Summary of Contents for SINNOR S500
- Page 1 Handheld Pulse Oximeter S500 HANDHELD PULSE OXIMETER UER’S MANUAL VER 1.0 2013/8 Copy right reserved by SINNOR Instruments, Inc. SINNOR Instruments, Inc.
- Page 2 S500 Handheld Pulse Oximeter Instructions This manual provides the instructions necessary to operate Pulse Oximeter (hereinafter called as the Oximeter) in accordance with its function and intended use. Observance of this manual is a prerequisite and correct operation, and ensures patient and operator safety.
-
Page 3: Chapter 1 Safety Information
S500 Handheld Pulse Oximeter Chapter 1 Safety Information The safety statements presented in this chapter refer to the basic safety information that the operator of the oximeter shall pay attention to and abide by, There are additional safety statements in other chapters or sections, which may be the same as or similar to the followings, or specific to the operations. - Page 4 S500 Handheld Pulse Oximeter 1.2 Cautions CAUTION The oximeter is a commonly sealed device. Keep its surface dry and clean, and prevent any liquid from infiltrating it. The device should be appropriately placed. Keep it from falling, strong vibration or other mechanical damage.
-
Page 5: Chapter 2 General
S500 Handheld Pulse Oximeter Chapter 2 General 2.1 Introduction The oximeter is a non-invasive, handheld patient Oximeter. It operates on alkaline or rechargeable battery power supply. It is compact, small, light, and easy for learning and handling. It is suitable for monitoring adult and child patients. It is widely used in the hospital’s operation... - Page 6 S500 Handheld Pulse Oximeter Figure 2-1 Front Panel Figure 2-2 Back Panel Figure 2-3 Top Side Panel Figure 2-4 Right Side Panel Table 2-1 Appearance description Description Remarks LCD display It displays test result& information, as described in chapter 4.
-
Page 7: Chapter 3 Installation
S500 Handheld Pulse Oximeter It changes the parameter along up direction. UP button It confirms the selection parameter and exit the submenu. EXIT button It changes the parameter along down direction. DOWN button Speaker It ring the alarm sound when the test value beyond the limit... -
Page 8: Chapter 4 Display And Operation
S500 Handheld Pulse Oximeter Chapter 4 Display and Operation The screen of the Oximeter (Display Area) can display the monitoring parameters. The buttons on the front panel operate the Oximeter below this screen. For button details, please refer to figure 2-1 and table 2-1. - Page 9 S500 Handheld Pulse Oximeter Figure 4-1 Parameter monitoring interface 4.2.2 Description of Displayed Information Table 4-1 Description of displayed information on the monitoring screen Description Remarks Plethysmogram It displays plethysmogram of pulse rate SpO2 It displays SpO2 value and is refreshed every second...
- Page 10 S500 Handheld Pulse Oximeter Figure 4.4.1 main menu 4.4.2 The user can use direction & button to change the setting item in this sound setup submenu, Press the button for parameter setting. Use & button to increase or decrease the value of parameter. Then press button to confirm the parameter setting and return to the submenu.
- Page 11 S500 Handheld Pulse Oximeter Figure 4.4.3 Alarm setup menu Note: When you select the different patient type, The alarm limit value will change according to patient type. 4.4.4 The user can use & button to change the setting item in this time setup submenu, Press the button for parameter setting.
- Page 12 S500 Handheld Pulse Oximeter Figure 4.4.5.1 Record setup menu If the user selects the new item at the ID submenu, you can see the interface as figure 4.4.5.2. Use & button to move the cursor crosswise, also use button to move the cursor lengthwise.
- Page 13 S500 Handheld Pulse Oximeter Figure 4.4.6 System setup menu 4.4.7 The user can use & button to change the setting item in this file system setup submenu, Press the button for parameter setting. Use & button to increase or decrease the value of parameter. Then Press button to confirm the parameter setting.
- Page 14 S500 Handheld Pulse Oximeter Figure 4.4.7.1 File system View interface Note: 1. When the record is setting to on situation, the oximeter begins to record the testing result (SpO2&PR), the maximum record will up to 360 hours. 2. The user also can upload the storage data through USB port to the computer, and it also can review the data with software in PC.
-
Page 15: Chapter 5 Spo2 Monitoring
S500 Handheld Pulse Oximeter Chapter 5 SpO2 Monitoring 5.1 Measurement principle SpO2 plethysmogram measurement is employed to determine the oxygen saturation of hemoglobin in the arterial blood. The SpO2 parameter can also provide a pulse rate signal and pulse strength. - Page 16 S500 Handheld Pulse Oximeter Make sure to insert the finger to a suitable depth into the sensor so that the fingernail is just opposite to the light emitted from the sensor. To acquire accurate results, please read data until the sensor is steadily placed.
- Page 17 S500 Handheld Pulse Oximeter As with any medical equipment, carefully route patient cabling to reduce the possibility of patient entanglement or strangulation. Cables of electrical surgical equipment should not be winded around that of the SpO2 sensor. Do not put the sensor on extremities with arterial catheter or venous syringe.
-
Page 18: Chapter 6 Body Temperature Monitoring (Optional)
S500 Handheld Pulse Oximeter Chapter 6 Body Temperature Monitoring (Optional) Measurement Steps You can plug the probe directly into the monitor with a reusable TEMP probe and apply the TEMP probe securely to the patient. Then switch on the machine and make testament. -
Page 19: Chapter 7 Data Transfer Procedure
S500 Handheld Pulse Oximeter Chapter 7 Data Transfer Procedure: Connecting the USB line from the machine to the computer after switching off the pulse oximeter. It will enter into transfer mode after switching on the machine again. The signal of USB will show in the LCD display, but not measure the data. - Page 20 S500 Handheld Pulse Oximeter Failure on the part of the responsible hospital or institution employing the use of the monitoring equipment to implement a satisfactory maintenance schedule may cause undue equipment failure and possible health hazard. The safety inspection or maintenance, which requires opening the oximeter housing, must be performed by trained and authorized personnel only.
- Page 21 S500 Handheld Pulse Oximeter ALWAYS wipe off all the cleaning solution with a dry cloth after cleaning and dry the Oximeter in the air. Never dry the Oximeter in violent sunshine or toast it under high temperature. If the Oximeter is polluted by chemical substance, the users should handle it effectively according to the properties of the chemical substance.
-
Page 22: Chapter 9 Packing List And Accessories
S500 Handheld Pulse Oximeter Chapter 9 Packing List and Accessories Standard Packing List Pulse oximeter main unit 1pcs Adult finger SpO2 sensor 1pcs USB line 1pcs The operator’s manual 1pcs Optical disk 1pcs Optional accessory Child finger/toe SpO2 sensor 1pcs... -
Page 23: Appendix A Specifications
S500 Handheld Pulse Oximeter Appendix a Specifications General Monitoring Parameters: SpO2\PR\Body temperature (Optional) Signal sockets: SpO2 socket\USB socket\ Temperature sensor socket. Display screen Type: 2.8 inch TFT LCD Display area: 58mm×43mm Size 133mm (L) ×62mm (w) ×22mm (H) Weight 90g (not include probes and battery) Electrical specifications Working voltage: DC4.0V-6.0V or 3.5V-4.2V Li battery. - Page 24 S500 Handheld Pulse Oximeter Low perfusion Condition ≤0.3% Temperature Channel 18 ~ 45 C Measuring and Alarm Range Resolution 0.1C 0.1C Accuracy Actualization interval about 1 Sec. Average Time Constant < 10 Sec. SINNOR Instruments, Inc.
