Summary of Contents for Orbea Gain
- Page 1 GAIN TECHNICAL SPECIFICATIONS BLUE PAPERS GAIN TECHNICAL MANUAL...
-
Page 2: Table Of Contents
GAIN TECHNICAL SPECIFICATIONS CONTENT GEOMETRY ERGONOMY CHARACTERISTICS OPTIONS PARTS & HARDWARE CABLE ROUTING INSTRUCTIONS IWOK ONE IWOK TRIO PROTOCOL SOFTWARE EBIKEMOTION MANTEINANCE FRAME & MATERIAL WARRANTY ADITIONAL INFORMATION... -
Page 3: Geometry
GAIN TECHNICAL SPECIFICATIONS GEOMETRY SIZE 1 - SEAT TUBE (C-T) 2 - TOP TUBE (EFF) 3 - HEAD TUBE 4 - CHAINSTAY 5 - BB HEIGHT 6 - BB DROP 7 - WHEELBASE 1016 1022 1037 1051 1067 8 - HEAD ANGLE... -
Page 4: Ergonomy
GAIN TECHNICAL SPECIFICATIONS ERGONOMY SIZE CRANK STEM HANDLEBAR * The handlebar size is centre-centre. HEIGHT (cm) HEIGHT (in) SIZE <160 160-170 170-180 180-190 >190 * Estimated measurements. This result is only orientative. We can recommend the best size for you, based on your measurements, on our web:... -
Page 5: Characteristics
GAIN TECHNICAL SPECIFICATIONS CHARACTERISTICS DIRECTION 1" ⅛ SEMI-INTEGRATED BB68 THREADED FRONT DERAILLEUR C/CLAMP Ø31,8 FRONT DERAILLEUR TP/DP FD ANGLE 63º- 66º SEAT POST DIAMETER DIAM 27, 2 MM SEAT CLAMP INTERNAL DIAM 31,8 MM DROPOUT ALL ROAD E-BIKE CHAINSTAY PROTECTOR... -
Page 6: Options
GAIN TECHNICAL SPECIFICATIONS OPTIONS V-BRAKE DISC BRAKE BRAKE REAR BRAKE IS/PM+DIAMETER DISC FLAT MOUNT 140/160 DEL/TRAS (POST MOUNT C/ADAPTADOR) CALIPER BRAKE BAG OPTION IN TOP TUBE BOTTLE CAGE DT AND ST [ALL SIZES) OPTION AERO AND STANDARD BOTTLE LUGGAGE REAR LUGGAGE OPTION... - Page 7 GAIN TECHNICAL SPECIFICATIONS OPTIONS Groupsets ROAD SHIMANO SHIMANO DI2 SHIMANO DI2 DISC SRAM SRAM DISC YES (WITH DROPOUTS MODIFIED IN 57°)
-
Page 8: Parts & Hardware
GAIN TECHNICAL SPECIFICATIONS PARTS & HARDWARE X35 of eBIKEMOTION SCREEN iWOOK TRIO iWOOK ONE iWOOK ONE EXTERNAL BATTERY iWOOK TRIO CHARGING PORT INTERNAL BATTERY HEAD LIGHT REAR LIGHT MOTOR (REAR WHEEL) PAS SENSOR (RIGHT DROPOUT) PART NUMBER ORBEA DESCRIPTION PART NUMBER... - Page 9 GAIN TECHNICAL SPECIFICATIONS PARTS & HARDWARE VARIOUS & CAPS...
- Page 10 CABLE CLIP 5,5 FOR 1 CABLE 11001182 CABLE CLIP 5,5 FOR 2 CABLES 11000405 BOTTOM COVER GAIN 11200460 GUIDE FOR BATTERY GAIN 11001161 RUBBER CAP 3 MM KEYHOLE 30X10 12300019 SCREW M5X20 ISO 7380 INOX 12301058 SETSCREW M4X10 DIN 916 INOX...
-
Page 11: Cable Routing
GAIN TECHNICAL SPECIFICATIONS CABLE ROUTING MECHANICAL FRONT DERAILLEUR (INTERNAL) REAR DERAILLEUR (INTERNAL) REAR DISC BRAKE (INTERNAL) FRONT DISC BRAKE 1/ Insertion of the front and rear derailleur. - Page 12 GAIN TECHNICAL SPECIFICATIONS CABLE ROUTING X35 SYSTEM iWOOK ONE / SCREEN * iWOOK ONE OPTIONAL LIGHT * CHARGIN PORT SENSOR (right chainstay) HUB MOTOR MOTOR CABLE (LEFT CHAINSTAY) iWOOK ONE + TRIO + SCREEN CHARGIN PORT MOTOR LIGHT BATTERY X35...
- Page 13 GAIN TECHNICAL SPECIFICATIONS CABLE ROUTING X35 BATTERY CHARGING PORT PASS SENSOR DERAILLEUR DISC BRAKE MOTOR The X35 battery has 2 cables in one end (that will stay in the top part of the frame) and 3 in the opposed end.
