Pure Sine Wave Inverter
S400VA / S1000VA / S1500VA
User Manual
1.
Introduction
The Vu Phong Sine Wave series models are used in a wide range
of applications. It will operate most televisions, fans, lamps,
personal computers, small appliances and tools.
The inverter must have a greater power rating than the
load it provides power to.
To get the most out of the power inverter, it must be installed
and used properly.
Please read the instructions in this manual before installing and
using this model.
www.vuphong.vn|www.vuphong.asia

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S400VA and is the answer not in the manual?

Questions and answers

Related Manuals for Vu Phong S400VA

Summary of Contents for Vu Phong S400VA

  • Page 1 S400VA / S1000VA / S1500VA User Manual Introduction The Vu Phong Sine Wave series models are used in a wide range of applications. It will operate most televisions, fans, lamps, personal computers, small appliances and tools. The inverter must have a greater power rating than the load it provides power to.

  • Page 2: Specifications

    S400VA / S1000VA / S1500VA Specifications S400VA S1000VA S1500 VA Input Voltage 12V DC Output Voltage 230V AC +/- 5%; 50Hz Rated Output 320W 800W 1200W Power Max. Output 400VA 1000VA 1500VA Power Peak Surge 600VA 2000VA 3000VA Power (5s)

  • Page 3: Back Side

    Red is positive; Black / Blue is negative. 3.2. Front side AC outlets: Connect to 220V loads Green Power switch (S400VA / S1500VA): Energy saving enable. Turn the switch ON to reduce the consumption of the battery when AC output is without load.

  • Page 4: Where To Install

    S400VA / S1000VA / S1500VA Empty: empty battery / loose connection (red)  S1500VA (1): load detection (green) (2): Green Power mode ON (green) (3): over input voltage (red) (4): load short circuit (red) (5): over load (red) (6): normal operation (green)
  • Page 5 Keep the product away from children 4.2. Hook-up and testing a) Unpack and inspect your Vu Phong Inverter, check to see that the power switch is in the OFF position. b) Connect the Red cable of the inverter to the positive (+) terminal of the battery and the Black / Blue cable to the negative (-) terminal of the battery.

  • Page 6: Operation

    S400VA / S1000VA / S1500VA d) Set the power inverter switch to the ON position. The fan runs and the LED “Normal” lights. Turn the test load on. The inverter should supply power to the load. Notice! Please do not connect the AC output of the invert to the grid.
  • Page 7 S400VA / S1000VA / S1500VA ventilation, make sure ventilation openings in inverter are not obstructed. Then switch the ON/OFF switch back to ON. Short circuit / wiring error/ very high power load: The fault indicator(s) also indicates that the power inverter has shut itself down because its output circuit has been short circuited or drastically overloaded.

  • Page 8: Operating Limits

    S400VA / S1000VA / S1500VA Operating limits 7.1 Power output The inverter will operate most AC loads within its power rating. Some motor-operated equipment require very high surge currents to start. The power inverter may not be able to start some of them even though their rated current draw is within the power inverter.
