- Page 1 EGG COOKER MODEL EC14PB-240V Installation and Operation Instructions 2M-Z11369 Rev. - 2/1/08 EC14PB-240V...
-
Page 2: Safety Symbol
RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine Star factory supplied parts relieves the manufacturer of all liability. Star reserves the right to change specifi cations and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment. -
Page 3: General Specifications
(B) Depth Inches (C) Closed Inches (D) Open Inches (E) Grill Width Model No Grill Surface (cm) (cm) (cm) (cm) Inches (cm) EC14PB-240V Alum. 23.22 (59) 18.76 (47.7) 8.82 (22.4) 23.97 (60.9) 15.25 (38.7) Approximate Weight Model No Voltage Wattage... -
Page 4: General Installation Data
GENERAL INSTALLATION DATA This equipment is designed and sold for commercial use only by personnel trained and experienced in its operation and is not sold for consumer use in and around the home nor for use directly by the general public in food service locations. CAUTION Before using your new equipment, read and understand all the instructions &... - Page 5 SEASONING THE COOKING SURFACES FIRST TIME SEASONING Follow your company/corporate guidelines for seasoning cooking surfaces. or . Bring the grill to 00°F (9°C) and leave it on while doing the next two steps. . Brush the cooking surfaces with a SALT-FREE release agent. If using an aerosol agent, first apply into a cup and then brush onto cooking surface.
- Page 6 OPERATING INSTRUCTIONS . Turn unit on by placing power switch in Power "ON" position. The "Heat On" indicator, Switch program number indicator and display will flash indicating unit is heating. When the preset temperature is reached, the Heat On Temp Indicator, display and program light indicator Button will stop flashing followed by 3 beeps.
- Page 7 PRESET TIME AND TEMPERATURE This 0V unit comes with an LED Timer Controller, which has four () individual program settings. All of these programs come preset to 00°F at :00 minutes from the factory. By following the steps below you can change a program to fit your specific needs, giving you more flexibility in your menu offerings.
-
Page 8: Maintenance
MAINTENANCE MONTHLY INSPECTION Check all bolts/screws and tighten if necessary. CLEANING Begin cleaning procedure by using the operating procedures within your organization, or follow the steps below: . If particles adhere to the cooking surface during the day, scrape them off with a spatula. NOTE: It is best not to let food residue onto the grill, as food build-up on the grill will increase sticking and smoking. - Page 9 LIMITED EQUIPMENT WARRANTY All workmanship and material in Star products have a one (1) year limited warranty on parts & labor in the United States and Canada. Such warranty is limited to the original purchaser only and shall be effective from the date the equipment is placed in service. Star's obligation under this warranty is limited to the repair of defects without charge, by the factory authorized service agency or one of its sub-agencies.
- Page 10 FOR REFERENCE WIRING DIAGRAM IS SHOWN AS UNIT IS ASSEMBLED WITH THE BOTTOM PLATE REMOVED. THE TOP DESCRIPTIONS ARE THEIR POSITIONS WHEN UPRIGHT. WIRE DIAGRAM, 240V, 2150 WATT (D9-Z11369 CONTROLLER ONLY) STAR MANUFACTURING INTERNATIONAL, INC. MODEL: EG14PB-240V SK2343 REV. - 01/15/08...
- Page 11 SOME ITEMS ARE INCLUDED FOR ILLUSTRATIVE PURPOSES ONLY AND IN CERTAIN INSTANCES MAY NOT BE AVAILABLE This drawing contains information confidential to Star Manufacturing International, Inc. No reproduction or disclosure of its contents is permitted. STAR MANUFACTURING INTERNATIONAL, INC. MODEL: EC14PB-240V SK2345 REV.
-
Page 12: Parts List
RTD PROBE - 8" LONG WIRE A ECPB-0V IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE INCLUDE MODEL AND SERIAL NUMBER Some items are included for illustrative purposes only and in certain instances may not be available. Star Manufacturing International, Inc.
