Summary of Contents for Shineway Technologies OCC-50
- Page 1 OCC-50 CWDM Optical Channel Checker User’s manual Shineway Technologies, Inc. All rights reserved.
-
Page 2: Safety Instructions
Do not open or mutilate batteries. Avoid touching the electrolyte in the batteries, which is corrosive and may cause injuries to eyes, skin or damage to clothes. External Power: OCC-50 supports external power. Power requirements: 13.8V/1.2A. Laser Radiation: To avoid serious eye injury, never look directly into the optical outputs Shineway Technologies, Inc. - Page 3 User’s Manual for OCC-50 of fiber optic network equipment, test equipment, patch cords, or test jumpers. Always avoid looking directly into the optical output port, when the instrument is working Always replace protective dust cap on the detector port when the instrument is not being used ...
-
Page 4: Table Of Contents
User’s Manual for OCC-50 Table of Contents SAFETY INSTRUCTIONS ................II 1.GENERAL INFORMATION ................1 1.1 S ................1 COPE OF THIS ANUAL 1.2 U ................ 1 NPACKING AND NSPECTION 1.3 I ....................2 NTRODUCTION 2. BASIC OPERATION ..................3 2.1 F... - Page 5 User’s Manual for OCC-50 6 WARRANTY INFORMATION ..............19 ..................20 WARRANTY PERIOD 6.2 E ....................20 XCLUSION 6.3 W ................. 20 ARRANTY EGISTRATION 6.4 R ................20 ETURNING NSTRUMENT 6.5 C ..............20 ONTACT USTOMER ERVICE Shineway Technologies, Inc.
- Page 6 User’s Manual for OCC-50 Table of Figure 3.1 ..........................7 IGURE 3.2 ..........................8 IGURE 3.3 ..........................8 IGURE 3.4 ..........................9 IGURE 3.5 ..........................9 IGURE 3.6 ..........................10 IGURE 3.7 ..........................11 IGURE 3.8 ..........................11 IGURE 3.9 ..........................12 IGURE 3.10 ...........................
-
Page 7: General Information
OCC-50 Handheld CWDM Optical Channel Checker is specially designed for CWDM installation, maintenance and troubleshooting, which is able to measure and monitor power values of up to 18 CWDM channels. OCC-50 can replace high-cost Spectrometers and conduct quick and reliable measurements in all environments. Thanks for its light, compact Shineway Technologies, Inc. - Page 8 Result display in histogram and list Straightforward result display for easy understanding. Internal clock & fiber S/N editable Internal clock enables OCC-50 to save test data with time and editable fiber SN information for convenient archiving and editing. Shineway Technologies, Inc.
-
Page 9: Basic Operation
2. Basic Operation 2.1 Forward This part introduces the basic operation on OCC-50. Specific operations of each type instrument are elaborated in Chapter 3 of this manual. Please read this manual carefully for optimal operation. Should you encounter any problems during operation, you are welcome to contact the technical staff of our company or representatives. -
Page 10: 1External Interfaces
User’s Manual for OCC-50 2.2.1 INSTRUCTION INTERFACES ① OPM & OCC Optical Input:: Type FC/PC ② Power Input: 13.8V DC @1.2A ③ RS-232 Port: Program upgrade ④ USB Port: Data transfer to PC 2.2.2 Keypad Operation Power on/off Toggle between OPM interface, CWDM Channel Checker interface and histogram display 1. -
Page 11: Indicator
OCC-50 works on NiMH rechargeable battery, please make sure the battery is mounted properly before use. When battery is low, low battery indicator will appear on LCD. You can still use OCC-50 as long as its display on LCD is identifiable. Please charge as soon as possible when battery is low to ensure accurate measurement. - Page 12 User’s Manual for OCC-50 working, laser is invisible and can cause serious eye damage. Disconnect instrument from power supply before cleaning to prevent electric shock. Do not install unauthorized parts or make unauthorized adjustments on instrument. Please consult qualified professional about maintenance and repair services.