- Page 14 GAIN TECHNICAL SPECIFICATIONS CABLE ROUTING CABLE ROUTING ON THE BASE 1/ cable clip 5,5 for 2 cables 2-3/ cable clip 5,5 for 1 cable...
- Page 15 GAIN TECHNICAL SPECIFICATIONS CABLE ROUTING P.A.S SENSOR PLACEMENT SETSCREW 1- Place de sensor in the specific whole in the inner side of the drop-out, inserting the pivot it´s housing. 2- Then, fix it with the setscrew (M4x10)
- Page 16 GAIN TECHNICAL SPECIFICATIONS CABLE ROUTING IWOC ONE CABLE ROUTING iWOOK 20 HOLE Ø STEERING TUBE LIGHT CABLE (OPTIONAL) The cable routing for the start button IWOK ONE will be done through the steering tube.
-
Page 17: Instructions
GAIN TECHNICAL SPECIFICATIONS INSTRUCTIONS INSTRUCTIONS GUIDE PLACEMENTE IN THE BATTERY BATTERY PLACEMENT IN THE FRAME iWOOK ONE + TRIO + SCREEN CHARGIN PORT MOTOR LIGHT BATTERY X35 SENSOR DOUBLE SIDED TAPE Once the guides are attached in the battery, insert... - Page 18 GAIN TECHNICAL SPECIFICATIONS INSTRUCTIONS BATTERY PLACEMENT AND COVER bottom cover 1/ Secure the battery to the frame by the points A and B with the M5x10 DIN 7380 screws and rout the pertinent cables (derailleurs and disc brake). 2/ Later, fix the bottom cover by the points C and D, using the provided M5x20 INOX (DIN 7380) and M5x25 INOX (DIN 7991) respectively.
- Page 19 GAIN TECHNICAL SPECIFICATIONS INSTRUCTIONS REAR WHEEL ASSEMBLY / DISMANTLING CONECTOR ANTI-ROTATION WASHER M12 NUT 1/ Place the wheel in the frame, making sure the power cable stays between the chainstay and seat stay (fig.1) for a easy connection later on.
- Page 20 GAIN TECHNICAL SPECIFICATIONS INSTRUCTIONS FLAT MOUNT-POST MOUNT / REAR DISC INSTALLATION FRONT REAR 1/ The rear disc brake must be installed with specific M5x6 TORX screws. (ref. 12301087)
-
Page 21: Iwok One
GAIN TECHNICAL SPECIFICATIONS IWOK ONE BUTTON OPERATING INSTRUCTIONS... - Page 22 GAIN TECHNICAL SPECIFICATIONS IWOK ONE BUTTON GENERAL LIGHT SCHEME AND MEANING...
- Page 23 GAIN TECHNICAL SPECIFICATIONS IWOK ONE BUTTON LIGTH SCHEME WHEN CHARGING...
-
Page 24: Iwok Trio
GAIN TECHNICAL SPECIFICATIONS IWOK TRIO BUTTON OPERATING INSTRUCTIONS... - Page 25 GAIN TECHNICAL SPECIFICATIONS IWOK TRIO BUTTON GENERAL LIGHT SCHEME AND MEANING...
- Page 26 GAIN TECHNICAL SPECIFICATIONS IWOK TRIO BUTTON LIGHT SCHEME WHEN CHARGING...
-
Page 27: Protocol
GAIN TECHNICAL SPECIFICATIONS PROTOCOL START PROTOCOL MOTOR PROTOCOL... - Page 28 GAIN TECHNICAL SPECIFICATIONS PROTOCOL CHARGING PROTOCOL LIGHTS PROTOCOL...
-
Page 29: Software Ebikemotion
GAIN TECHNICAL SPECIFICATIONS SOFTWARE APP FOR YOUR GAIN (find the manuals in www.ebikemotion.com) -
Page 30: Manteinance
GAIN TECHNICAL SPECIFICATIONS X35 MAINTENANCE BATTERY, POWER CABLE AND CHARGING... -
Page 31: Frame & Material
GAIN TECHNICAL SPECIFICATIONS FRAME AND MATERIAL 2) Bring your bike to your Orbea dealer for pro- Orbea frames are carefully designed to be durable, 3) Inspect your Gain before you ride AFTER A CRASH OR IMPACT efficient, and easy to maintain. Gain tubes are stiff fessional inspection. -
Page 32: Warranty
3) All the parts assembled in our bicycles are protec- ted against assembly or manufacturing defects for 2 8) In case of crashes, the Orbea warranty shall be con- sidered null and void. years, and repairs qualifying under this warranty will... -
Page 33: Additional Information
View and download photos, videos and Our dealers are experts and should be able to assist documents. you with setting up and maintaining your Orbea bicy- cle. A complete listing of Orbea dealers and distributors TWITTER content.orbea.com/us-en/ can be located on our website: www.twitter.com/Orbea/...
