Dragon Wholesaling Family EVO Installation Instructions Manual

Document name: 2010 EN Instrukcja Family EVO 2,11 | date: 08.07.2010 | page: 1 / 11
Terrace awning Family EVO
1.1. Safety Tips
1.2. Content of delivery.
● 1x awning: Family EVO
● Ordered types of monting brackets (wall
Dimensions (cm)
Depth: 150 - 200
Depth: 250 - 350
● 1x "installation and adjustment instructions"
● 1x "use and maintenance manual, guarantee"
● 1x "instruction for connection and adjustment of the electric motor" (for awnings with electric motor)
● 1x "instruction for remote control and/or weather sensor" (for awnings with this equiptment)
● 1x crank (for awnings with manual drive or NHK*)
● 1x cord for the test run and/or programming the engine (additionally ordered)
1.3. General guidlines
1.4. Qualifications of the specialized service.
● complies with safety guidelines provided/required by local law
● Is qualified and has experience in using ladders and/or scaffolding
● takes responsibility of transport and proper storing
● has experience in using tools and equiptment
● has a permition/license for usage of montage methods, tools and equiptment
Installation instructions and regulations
CAUTION!
To ensure safety it is important to read this instruction cafefully.
This instruction of montage should be kept, and in case of reselling the awning,
passed to another user.
Information
● It is required to take safety measures to prevent accident while working at
heights.
● A ladder or scaffolding shall be so positioned as to ensure its stability during
use.
● Iit is necessary to possess required qualifications to work at heights.
Width: 200 - 360
2
3
CAUTION!
Montage of the awning should be performed by a specialised company. Depending on
the conditions of the monting surface, proper means/tools should be used for
montage. Company/personel performing the montage is responsible for proper
selection of montage method and tools.
Information
The awning is supplied without montage materials. The components of this awning,
conform with the requirement and rules of technique. Changes in construction is
possible only by DRAGON, Korgul, Prochowski Sp. J. premission.
Installation and adjustment instructions
Terrace awning Family EVO
and ceiling
Width: 361 - 470
3
3
) an amount consistent with table:
Width: 471 - 520 Width: 521 - 610
3
4
4
4
