- Page 1 INSTALLATION GUIDE Endline Isodrive System 1350 www.schweigen.com.au 02.2018 / V1.0...
-
Page 2: Welcome
Welcome Thank you for purchasing your new Schweigen Endline Isodrive system. To get the maximum output from the Isodrive 1350 motor, please read through this guide before use and installation. This guide contains important information on the correct use and maintenance of the unit, as well as important safety notes. -
Page 3: Table Of Contents
5. Flexible Ducting Installation Flexible Ducting __________________________________________________________________ 15 Shallow Space ___________________________________________________________________ 15 Important Note __________________________________________________________________ 15 Securing Flexible Duct _____________________________________________________________ 16 6. Parts List Parts List for Endline Isodrive 1350 Motor _______________________________________________17 7. Maintenance Cleaning ________________________________________________________________________ 18 8. Specifications/Warranty/Disclaimer ________________________________________________________ 18 Page 3... -
Page 4: Your Safety
It is dangerous to modify any part of this appliance. Do not install Isodrive motor to a non-Schweigen Modification of any kind, will immediately void the and/or non-silent rangehood. If you fail to do so, your warranty. -
Page 5: Motor Features
1350m than 200mm flexi ducting would result in a Schweigen recommends a length of 4 to 6 metres loss of airflow and it is not recommended. of flexi ducting, with at least 1 to 2 bends for optimal •... -
Page 6: Minimum Mounting Height
Any installation problem must be reported to Schweigen. Call outs relating to incorrect installation will result in a service fee direct to the customer. Schweigen takes no responsibility for problems caused by faulty installation, this may void warranty. -
Page 7: Description
3. Description Endline Isodrive System 1350 Included in the box: Isodrive 1350 motor + housing Approx. 5 metre, 10amp cable and standard male plug Flexible ducting Approx. 6 metres, 200mm (210mm OD ) diameter Bell-mouth adopter ring 200mm Back Draught Shutter Not included in the box: Optional Accessories 5. -
Page 8: Installation Overview
Wall Installation cuts (See Fig.3, pg.12); if you have less than 40mm of depth in the wall aperture — or the wall 1. Remove the Endline Isodrive 1350 Motor System requires extra stability for the motor housing to from the packaging. - Page 9 Note: If you require extra support to stabilise the NOTE: A Fire Ember Mesh Guard may be required motor housing, you may use the optional accessory: when installing the Endline Isodrive 1350 Motor rear clamping assembly (attachment screws not System in a BAL (Bushfire Assessment Level area).
-
Page 10: Full Housing Assembly - Cross Section
5. Installation Full Body Assembly Cross Section Figure 1A Page 10... -
Page 11: Removable Motor Assembly
5. Installation Removal of Motor Assembly Removable Motor Assembly Insert electrical plug fully into mounted power outlet inside housing Figure 1B Removal of Motor Assembly: Front or Rear INSTALLATION NOTE: Align shutter FRONT REAR assembly and bellmouth, position the flange TO REMOVE: Slide removable assembly end so it locates behind the rail stop and is along side rails lifting the motor... -
Page 12: Wall Aperture Cut Out
5. Installation Wall Cut Out 40 mm Building wall shown (minimum) Wall Aperture Cut Out Figure 3 Motor Housing to Wall Fitment Completely seal front flange to wall joint using high quality bonding Wall urethane all four sides NOTE: Attachment screws and wall anchors not provided. -
Page 13: Front View Of Motor Housing (View From Behind Front Grille)
5. Installation Front view of motor housing (Looking behind the front grille) Housing attachment hole Housing attachment hole Diagonal dimensions must be within 2mm of each other 296mm 472mm 472mm Housing attachment hole Housing attachment hole 368mm Figure 5 Installation using optional rear clamp assembly Clamp to body fitment 4 places Fit screw from... -
Page 14: Attaching Optional Fire Ember Mesh Guard (Exploded View)
5. Installation (optional) Attaching optional fire ember Mesh Guard Can be fitted to any installation with access to the front. Fire Fire guard Normal guard frame grille frame Motor housing Guard is attached by screwing through Mesh both sides of guard into existing grille. 20mm deep 45mm... -
Page 15: Flexible Ducting Installation
Incorrect installation may reduce airflow or increase noise levels. Call outs relating to incorrect installation will result in a service fee directed to the customer. Schweigen will take no responsibility for problems caused by faulty installation. A list of preferred Schweigen installers can be obtained from the Schweigen website www.schweigen.com.au. -
Page 16: Securing Flexible Duct
6. Flexible Ducting Installation Securing Flexible Duct (Example) Flexible duct must be installed with supports at maximum intervals of 1.0 metres. Flexible ductwork can be supported by using good quality aluminium foil tape. Provided that it does not restrict the internal diameter of the ducting. -
Page 17: Parts List
7. Parts List Parts List for Isodrive Motor 1350 EL Base Build Assy 200mm Boss P3024 (Optional) Build Assy P3012 P3036 P3013 P3011 (Optional) EL RMB build assy (Optional) EL Inlet Build Assy Part Number Description Quantity P3036 Eliso1350 - Vinidex: 150mm x 50mm Pipe P3024 Eliso1350 - Fire Guard Optional... -
Page 18: Cleaning
IPX4 information supplied is to be used for general reference purposes only and is on the understanding that Schweigen Pty Ltd will not be liable for any loss, liability or damage of whatever kind arising as a result Warranty of any reliance upon such information. All pictures used in the guide are for illustrative purposes only. - Page 19 Notes Page 19...
- Page 20 Australia 8/3-4 Anzed Court, Mulgrave 3170 Victoria. Phone 1300 881 693 Email sales@schweigen.com.au Web www.schweigen.com.au New Zealand 5 Tolich Place, Henderson, Auckland 0610. Phone 0800 200 510 Email info.parex@emerson.com Web www.parex.co.nz Distributed by Axis Group International Pty Ltd. ACN 124 141 322...
