Tema Telecomunicazioni AD615/S Product Manual

Analog/digital encoder for multicast audio streaming
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Products for VoIP SIP LAN networking Communications, Paging Amplifiers Systems and
Audio Applications. Zone Announcements, Night Ringer, Multicast general call,
Background music, Standard SIP call or Emergency call, SD memory with pre-recorded
messages, Relays for LAN drives.
Revision
Date
0
02/11/2017
TEMA TELECOMUNICAZIONI
"IP COMMUNICATION AND SECURITY COMPANY"
WWW.TEMATLC.IT
AD615/S
Analog/Digital Encoder
for Multicast Audio Streaming
Audio Over IP Network Series
PRODUCT MANUAL
Version HW 1.0 - Version SW 1.09m
Revision reason
Update
Prepared
MM, DP
Checked/Approved
DP, FL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AD615/S and is the answer not in the manual?

Questions and answers

Related Manuals for Tema Telecomunicazioni AD615/S

Summary of Contents for Tema Telecomunicazioni AD615/S

  • Page 1 TEMA TELECOMUNICAZIONI “IP COMMUNICATION AND SECURITY COMPANY” WWW.TEMATLC.IT AD615/S Analog/Digital Encoder for Multicast Audio Streaming Audio Over IP Network Series Products for VoIP SIP LAN networking Communications, Paging Amplifiers Systems and Audio Applications. Zone Announcements, Night Ringer, Multicast general call, Background music, Standard SIP call or Emergency call, SD memory with pre-recorded messages, Relays for LAN drives.
  • Page 2 IP PoE Multicast Encoder TEMA TELECOMUNICAZIONI DICHIARAZIONE DI CONFORMITÀ CE DECLARATION OF CONFORMITY CE We, TEMA TELECOMUNICAZIONI SRL Via C. Girardengo, 1/4 - 20161 MILANO declare under our sole responsibility that the product: Product name Encoder Multicast IP PoE Trade name...
  • Page 3 This document is property of Tema Telecomunicazioni, It is forbidden any duplication and reproduction, even partial, as well as storage on any medium without written permission of Tema Telecomunicazioni.

  • Page 4: Table Of Contents

    TEMA TELECOMUNICAZIONI INDEX PAGE PRESENTATION ............................5 FEATURES ..............................7 PACKING LIST ............................8 TECHNICAL SPECIFICATIONS ....................... 8 OPERATION ..............................9 5.1. S AD615/S ....................9 IMPLE APPLICATION WITH NCODER 5.2. A AD615/S IP-PBX ..................9 PPLICATION OF THE NCODER WITH 5.3. E AD615/S E ....................

  • Page 5: Tema Telecomunicazioni Ad615/S

    Power Supply AD615/S can be powered directly on the network LAN cable from a standard 803.af PoE injector. If the PoE power is unavailable, it is posssible to power AD615/S with a 230Vac/12Vdc-1,0A power adapter (for example the TEMA model AA-39DL plug-in, the model AA-39D1A for DIN rail, the model AA-39P4 Injector PoE).
  • Page 6 AD615/S IP PoE Multicast Encoder TEMA TELECOMUNICAZIONI “SipComStage” VoIP SIP Amplifiers-Speakers Products and Accessories of the AD600 series AD630 IP-SIP PoE 25W Horn Speaker AD330/xx Are available Speakers of with 40W internal amplifier (2x20W) IP65 different power, Horns and Loudspeakers protection.

  • Page 7: Features

    Integration with the local LAN, 100BaseT Ethernet LAN port with RJ45 connector • Integrated 802.af PoE, a single UTP cable for connection • Extremely compact dimensions 74x58x25 mm • Wall mounting, table/shelf and DIN rail AD615/S - views and dimensions MAS-AD615-S-REV00EN Page 7 of 23...

  • Page 8: Packing List

    Connection SIP Server (IP-PBX) or P2P (Peer To Peer) Protocols SIP 2.0, RFC 3261 Audio communication Monodirectional, from AD615/S to receiver devices Bandwidth 80Hz – 20kHz RTP Multicast audio Streaming G.711 a/µ-Law, G.722, Linear 16kHz, 24kHz, 32kHz External audio input Stereo 3.5 mm stereo jack connector.

