Hawk AR517 Owner's Manual

E-glide electro roto commercial floor machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

HAWK ENTERPRISES OF ELKHART, INC
E-Glide Electro Roto Commercial
Floor Machine Owner's Manual
Operation
Stock No. AR517 -- 17" (120V)
AR520 -- 20" (120V)
AR517- 230 - 17" (230V)
AR520 - 230 - 20" (230V)
Care
l
l
Service
Shown with Optional
Weight Kit
AR0032-KIT
Manual No.: AR520
Rev. 02 (09-2012)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AR517 and is the answer not in the manual?

Questions and answers

Related Manuals for Hawk AR517

Summary of Contents for Hawk AR517

  • Page 1 HAWK ENTERPRISES OF ELKHART, INC E-Glide Electro Roto Commercial Floor Machine Owner’s Manual Operation Care Service Stock No. AR517 -- 17” (120V) AR520 -- 20” (120V) AR517- 230 - 17” (230V) AR520 - 230 - 20” (230V) Shown with Optional Weight Kit AR0032-KIT Manual No.: AR520...

  • Page 2: Table Of Contents

    E-Glide Electro Roto Table of Contents Page Specifications……………………………………………………………………...2 Rules for Safe Operations………………………………………………………..3 Safety Recommendations………………………………………………………..3 Grounding Instructions……………………………………………......4 III. Operating Instructions………………………………………………………….…5 Preventative Maintenance Guide................8-9 Troubleshooting Guide…………………………………………………………..10 Repair Guide…………………………………………………………….……12-14 VII. Parts List A. Base Assembly and Parts………………………………………………….…16 B. Handle Assembly and Parts………………………………………………19-20 C. Motor Assembly and Parts……………………………………… …………..18 D.

  • Page 3: Specifications

    E-Glide 17” and 20” Electro Roto Section I Owner’s Manual -- For Commercial Use -- Specifications STOCK BRUSH LOAD MODEL SIZE H.P. VOLTS NUMBER AMPS 516L AR517 17” 1 1/2 14.9 507L AR520 20” 1 1/2 14.9 AR517-230 17” 1 1/2 AR520-230 20”...

  • Page 4: Rules For Safe Operations

    E-Glide 17” and 20” Electro Roto Section II Owner’s Manual Rules For Operation RULES FOR SAFE OPERATION Give complete and undivided attention to the job at hand. 2. Never operate a roto unless handle is properly locked (See Operation Instructions). 3.

  • Page 5: Grounding Instructions

    GROUNDING INSTRUCTIONS This appliance must be grounded. If it should electrically malfunction, grounding provides a path of least resistance for electrical current to reduce the risk of electrical shock. This appliance is equipped in accordance with all local codes and ordinances. DANGER!!! Improper connection of the equipment-grounding conductor can result in a risk of electric shock.

  • Page 6: Operating Instructions

    E-Glide 17” and 20” Electro Roto Section III Owner’s Manual Operating Instructions OPERATING INSTRUCTIONS PREPARATION AND SET-UP Roto Check the roto and components to insure that they are in good operating condition. Quick Release Handle The handle of your machine can be adjusted to any comfortable work position. Simply lift the handle-locking device located on the lower handle shaft to release the lock.
  • Page 7 E-Glide 17” and 20” Electro Roto Section III Owner’s Manual Operating Instructions Solution Tank Be sure the filter is securely seated into the bottom opening inside the tank. To fill, set the shutoff valve in the closed position and the roto handle in a stand-up position, slightly offset so accidental spillage will not drop on the motor.
  • Page 8 E-Glide 17” and 20” Electro Roto Section III Owner’s Manual Operating Instructions POST OPERATION Driving Assemblies Remove the electrical plug from the wall outlet. Put the handle into the upright position. Tilt the machine back so the handle is flat on the floor and driving assembly is perpendicular to the floor.

  • Page 9: Preventative Maintenance Guide

    E-Glide 17” and 20” Electro Roto SECTION IV Owner’s Manual PREVENTIVE MAINTENANCE GUIDE This preventive maintenance guide will be helpful in keeping your roto in top operating condition to help ensure maximum usage and life. The time intervals shown (daily, weekly, monthly or quarterly), are based on a typical 8 hour day. Daily Checks Check the filter inside the bottom of the tank.

  • Page 10: Troubleshooting Guide

    E-Glide 17” and 20” Electro Roto Section V Owner’s Manual TROUBLESHOOTING GUIDE This troubleshooting guide will assist in locating a malfunction that may develop. To identify parts described here, refer to the pictures and the parts lists in the back of this manual. For a detailed description of how to repair or replace parts, see the Roto Repair Guide.
  • Page 11 E-Glide 17” and 20” Electro Roto Section V Owner’s Manual Troubleshooting Guide A swollen or disintegrated seal at the base of the plunger, especially if high concentrations of solvents are used, such as GSL, DiasasterClene, MBI, in cleaning or shampoo mixtures. FREQUENT POWER OVERLOADS –...
  • Page 12 E-Glide 17” and 20” Electro Roto Section V Owner’s Manual Troubleshooting Guide NOISES IN ROTO (Disconnect from power source before making checks.) Motor gearbox rubbing base (motor slightly shifted on mounting holes). Loosen motor mounting screws and shift away from the rubbing area. Driving assembly or brush back rubs against housing.

