- Page 1 Bluetooth Barcode Scanner BS03-B User’s Manual...
- Page 2 BS03-B Bluetooth scanner is a handheld barcode recognition device based on the international standard Bluetooth protocol (HID and SPP). It is used mainly with portable devices such as mobile phone, tablet and PC. Compared with the traditional corded equipment, BS03-B is more convenient, fast and applicable.
-
Page 3: Chapter I Inspection & Installation
Bluetooth Barcode Scanner BS03-B User’s Manual After-sale Service and Warranty The Bluetooth Scanner is warranted for a period of 12 months from the delivery date and the accessories 3 months. For maintenance, please send the scanner back to factory or to appointed partners. -
Page 4: Chapter Ii Quick Guide
Bluetooth Barcode Scanner BS03-B User’s Manual Chapter II Quick Guide 2.1 Connect with Bluetooth devices (HID and SIP supported) 1) Make sure that the device supports HID and SIP protocol; 2) With the scanner off, press and hold the trigger for 5 seconds till two beep tones sounded to enter the configuration status. - Page 5 Bluetooth Barcode Scanner BS03-B User’s Manual 5) Scan the "Save Settings" barcode to reboot the scanner and start pairing; Save Settings 6） Open the Bluetooth communication of the terminal device, select BS03-BT in the Add New Device Wizard; 7）Configuring device;...
- Page 6 Bluetooth Barcode Scanner BS03-B User’s Manual 8）Device added successfully;...
- Page 7 Bluetooth Barcode Scanner BS03-B User’s Manual 9) Open a text processor (eg. Notepad, WordPad, word) on the terminal device and start reading barcode with the Bluetooth scanner. Data scanned is shown in a simulated keyboard input mode. Note: if SPP protocol is specified, a software other than the common text processor (eg. Notepad, WordPad, word) is asked to acquire data through the serial port.
- Page 8 Bluetooth Barcode Scanner BS03-B User’s Manual Charper III Technical Parameters 3.1 Physical 1) Dimension: 140mm(H)*78mm(D)*58(W) 2) Weight：212g (with battery) 3) Battery：1500mAh Polymer Lithium-ion Battery 4) Charging Time：4.5 hours 3.2 Performance 1) Light Source: 650nm Laser 2) Scanning Angle: elevation±65°，inclination±60° 3) Resolution: 0.1mm（Min.）...
- Page 9 Bluetooth Barcode Scanner BS03-B User’s Manual 6) Transmission Distance：300M (open area) 3.5 Charging 1) Input: AC 100-240V, 50/60Hz, 0.3A 2) Output: DC5V, 1000mA 3) Interface: Min-USB 4) Certification: 3C 3.6 Safety 1) Electrical equipment safety: UL60950-1,CSA C22.2 No. 60950-1, EN 60950-1 / IEC 60950-1 2) Laser safety：EN 60825-1,IEC 60825-1,21CFR1040.10, CDRH Class II, IEC Class 2...
