A.Heller...
- Page 3 Complaints made later than this cannot be considered. Wärtsilä JOVYATLAS EUROATLAS GmbH will annul all duties such as promises to offer a warranty period, service contracts etc. without warning if any spare parts other than original are used for maintenance and repair purposes.
-
Page 4: Table Of Contents
TABLE OF CONTENT GENERAL NOTES SCOPE OF DELIVERY GENERAL NOTES REGARDING THE UPS DEVICES DESCRIPTION OF THE SYSTEM GENERAL DESCRIPTION OF THE FUNCTION TECHNICAL DATA 1000 VA 1500 VA 2000 VA 3000 VA TECHNICAL DATA BATTERIES VIEWS OF THE UPS FRONT VIEW 1000VA –... - Page 5 7.7.6 GENERATOR MODE ERROR MESSAGES AND THEIR REMOVAL 7.8.1 OPTICAL AND ACOUSTICAL ERROR MESSAGES SERVICE INFORMATION REMOTE MONITORING CONNECTING THE UPS TO THE COMPUTER ASSIGNMENT OF THE RS232 INTERFACE SPECIAL EQUIPMENT 10.1 ELECTRONIC STOP FUNCTION BATTERY 11.1 BATTERY OPERATION 11.2 SERVICE LIFE OF BATTERIES 11.3 INSTRUCTIONS FOR USING THE BATTERIES...
-
Page 6: General Notes
For this UPS systems are Type Approval certificates by GL, DNV and BV on our website in the download section available: http://www.jovyatlas.com/ja/JOVYTEC-P-nt,120-83-2. IMPORTANT: The manufacturer declines all responsibility for damages to people or equipment deriving from non-fulfilment of the above. -
Page 7: General Notes Regarding The Ups Devices
General notes regarding the ups devices N O T E! The UPS should be attached to the mains supply and switched on at the latest 4 weeks after receipt in order to prevent the battery discharging itself. P L E A S E N O T E! The batteries used are just designed for the required backup time to supply the nominal load of the UPS. -
Page 8: General Description Of The Function
General description of the function Normal operation During normal operation the battery and the inverter are supplied with power via a rectifier (online operation). The change-over from alternating voltage to direct voltage and back to alternating voltage again is achieved by a sinusoid output voltage with a low distortion factor. - Page 9 Fault in the inverter or an overload (bypass operation) In the case of a fault occurring in the inverter or an overload, a switch-over device switches the load back to the mains. This means that, in the case of a power failure, the connected consumers will no longer be supplied with power.
-
Page 10: Technical Data
Technical data 1000 VA cos 0,7 ind. Output power 1000VA / 700W 230V Input voltage ranges Voltage 168V - 276V (0-100% load) 140 - 159V (0-70% load) 120 - 139V (0-40% load) Current with standard charger 3.6A Network supply Current with additional charger 4,6A Frequency... -
Page 11: 1500 Va
1500 VA cos 0,7 ind. Output power 1500VA / 1050W 230V Input voltage ranges Voltage 168V - 276V (0-100% load) 140 - 159V (0-70% load) 120 - 139V (0-40% load) Current with standard charger 5,7A Network supply Current with additional charger 6,9A Frequency 50Hz ±3Hz or 60Hz ±3Hz... -
Page 12: 2000 Va
2000 VA cos 0,7 ind. Output power 2000VA / 1400W 230V Input voltage ranges Voltage 168V - 276V (0-100% load) 140 - 159V (0-70% load) 120 - 139V (0-40% load) Current with standard charger 7,7A Network supply Current with additional charger 8,9A Frequency 50Hz ±3Hz or 60Hz ±3Hz... -
Page 13: 3000 Va
3000 VA cos 0,7 ind. Output power 3000VA / 2100W 230V Input voltage ranges Voltage 168V - 276V (0-100% load) 140 - 159V (0-70% load) 120 - 139V (0-40% load) Current with standard charger 10,7A Network supply Current with additional charger 11,9A Frequency 50Hz ±3Hz or 60Hz ±3Hz... -
Page 14: Technical Data Batteries
