Summary of Contents for EDI ED BLACK EB-105
- Page 1 ED BLACK EB-105 User Manual Ver. 1.0 www.edi-works.com Wi-Fi...
-
Page 2: Table Of Contents
Regulations for Safety Special Features CONTENTS Package Components Parts name Installation Mounts Separation & Combination Descriptions Mobile Viewer ( Android, iOS) PC Viewer Firmware Upgrading Product Specification Warranty EB-105... -
Page 3: Regulations For Safety
Please do not decompose or modify the product of one's own accord. Fire, electric shock or injury may result. For the Internal inspection and repairing, please contact the EDI customer support. Not responsible for any arbitrarily modification. Micro SD Card is a consumable. -
Page 4: Special Features
Full HD(1920 x 1080) Video 3-Axis Acceleration Sensor, Motion Sensing 1080p Full HD(1920 x 1080) 30fps. With built- in Sensor, impact sensing recording, Full HD CMOS High Sensitivity, High Quallity Motion detection recording. Special G Sensor Features High quallity 3Mega Pixel Lens Voice / Sound E ects &... -
Page 5: Package Components
Package Components Manual ED BLACK EB-105 Hex wrench Mount Use a hex wrench to ensure the Double -sided tape product is securely attacthed. Micro SD Card Cable holder clip Cigar Cable Reader (3ea) ●The items may be changed by the specific circumstances. -
Page 6: Parts Name
Power terminal Unlock Button Hex bolt Parts name Cover Micro SD Card Slot WiFi LED GPS LED Security LED Speaker REC LED MIC / FCN BUTTON Camera Lens WiFi / FORMAT BUTTON EB-105... -
Page 7: Installation
Installation 1. Remoe the "release 2. Attach the mounts 3. Push and combine the 4. Insert the Micro SD Card. paper" of the mounts. appropriately, and fix EB-105 to the mounts it with the Wrench until it cliks. once more. Please install in the bright and safe place. -
Page 8: Mounts Separation & Combination
Mounts Separation & Combination Press and hold the Unlock Button, and down and pull the Product. ●Push and combine the product to the mounts until it cliks. ●Press and hold the Unlock Button, and down and pull the product. ●Please separate and combine carefully with the upper tips. EB-105... -
Page 9: Descriptions
1. Recording Files - Separated by time and manage the files,File lists are to be scanned quickly. Descriptions - Prebuffering time : 5 sec Normal mode : From the beginning, the basic driving record mode ● Event Mode : When impact , the event record mode. ●... - Page 10 Voice & Sound E ect Guide " Provide the necessary Sound guidance to the staus of the product information. " Descriptions Power on "ED BLACK starts recording" Power off "Recording is shutting down" Upgrading "upgrade file prepared.Press the mic button long. " SD Card Formatting "Formatting the SD card"...
- Page 11 When system Memory damaged, SD Card recovery function is available Descriptions * Contact the customer support system of EDI. Regular Power mangement device. Usually, EB-105 is compatible with the power management device on the market. the specification.( 1A @ 12~ 24V ) For using the battery of the car, there is always the possibility of the discharge.
-
Page 12: Mobile Viewer ( Android, Ios)
* Via Wi-Fi, additional function will be supported continuously. For iOS * Please refer to the website for more detailed descriptions. http:// www.edi-works.com Connecting Wi-Fi 1) Find the Setting of the mobile phone. 2) Find the setting of the Wi-Fi. -
Page 13: Pc Viewer
ED BLACK PC Viewer Via the PC Viewer , you can operate belows. PC Viewer - Mac PC Viewer will be supported in future. - Image processing will be supported in future. setting items : [ video / audio / G-sensor / GPS info. / option setting / Digital Zoom /scanning frame by frame / etc. ] Insert a USB card reader into an available USB port on your PC. -
Page 14: Firmware Upgrading
Firmware Upgrade Function For continued product support, we will provide the update file periodically via customer Firmware support system. Upgrading 1) Via customer support system of website, you can find the "update.bin" file and copy the files to the top folder. 2) After power supply and normal booting, you can find the sound guidance "upgrade file prepared.Press the mic button long. -
Page 15: Product Specification
ITEM SPECIFICATION Brand Name ED BLACK Product Color / Size Black & Silver / 108.93mm x 40.6mm x 36.1mm Model Name EB-105 Speci cation Storage microSD Card (16GB / 32GB) Camera CMOS Image Sensor (2M Pixel) 142.2°(D), 118.7°(H), 63.1°(V) Viewing Angle Resolution/Frame Full HD (1920 x 1080) / Max 30fps WIFI... -
Page 16: Warranty
- This product creates a recorded video to help determine what happened during before and after the crash or event. EDI Inc. shall not take any legal responsibility for damages and losses by accidents. EB-105... - Page 17 Warranty Period The free warranty period is as below Malfunction or damage by consumer’s misuse, careless handling and intentional modifica- Warranty tion shall be attributable to customer with the paid repair even if it is under warranty. EB-105 Warranty Period Main Device 1 year of the purchase Cigar cable, Card reader, Cradle etc.
-
Page 18: Fcc
FCC ID : 2ACFS-EB-105 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. Operation is subject to the following two conditions; (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 19 ㆍReorient or relocate the receiving antenna. ㆍIncrease the separation between the equipment and receiver. ㆍConnect the equipment into an outlet on a circuit different from that to which the receiver is connected. ㆍConsult the dealer or an experienced radio/TV technician for help. Modifications not expressly approved by the manufacturer could void the user's authority to operated the equipment under FCC rules.
- Page 20 2ACFS-EB-105 MSIP-CMM-ED9-EB-105...
