- Page 1 USER MANUAL Cyfrowy modulator HDMI-DVB-T Model Nr：R86111...
- Page 2 Modulator HDMI-DVB-T R86111 jest urządzeniem, które wejściowy sygnał podany na złącze HDMI moduluje w standardzie DVB-T. Można na niego podać sygnał w wysokiej rozdzielczości Full HD. Posiada wejście HDMI oraz wyjście RF DVB-T. 1. Zasilacz AC 100V～240V 50HZ/60Hz, DC5V/2A 2. MDULATOR HDMI-DVB-T FIG.1 Widok od strony złącz (HDMI, zasilanie)
- Page 3 FIG.2 Widok od strony złącza RF DVB-T Uwaga: 1. Maksymalna długość transmisji sygnału przy pomocy kabla: 500m 2. Modulator nie posiada wsparcia dla protokołu HDCP 3.Poziom wyjściowy sygnału RF DVB-T z modulatora 100 dBuV – w przypadku przesterowania głowicy odbiornika na który podawany jest sygnał RF DVB-T z modulatora zaleca się zastosowanie tłumika sygnału RF.
-
Page 4: Przykład Zastosowania
0001 1000 0101 1000 0001 1001 0101 1001 0010 0000 0110 0000 0010 0001 0110 0001 0010 0010 0110 0010 0010 0011 0110 0011 0010 0100 0110 0100 0010 0101 0110 0101 0010 0110 0110 0110 0010 0111 0110 0111 0010 1000 0110 1000 0010 1001... - Page 5 DVB-T TV/ Receiver Coaxial cable Coaxial cable DVD/PC/STB HDMI cable CATV mixer Other TV/Monitor Special receiver DANE TECH. HDMIRozdzielczość………………………………..24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i HDMI Audio Format……………………………………………………………………………………..LPCM Częstotliwość RF (wyj.) …………………………………………………………… ……...139～950 MHz Szerokość kanału ………………………………………………………………......7/8 MHz Liczba kanałów………………………………………………………............80 ..100 RF wyjście…………………………………………………………………......dBμV Typ złącza RF …………………………………………………………………………………………złącze F Impedancja kabla koncentrycznego ……………………………………………………………………..75Ω...
- Page 6 Zasilanie ……..….….…….…….…….…. ……………………AC 100V～240V 50HZ/60Hz, DC5V/2A Temp. pracy ……..…………….………………………………………………………………. -10 … +45 ℃ Wymiary (L x W x H) ………………………………….……………………………………...94x74x28 (mm) Masa …….…………………………….………………………………………….………………..…… .120g...
-
Page 7: Dear Customer
Enjoy the vivid world! Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. The products are designed to make your A/V device use more convenient, comfortable, productive and cost-efficient. -
Page 8: Package Contents
multiple video matrix. The use of digital TV communication protocol, anti interference and error correction capability is very strong. Installs in minutes. The use of the existing CATV transmission network, no need wiring. PACKAGE CONTENTS: 1. AC power adapter 1pcs FEATURES OF THE INTERFACE: FIG.1 Front Panel View... - Page 9 FIG.2 Rear Panel View CHANNEL: Channel selection switch RF OUT: RF signal output OPERATIONG AND CONNECTION: 1. Pair to Pair mode Coaxial cable DVB-T TV/ Receiver HDMI cable DVD/PC/STB FIG.3 CONNECTION DIAGRAM 1. Connect one SYV-75/RG59 coaxial cable from Modulator (TX) RF OUT into the DVB-T Receiver Tuner /RF IN.
- Page 10 Ⅱ. One to multiple Splitter mode DVB-T TV/ Receiver Coaxial cable Coaxial cable DVD/PC/STB HDMI cable CATV mixer Other TV/Monitor Special receiver FIG.4 SPLITTER CONNECTION DIAGRAM 1. Connect one SYV-75/RG59 coaxial cable from TX RF OUT into the input port of CATV mixer. 2.
- Page 11 need amplification. For the high-frequency RF signal haves signal attenuation, signal strength will become weakened after adding CATV network mixer and multi output. 2. If the signal frequency is high, the transmission attenuation is greater. So choose low channel for long-distance transmission.
-
Page 12: Specifications
Switch setting note: 0-dial switch to the up, 1-dial switch to the down. In fact, the switch 8 bit code equals to the binary code of channel ID. SPECIFICATIONS: R86111 HDMI resolution ……………………………………..24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i HDMI Audio Format……………………………………………………………………………………..LPCM RF frequency range…………………………………………………………………………...139～950 MHz RF Channel B/W…………………………………………………………………………....7/8 MHz... - Page 13 Operating Humidity range ………………………….….……….……….10 to 90%RH (No Condensation) Storage Humidity range………………………….….……….……………5 to 95%RH (No Condensation) Case Dimension (L x W x H) ………………………………….…………………………….94x74x28 (mm) Weight …….…………………………….………………………………………….………………..…… 120g Notes: Pls use the machine as the instruction listed to keep the long use lifetime of the machine. 1.
- Page 14 1. Confirm the coaxial cables are intact and reliable connection. Image mosaic/ 2. Confirm the length of coaxial cable is too short or long. Abnormal Picture 3. Device EDID read error, please reboot. 4. Nearby signal interference, proposals to change the other channel 1.