Technical data batteries Battery for 1000VA UPS Voltage Capacity Quantity 3 pcs. General Data Weigth each bloc 2,54kg Dimensions each bloc (LxWxH) 151 x 65 x 94mm Type of battery JL 205670 Battery for 1500VA UPS Voltage Capacity Quantity 3 pcs. General Data Weigth each bloc 2,54kg... -
Page 15: Views Of The Ups
Front view 1000VA – 1500 VA DISPLAY FUNC BUTTON ENTER BUTTON ON/OFF BUTTON FUNC ENTER ON-LINE ON-BAT ON/OFF BY PASS FAULT JOVYATLAS SHOCK MOUNT SHOCK MOUNT MOUNTING PLATE Sign Meaning Operation ON - LINE Output Voltage available ON – BAT Battery Operation BYPASS... -
Page 16: Rear View 1000 Va - 1500 Va
Rear view 1000 VA – 1500 VA RS232 BATTERIEVERBINDER BATTERY CONNECTOR COVER PLATE Abdeckplatte USV AUSGANG 1 230V 50/60Hz UPS OUTPUT 1 Erdungsbolzen M6 230V 50/60Hz EARTHING BOLT M6 10 AMP COVER PLATE Abdeckplatte COVER PLATE Abdeckplatte USV AUSGANG 2 230V 50/60Hz UPS OUTPUT 2 230V 50/60Hz... -
Page 17: Front View 2000 Va - 3000 Va
Front view 2000 VA – 3000 VA DISPLAY FUNC BUTTON ENTER BUTTON FUNC ENTER ON/OFF BUTTON ON-LINE ON-BAT ON/OFF BY PASS FAULT JOVYATLAS SHOCK MOUNT SHOCK MOUNT MOUNTING PLATE Sign Meaning Operation ON - LINE Output Voltage available ON – BAT Battery Operation BYPASS... -
Page 18: Rear View 2000 Va - 3000 Va
Rear view 2000 VA – 3000 VA RS232 10 AMP BATTERIEVERBINDER BATTERY CONNECTOR Eingangssicherung INPUT FUSE Abdeckplatte COVER PLATE NETZEINSPEISUNG 230V 50/60Hz MAINS INPUT 230V 50/60Hz Abdeckplatte COVER PLATE USV AUSGANG 1 USV AUSGANG 2 230V 50/60Hz 230V 50/60Hz Erdungsbolzen M6 EARTHING BOLT M6 UPS OUTPUT 1 UPS OUTPUT 2... -
Page 19: Electrical Connection
Electrical connection P L E A S E N O T E Only trained personnel are allowed to work on the UPS unit. Observe all corresponding safety regulations. Marking of cables is to be according to DIN EN 60445! When connecting to the UPS unit, ensure use of an adequately sized protective- conductor connection! P L E A S E N O T E When working on the batteries it is possible for dangerous situations to arise... -
Page 20: Commissioning
Commissioning P L E A S E N OT E! The unit should be started over the input mains. If the input mains is not available for a short time then it is also possible to start the unit over the battery. It is a basic prerequisite for this operating mode that the UPS unit was one time operated over the energy supplier’s mains network. -
Page 21: Operating And Indicating Elements
Operating and indicating elements Function of LED and function keys Display indicator The display indicator informs about the operating modes, menu points and parameters. ON/OFF button The UPS unit can be switched on and off using the ON/OFF button. The formalism is as follows: The UPS unit is switched on by pressing the ON/OFF button for about 3 seconds. -
Page 22: Parameters
Parameters The table below show an example of an 1kVA – UPS Indicator Function of the indicator O/P VOLT = 230.0V Output voltage of the UPS O/P FREQ = 50,0Hz Output frequency of the UPS I/P VOLT = 230,2V Input voltage of the UPS I/P FREQ = 50,2Hz Input frequency of the UPS BAT VOLT = 24V... -
Page 23: Configuration
Configuration Use of the function display and the function keys allows diverse settings to be made on the UPS unit. The formalism is as follows: In order to achieve Configuration Mode it is necessary to press the key FUNC for 2 seconds. The first configuration parameter appears in the display. -
Page 24: Automatic/Manual Battery Test