  • Page 13: Repair Guide

    E-Glide 17” and 20” Electro Roto Section V Owner’s Manual Troubleshooting Guide Grease Leak – leaking gasket or seals in gearbox. Noises in motor gear unit. Loading spring (finger washer) at top motor bearing out of proper position. Centrifugal or stationary switch shifted Worn coupling (excessive play of hub) Loose screws.
  • Page 14 E-Glide 17” and 20” Electro Roto Section VI Owner’s Manual Repair Manual TABLE OF CONTENTS Main Switch and Electro Valve Switch Shunt Cord or Strain Reliever Electro Valve Bumper Motor Gear Unit Remove and Replace Handle Assembly (for Base Assembly) MAIN SWITCH OR ELECTRO VALVE SWITCH, REPLACE (Disconnect from power source before making repairs.) (Refer to parts illustration of Handle Assembly.)
  • Page 15 E-Glide 17” and 20” Electro Roto Section VI Owner’s Manual Repair Guide ELECTRO VALVE, DISASSEMBLY PROCEDURE(Figures 2 & 5) (Disconnect from power source before making repairs.) (Refer to parts illustration of Electro Valve Assembly.) Remove the nut on top of the Electro Valve and lift off the housing and coil together. Unscrew and remove the sleeve assembly.
  • Page 17 Figure 1 17 & 20 INCH BASE ASSEMBLY ARAMARK 17 & 20 INCH BASE ASSEMBLY Illus. Qty. 16 inch 20 inch Description Req'd. H0057AR H0057AR NUT 3/8-16 THIN NYLOCK HP0004-BLACKAR HP0004-BLACKAR CORD HOOK BODY & CAP HP0003-BLACKAR HP0003-BLACKAR CAM LOCK ASSEMBLY S0018PAR S0018PAR CONNECTING LEG BLK...
  • Page 18 Figure 2 ARAMARK ELECTRO VALVE ASSEMBLY Illus. Qty. 16 inch 20 inch Description Req'd. 1,8,9 AR50209-KIT AR50209-KIT ELECTRO VALVE KIT COMP 2,3,6,7,10 AR0036-KIT AR0036-KIT ELECTRO VALVE HARDWARE KIT AR50209 AR50209 ELECTRO VALVE AR50261 AR50261 WASHER SS 1.5 OD ARH0120 ARH0120 NIPPLE 3/8 X 1 SS AR50280 AR50280...
  • Page 19 Figure 3 ARG0002XHD-180F ARE0030HDMG MOTOR AND GEAR BOX ASSY. GEAR BOX COMP. Illus. Qty. 16 inch 20 inch Description Req'd. ARE0030-180B ARE0030-180B TOP MOTOR BEARING ARE0030-180SS ARE0030-180SS STATIONARY SWITCH ARE0030-180CS ARE0030-180CS CENTRIFUGAL SWITCH ARE0030-180S ARE0030-180S START CAPACITOR ARE0030-180R ARE0030-180R RUN CAPACITOR ARG0002XHD-180F ARG0002XHD-180F GEAR BOX COMP.
  • Page 20 Figure 4...
  • Page 21 HANDLE ASSEMBLY COMPLETE AR50764 Illus. Qty. 16 inch 20 inch Req'd. ARH0012 ARH0012 ROLL PIN ARH0023 ARH0023 SPRING ARS0008-1P ARS0008-1P TRIGGER BLK. ARC0007 ARC0007 GRIP HANDLE BLK. ARH0021 ARH0021 STRAIN RELIEF ARH0055 ARH0055 BUTTON PLUG AR50953 -1P AR50953 -1P HANDLE CHROME PLATED ARH0013 ARH0013 INSULATION SWITCH...
  • Page 22 Figure 5 MICRO SWITCH BRACKET ASSEMBLY COMPLETE AR50964-KIT. MICRO SWITCH BKT. ASSY COMPLETE AR50964-KIT Illus. Qty. 16 inch 20 inch Description Req'd. 13-23 AR50964-KIT AR50964-KIT MICRO SWITCH BKT. ASSY. COMP. MICRO SWITCH BKT. MICRO SWITCH WIRE JUMPER MICRO SWITCHS WIRE JUMPER MAIN SWITCH /MICRO INSULATION MICRO SWITCH NUT #2-56 HEX WASHER LOCK #2 INTERNAL...

  • Page 23: Solution Tank Assembly

    Figure 6 SOLUTION TANK ASSEMBLY Illus. Qty. 16 inch 20 inch Description Req'd. AR50794 AR50794 TANK ASSEMBLY COMPLETE AR0033-KIT AR0033-KIT VALVE ASSEMBLY KIT AR0034-KIT AR0034-KIT FILTER (6 PER PACK) AR0035-KIT AR0035-KIT TANK MTG. HARDWARE KIT...
  • Page 24 Illus. Stock Description Reqd. AR50698-1 Powercord Assembly 12-3 ST x 50 Ft., Yellow AR50727 Pigtail 21” l Yellow 14-3 25 # Horse Shoe Weight AR0032-1P Optional Weight Post Kit AR0032-KIT Weight Pin Kit AR0032PIN...
  • Page 25 Weighted Diamond Pad Driver: 13” A0017WTDPD (25#) 15” 17” A0010WTDPD (46#) 20” A0011WTDPD (64#) Applix Face Top View Orbitec Diamond Driver: 13” HP0018 15” 17” HP0017 20” HP0020 Orbitec Diamond 6 Independently Ro- Top Veiw Drivers have the tating Applix Faces option of 3”, 4”, and 5”...

  • Page 26: Warranty

    ExCEPT AS TO TITLE AND MERCHANTABILITY, THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES ExPRESSED OR IMPLIED. IN NO EvENT SHALL THE MANUFACTURER BE LIABLE FOR CONSEQUENTIAL DAMAGES. Hawk Enterprises of Elkhart, Inc. 52744 Park Six Court Elkhart, IN 46514...
