- Page 1 CV9601T-T-1F Installation Manual Version 1.0 * All rights reserved ** Subject to change without notice Sena Computer – 28 rue de bel air – 49750 Chanzeaux France Tel + 33 2 41 74 13 74 Fax : + 33 2 41 74 13 75...
-
Page 2: Table Of Contents
Table of Contents IMPORTANT SAFETYINSTRUCTIONS..................... 3 FRONT PANEL DESCRIPTION ......................3 INSTALLATION............................4 ......................4 ONNECTOR AND IN DEFINITION RS232C ......................5 ONNECTION IAGRAM RS485C ......................6 ONNECTION IAGRAM TCP/IPC ......................7 ONNECTION IAGRAM ..........................8 NSTALLATION STEPS PACKINGLIST............................ -
Page 3: Important Safetyinstructions
1 Important safety instructions Don’t connect the unit to higher than 24V DC. Don’t set this product near heaters or anything that produces heat. Don’t install this product near electric motors running. Be ALWAYS careful not to short-circuit any part of the circuitry with tools like a screwdriver in hand. -
Page 4: Installation
3 Installation 4.1 Connector and Pin definition P2 description: Normally closed of lock relay. LCOM Common port of lock relay. Normally open of lock relay. Normally closed of alarm relay. ACOM Common port of alarm relay. Normally open of alarm relay. Tranceive Data-;... -
Page 5: Rs232 Connectiondiagram
J203 description: Changing IP address jumper, open is a normal working. SW2 description: This jumper is opening in normal work. When it is shorting before power on, Main unit go to download user program state. 4.2 RS232 ConnectionDiagram Sena Computer –... - Page 6 Sena Computer – 28 rue de bel air – 49750 Chanzeaux France Tel + 33 2 41 74 13 74 Fax : + 33 2 41 74 13 75 Email : info1@senaco.com...
-
Page 7: Rs485C Onnection Diagram
4.3 RS485 Connection Diagram Sena Computer – 28 rue de bel air – 49750 Chanzeaux France Tel + 33 2 41 74 13 74 Fax : + 33 2 41 74 13 75 Email : info1@senaco.com... -
Page 8: Tcp/Ipc Onnection Diagram
4.4 TCP/IP Connection Diagram Sena Computer – 28 rue de bel air – 49750 Chanzeaux France Tel + 33 2 41 74 13 74 Fax : + 33 2 41 74 13 75 Email : info1@senaco.com... -
Page 9: Installation Steps
4.5 Installation steps Step 1: Drill four holes on the Installation location as showed at mounting plate. Dimensions are as below: Step 2: Plug four plastic expansion pipe. Step 3: Install mounting plate on the Installation location. Step 4: Using 4 self tapping screws fixed mounting plate. Step 5 Wire connection. -
Page 10: Revisehistory
4 Revise history V1.0 Original Version 5 Technical support We have professionals to provide prompt, comprehensive technical support. If you have any technical questions, please contact info1@senaco.com Sena Computer – 28 rue de bel air – 49750 Chanzeaux France Tel + 33 2 41 74 13 74 Fax : + 33 2 41 74 13 75 Email : info1@senaco.com...
