Macroboom
IP67 Waterproof Bluetooth Speaker With Solar Charging
Quick Start Guide
Contents
Macroboom
V2.Unit
Specifications
Unit Size/Weight: 170 x 82 x 78mm (L x W x H)
Output Power: RMS 15W
S/N Ratio: 85dB
Frequency Range: 90Hz - 20kHz +/-3dB
Power Source: 7.4V, 5200mAh LG Lithium Battery
Playtime: >8+ hours from full charge based on volume level
Charging Time: Approximately 5-6 hours
Function: Bluetooth/Truewirelss stereo/Solar charging/Aux-
in/Powerbank/Micphone
Bluetooth BT 4.0 Version + EDR supporting apt-x
Operating Temperature: 0-40°C
Dust/Waterproof IP Code: IP67
1
USB Cable
Carabiner
Advertisement
Table of Contents
Summary of Contents for Roamproof Macroboom IP67
- Page 1 Macroboom IP67 Waterproof Bluetooth Speaker With Solar Charging Quick Start Guide Contents USB Cable Macroboom V2.Unit Carabiner Specifications Unit Size/Weight: 170 x 82 x 78mm (L x W x H) Output Power: RMS 15W S/N Ratio: 85dB Frequency Range: 90Hz - 20kHz +/-3dB Power Source: 7.4V, 5200mAh LG Lithium Battery Playtime: >8+ hours from full charge based on volume level Charging Time: Approximately 5-6 hours...
- Page 2 Components of Macroboom Unit: Side Panel Control Buttons 1,Press the Power Standby button to turn the Power Macrobom on or off. When turned off, Macroboom Bluetooth remains in standby mode. Please note that Main Play/pause Power Switch on the back panel needs to be set on Micphone for Power Standby Switch button to operate.
- Page 3 button one time, you will hear a “dingdong” voice, it certify speaker is searching another speaker. If you have another macroboom on hand, pls power on and then press TWS button one time, this two speaker will connect within 10s-15s. Once two speaker connceted, you can hear a “ding”...
- Page 4 * Unlock the protective cover by turning the cap anti-clockwise to reveal the switch and connections. ** After using these functions, ensure that the cap is locked properly. If the cap on the back panel is not properly locked, Macroboom is not watertight. Miro USB To charge your Macroboom, connect the USB cable Input...
- Page 5 Step 2: Opening the Cap - Lift the Cap as shown. Locking Back Panel Cap Step 1: Closing the Cap - Cover the Back Panel Main Power Switch & Connection Functions with the Cap as shown. - The Cap must fit snugly into the Back panel. Step 2: Closing the Cap - Turn the cap clockwise as shown.
- Page 6 Operating Macroboom - Bluetooth Step 1: Charging your Macroboom to the max. - Switch off the Main Power Switch. Connect the USB cable and a power source to Nomad Micro USB Input 5V/1A function (as shown). - 4 blue bars on Battery Power Indicator show a fully charged Macroboom.
- Page 7 Product Use & Care Macroboom Bluetooth speaker is intended to be used both indoors and outdoors. The speaker has been tested to IP67 waterproofing standards. IP67standard allow Macroboom to be submerged in water up to 1 metre water for 30 minutes without any damage.
- Page 8 Do not use Macroboom when you are charging the battery. Do not use Nomad near any open fire, heat source or excessive heat. Do not open to modify, repair or remove any original component of Macroboom. A qualified technician must carry out repair work. Do not remove the built-in battery or the grill cover.
- Page 9 FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
