Front Runner TENT031 Installation Manual

Roof top tent

Hide thumbs

Table Of Contents

ENG

Roof top tent

TENT031

220 min

READ ME FIRST!

Thank you for purchasing a Front Runner Roof Top Tent.

Before you start, take a moment to familiarize yourself with these Fitting Instructions and the components received.

Refer to Page 2 for a list of all the components, quantities and tools required.

IMPORTANT WARNING!

IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD

RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT

RUNNER PRODUCTS TO YOUR VEHICLE. CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND

DAMAGE. THEREFORE YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO

INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY

FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.

TENT031_REV_A01_MV

Table of Contents

Need help?

Do you have a question about the TENT031 and is the answer not in the manual?

Questions and answers

Summary of Contents for Front Runner TENT031

Page 1 IMPORTANT WARNING! IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT RUNNER PRODUCTS TO YOUR VEHICLE.
Page 2 GET ORGANIZED Here is what you are looking at for TENT031 IN THE BOX IN THE BOX IN THE BOX CONTINUED IN THE BOX Mounting Channel (TENT038) Tent Cover (TENT035) Self Tapping Screw Ladder (TENT025) U-Shaped Support Tube (TENT048) Tent Base...
Page 3 If you're using a Front Runner rack, be sure you have the appropriate Front Runner tent mount kit (TBMK001 - Low mount kit, TBMK004 - High mount kit or TBMK008 - Quick release mount kit).
Page 4 Securely mount the channels to the base with the Hex bolts and Washers (Item 15 and 17). Now use the self tapping screws (Item19) to secure the ends of the mounting channels to the bases aluminum edging. 10mm TENT031_REV_A01_MV © COPYRIGHT 2017 FRONT RUNNER VEHICLE OUTFITTERS...
Page 5 Secure as shown. If mounting to a Front Runner Rack refer to the ﬁtting instructions supplied with your Front Runner Tent Mount Kit. Fit the plastic end caps to the mounting channel ends (Item 17).
Page 6 IF A LONGER LADDER IS NEEDED FOR EXTREMELY HIGH VEHICLES, PLEASE ORDER A LADDER EXTENSION. (TENT022) Fit the tent cover by sliding the beaded edge into the aluminum channel of the tent base as shown. TENT031_REV_A01_MV © COPYRIGHT 2017 FRONT RUNNER VEHICLE OUTFITTERS...
Page 7 Note: The window bows will maintain some curve after the ﬁrst use - no worries! This is normal. The steel bows can be stored in their bag, under the mattress when not in use. TENT031_REV_A01_MV © COPYRIGHT 2017 FRONT RUNNER VEHICLE OUTFITTERS...
Page 8 Congratulations. You did it. Take a step back and admire your work! INSTALL OTHER VEHICLE AND RACK ACCESSORIES Now's the time to visit your favorite Front Runner Dealer in person or Online. TENT031_REV_A01_MV © COPYRIGHT 2017 FRONT RUNNER VEHICLE OUTFITTERS...