  • Page 9: Operation

    With the optional microphone base, the operator who has to launch warning messages will operate directly on the table microphone base and no longer by the AD615/S system lever. The microphone output volume is easily adjustable with a trimmer located on the left side of the AD615/S (to better suit the various types of electret microphones).

  • Page 10: Extended Ad615/S Encoder Application

    Starting from a musical sound source like a CD player or other, the analog signal enters the audio input jack of the AD615/S (the one used for the ambient music broadcast). The signal must be of "line" level like a typical output of a non-amplified stereo player.

  • Page 11: Operating Modes

    To get a continuous service of ambient music you will need to have a second AD615/S in order to dedicate a system for the transmission of music and the other to the transmission of the announcement messages, because with just one system the music channel will be interrupted when a microphone announcement is being broadcasted.

  • Page 12: Multicast Audio Streaming Installation

    Improper use of this output will permanently damage the unit. RJ45 LAN Port AD615/S requires a LAN cable to connect to the network. If the port cable has also PoE, it will not be necessary to supply the module with other power sources (Recommended solution).
  • Page 13 Is the three-position lever that controls the transmission of audio signals over the LAN network, encoded by AD615/S and sent in the selected protocol by the system parameters. A LED is located above each input jack. Red for the microphone and green for the audio input from the cable. Turns on when audio transmission is selected from either of the two ports.

  • Page 14: Programming

    The default IP address of AD615/S is "192.168.0.10". Remember that in order to successfully connect to the web interface of AD615/S, it is necessary that, in the IP addresses configuration of your PC, is present the subnet 192.168.0.x, where "x" is any number between 1 and 254 and different from 10.

  • Page 15: Access To Programming

    Any changes do not require restarting the device (except the change of IP address, and the software update). The installed software is shared by other Tema AD600 platforms, so on the AD615/S device used as "ENCODER MULTICAST" many of the features that can be found in the configuration windows are not implemented or have no utility.

  • Page 16: Network Parameters

    Subnet mask: indicate the subnet mask to be assigned to AD615/S. • Default gateway: indicate the gateway that can enable AD615/S to access to internet. • Primary and secondary DNS server: indicate the addresses of two DNS servers you want to use to resolve IP addresses.

  • Page 17: General Parameters

    It is possible to choose between G711 (the lowest) quality and L16 at 32kHz (the highest) quality. Obviously a best quality matches a greater bandwidth. The selected codec in AD615/S in the above window will be the same for the background music stream as well as for the stream output of a voice announcement from the microphone.

  • Page 18: Call Buttons

    The only purpose of this window (normally used to associate a number to call for each device button) is to choose the Multicast address to match the two stream channels managed by AD615/S, the one of the external music source and the one of the microphone.

  • Page 19: Maintenance

    AD615/S IP PoE Multicast Encoder TEMA TELECOMUNICAZIONI 9. MAINTENANCE 9.1. System On this page it is possible to check the current firmware version, update software, and backup / restore the system configuration: • MAC address: is the physical address assigned to the network interface.

  • Page 20: Login Credentials

    AD615/S IP PoE Multicast Encoder TEMA TELECOMUNICAZIONI 9.2. Login credentials By default, the user name and password for access to the configuration are master/master (lowercase). It is not possible to have more than one user (there are not hierarchical levels of programming), but it is possible to change the login credentials.

  • Page 21: Appendixes

    For example, it can play an audio file. The file, of any duration and format managed by the program, can be an announcement or a music compilation to be sent to the AD615/S Encoder system. AD615/S will encode it according to the selected algorithm and codec and make it available on a programmed Multicast channel.

  • Page 22: Appendix 2: Cabling Of Autp Rj45 Network Cable According To The Standard Eia568B

    AD615/S IP PoE Multicast Encoder TEMA TELECOMUNICAZIONI 10.2. Appendix 2: Cabling of a UTP RJ45 network cable according to the standard EIA568B Signal Connector 1 Connector 2 White/Orange White/Orange Orange Orange White/Green Bianco/Green PoE- Blue Blue PoE- White/Blue White/Blue Green...
  • Page 23 AD615/S IP PoE Multicast Encoder TEMA TELECOMUNICAZIONI Notes MAS-AD615-S-REV00EN Page 23 of 23...
