Summary of Contents for SpiderCloud SCRN-310
- Page 1 ® SpiderCloud Radio Node - SCRN-310 Hardware Installation Guide ® Part number: DOC-SCRN-310-HW-01, Rev. 0.1 DRAFT Published: February 2014...
- Page 2 SpiderCloud Wireless. Customer agrees to implement reasonable security measures to protect such trade secrets and copyrighted material at least to the extent that Customer protects its own information of a similar nature.
-
Page 3: Table Of Contents
The SpiderCloud Documentation Set ........ - Page 4 Contents SpiderCloud Wireless, Inc.
-
Page 5: About This Manual
LTE services. It is easy to install and connects to the existing enterprise LAN using standard Ethernet cabling or to a dedicated LAN infrastructure deployed for use by the operator. SCRN-310 radio nodes are managed by the SpiderCloud SCSN-9000 services node access controller, typically installed in the enterprise DMZ. -
Page 6: Radio Node Features
SpiderCloud Radio Node - SCRN-310 Hardware Installation Guide Radio Node Features The radio node supports the following features: • Complete enterprise mobility using licensed 3G and LTE spectrum • Self Organizing Network (SON) capabilities for autonomous setup, operation, and management •... -
Page 7: System Specifications
SpiderCloud Wireless currently provides two versions of the SCRN-310 for operation in the following UMTS and LTE band combinations. Note that the SCRN-310 hardware is also capable of supporting two carriers of LTE (feature available in a future software upgrade). -
Page 8: Power
R&TTE (Directive 1999/5/EC on R&TTE) • CB certification as per IEC 60950-1:2011 Radio Node Models Table 1 displays the orderable configurations of the SCRN-310 radio node: Table 1: SCRN-310 Radio Node Configurations Radio Node Model Description SCRN-310-0701 Dual-mode with internal antennas: LTE Band 7, UMTS Band 1... -
Page 9: Antennas
The radio node includes four integrated antennas: two UMTS antennas and two LTE antennas. The UMTS radio operates in 1x2 mode with receive diversity. The LTE radio operates in 2x2 mode with MIMO. To maximize antenna transmission, SpiderCloud Wireless recommends not installing the radio node Tip: inside a metallic enclosure. -
Page 10: Input Power
SpiderCloud Radio Node - SCRN-310 Hardware Installation Guide Input Power The radio node receives its power from a standard PoE+ switch (typical) or injector. The radio node is fully compliant with the IEEE 802.3at Power Over Ethernet (PoE+) specification. Per IEEE 802.3at, use standard Cat 5e or better twisted-pair cable with a maximum length restriction of 100 meters (328 feet) for PoE+. -
Page 11: Select The Radio Node Location
SpiderCloud Radio Node - SCRN-310 Hardware Installation Guide Step 3 Connect an Ethernet cable from the injector’s OUT port to the radio node. The injector will now inject power onto a pair of wire pairs in the cable. The radio node will expect a nominal 48V DC input (57V max) from a typical PoE+ injector. -
Page 12: Installation And Mount Bracket Assembly
Installation and Mount Bracket Assembly The radio node has a pedestal base that slides into a long bracket for ceiling or wall mounting. SpiderCloud Wireless pre-bolts the pedestal base onto the extrusion plate on the radio node. However you must attach... -
Page 13: Bracket Mounting And Cabling Guidelines
M8 studding. Installing the Radio Node The radio node receives its power source over powered Ethernet. If your wiring closet does not have existing PoE+ equipment, SpiderCloud Wireless recommends a PoE+ power injector for the radio node. See section Input Power on page 10. - Page 14 SpiderCloud Radio Node - SCRN-310 Hardware Installation Guide Transmit Side Figure 10 Attach the Mount Bracket Step 2 Insert the RJ-45 connector into the Ethernet port as shown in Figure 13. Route the Ethernet cable through the cable guides and pedestal base cable opening and through the...