Automatic/Manual battery test Automatic battery test In the interval of one month the UPS unit performs an automatic battery test. The UPS will return to normal operating mode after the battery test has been performed successfully. It is not necessary to operate any switches to do this!! If the battery is faulty, the message Battery fault will be shown in the display and a permanent tone will sound. -
Page 25: Free Running Off
7.7.2 Free running OFF If the input frequency is 49.3Hz, this value is within the narrow input frequency range. This means that the output frequency is also 49.3Hz (synchronised) and the UPS unit remains in line mode. If the input frequency then drops below 49Hz, for example 48Hz, then the input frequency is outside the specified values for the narrow input frequency range and the UPS unit switches to battery operation and supplies the load via the inverter with 50Hz. -
Page 26: Generator Mode
Summary: Free running mode On, bypass deactivated A fault occurs CPU on UPS checks whether the narrow input frequency window (±2%) and voltage window is being maintained if parameter OK no switch-over to bypass since bypass is deactivated Free running mode ... -
Page 27: Optical And Acoustical Error Messages
7.8.1 Optical and acoustical error messages Error message Acoustic Description of the alarm Removing the fault in the display alarm The UPS is overloaded. The load needs Overload Two bleeps Reduce the load by switching off more power than the UPS can deliver. The (output overload) per second unimportant consumers... -
Page 28: Service Information
Telefax: 04958 - 9394 - 10 E-Mail: service.jovyatlas.de@wartsila.com Internet: http://www.jovyatlas.de Remote monitoring The UPS unit is fitted as standard with an RS 232 signal output. This signal output is designed as a RS232- interface (SUB-D, 9-pin), and there is optionally the possibility of using an additional USB interface. -
Page 29: Special Equipment
Special equipment P L E A S E N O T E! The following conversion work or extension to the unit may only be performed by trained personnel and with the UPS unit in a deenergised condition. Observe the relevant safety regulations!! 10.1 Electronic STOP function The UPS is fitted with an integrated electronic STOP function. -
Page 30: Battery
Battery 11.1 Battery operation In the case of a network failure the consumers are supplied without interruption from the battery. In battery operation the LED ON-BAT (Battery operation) lights up and an acoustic warning tone sounds every 5 seconds. The acoustic warning tone changes towards the end of the backup time, i. e. when the battery is virtually discharged, to two bleeps sounding every 5 seconds. -
Page 31: Replacing An Internal Ups Battery
Replacing an internal UPS battery UPS units of this series offer the possibility by replacing the battery during operation. One must ensure in this case that the UPS unit is running in normal mode and not in autonomy mode. Proceed as follows to replace the battery: Remove the display panel through the stripping of the plastic cover. -
Page 32: Maintenance
Maintenance In case of longer standstill of the UPS (>4 weeks) the battery has to be charged monthly. For this charging you only have to connect the UPS to the mains for a charging time of at least 8 hours. However we recommend a charging time for about 24 hours. - Page 33 O. Böke n. Angabe n. Angabe 15/553 Nicht maßstäblich / Not scalable Kundenmodifizierung SAM Checked: Order-no.: Scale: Surface treatment: Varnishing: www.jovyatlas.de 452mm x 236mm x 2,0mm (1.4301) Zustand: Datum: Name: Norm: Werkzeug Kantbank: V10 V16 Programm-Nr. Kantbank: Abwicklungsabmessungen: Lager-Nr.: Blatt: von: B.