-
Page 13: Operation
Auto power off Open Delete View Set time OPM zero CWDM zero Power off About Fiber # New mark IGURE 3.2 Power on Press button and loading screen appears, entering OCC-50 module, see Figure 3.2. Shineway Technologies, Inc. - 7 -... - Page 14 User’s Manual for OCC-50 IGURE When measuring, just connect the fiber well, the power value of each channel appears, see Figure3.3 IGURE Shineway Technologies, Inc. - 8 -...
- Page 15 User’s Manual for OCC-50 Press button to switch to histogram display of power value, see Figure 3.4： IGURE Press button again to switch to OPM module, to start power measurement, see Figure 3.5 below. IGURE Shineway Technologies, Inc. - 9 -...
-
Page 16: Cwdm Module
User’s Manual for OCC-50 Press button to circularly select wavelengths in OPM interface After switching to the selected interface, press button to run the selected function. Please refer to the detailed operation instructions under each function interface below. 3.3 CWDM Module 3.3.1 “New”... -
Page 17: Open File
User’s Manual for OCC-50 IGURE 3.3.3 “Open” file Select “Open” icon on the right side of toolbar list, press button to enter the selected interface, select the file to be opened, click “OK” button, then press button. See Figure 3.8. -
Page 18: Delete File
User’s Manual for OCC-50 3.3.4 “Delete” File Select delete icon on the right side of toolbar, press button to enter delete interface, select the file to be deleted, click “OK”, then press button to delete the file. 3.3.5. “View” file Open the file first, then select “View”... -
Page 19: Reference
User’s Manual for OCC-50 3.10 IGURE 3.3.7 Reference Select “Set” icon, then press button to enter Reference Setting interface, Press button to shift the digit position to be adjusted; press button to adjust the value and press button to confirm.. Press button to switch the wavelength. -
Page 20: Cwdm Zeroing
User’s Manual for OCC-50 3.3.8 CWDM Zero Select “CWDM Zero” icon, press button to zero CWDM, see Figure 3.12, the zeroed voltage value will be shown.. Note: when perform zeroing, screw the dust cap tightly. 3.12 IGURE 3.3.9 Auto off Select “Auto off”... - Page 21 User’s Manual for OCC-50 3.13 IGURE Select “OPM Zero” icon， press button to perform zero, the zeroed power value will be shown the interface below. Note: when perform zeroing, screw the dust cap tightly. Shineway Technologies, Inc. - 15 -...
- Page 22 User’s Manual for OCC-50 3.14 IGURE Shineway Technologies, Inc. - 16 -...
-
Page 23: Maintenance And Calibration
User’s Manual for OCC-50 4. Maintenance and Calibration 4.1 Optical Interface Cleaning Optical interface must be always kept clean. Always put protective dust cap on when the unit is not in use, and keep the protective dust cap clean. 4.2 Calibration Requirements Calibration of the instrument is recommended every 3 years. - Page 24 User’s Manual for OCC-50 1000 组 Data Storage Connectivity Detector Type InGaAs Application SM fiber Range Connector FC/PC(interchangeable SC,ST) Back light Power saving Auto-off after 5 minute idle OPM Module Calibrated 850,1300,1310,1490,1550,1625 Wavelength(nm) Power Range -70~+10 (dBm) Accuracy ±0.25 dB (5%) @25℃& -10dBm(±0.5 dB@850nm) Resolution 0.01dB...
-
Page 25: Warranty Information
Unauthorized repair or modification Misuse, negligence, or accident Shineway Technologies, Inc. reserves the right to make changes to any of its products at any time without having to replace or change previously purchased units. 6.3 Warranty Registration A warranty registration card is included with the original shipment of equipment. Please take a few minutes to fill out the card and mail or fax it to the local Customer Service Center of Shineway Technologies, Inc. - Page 26 Be sure to seal the packing box with exclusive tape. Be sure to ship to your representative or agent of Shineway Technologies, Inc in a reliable way. 6.5 Contact Customer Service Please check our web site (www.shinewaytech.com) for updates to this manual and additional application information.
