Ultramax UXDV-3HD Quick Start Manual

Full high definition digital video camera

Download this manual

IMPORTANT

: The DV Camera MUST be set to ALWAYS ON MODE and it must be

POWER ON before inserted to the Underwater DV Housing

Setting the DV Camera to ALWAYS-ON MODE :

Step 1

Flip out the LCD panel (or press

the ON/OFF power button) to turn

on the DV Camera

Step 3

Choose SETTING menu, press to enter

Step 5

Move Joystick to highlight "Off", press to

activate

ULTRAMAX UXDV-3HD

FULL High Definition Digital Video Camera

QUICK START GUIDE

Step 2

Flip the LCD Panel clockwise until it faces

outwards

Step 4

Highlight "Auto off", press to enter

Step 6

Move Joystick leftwards back to MODE

menu. Press camera "Shutter" or "Video

Recording" button to standby mode

Need help?

Do you have a question about the UXDV-3HD and is the answer not in the manual?

Page 1 ULTRAMAX UXDV-3HD FULL High Definition Digital Video Camera QUICK START GUIDE IMPORTANT : The DV Camera MUST be set to ALWAYS ON MODE and it must be POWER ON before inserted to the Underwater DV Housing Setting the DV Camera to ALWAYS-ON MODE :...
Page 2 Set the DV Camera to Diving Mode before Installing to Underwater Housing : The Special Diving Mode program installed in the DV Camera corrects the Mirrored Image showed onto the Reflected Viewing Panel of the Underwater Housing which provides Normal Views convenience for the user.
Page 3 Mounting and Installing the DV Camera to Underwater Housing: Step 1 Position the “Support Tray” to the mounting hole of the DV Camera, tighten the screw using the hexagon key provided. Make sure “Support Tray” is straightly aligned with the DV Camera Step 2 Step 3...
Page 4 Step 6 Clamp and slide the Locking Latch to securely close and lock the housing caseback. Step 7 Slide and push the Safety Lock upwards to “ Lock “ position to prevent accidental opening of the caseback underwater Step 8 Flip the external Mirror View Panel outwards until it stops at approx 40 degree position Step 9 Push the RED Locking Knob upwards to secure the Mirror View Panel in place and prevent it...
