Summary of Contents for Savex SA-TX1
- Page 1 PST SAS 1, rue Brindejonc des Moulinais – ZAC de la Plaine – 31500 TOULOUSE, FRANCE Tel. : + 33 (0)5 67 77 94 46 – Fax : +33 (0)5 67 77 94 49 Email : savex@pst-france.fr Web : http://www.savex-securite.fr...
-
Page 2: Table Of Contents
Principle of operation (example of 2 detection zones) ............3 Disclaimer ........................4 Precautions ........................4 IV Precaution in the use of the SA-TX1 battery ..............5 Charging warnings ......................5 VI Technical characteristics of the SA-TX1 ................. 6 SA-TX1 portable device display led indicators ............. 7 SA-TX1 portable device detected faults ............... -
Page 3: I Overview Of The Savex Device
USER MANUAL Version 1.3 SA-TX1 Oct 2015 Overview of the SaveX device Principle of operation (example of 2 detection zones) The SaveXSA-IHM devices’s display installed in the driver cab indicates the number of pedestrians detected in the pre-alert or alert zones. -
Page 4: Disclaimer
NEVER modify the portable device whatever the reason. The portable device’s warranty does not cover problems due to an unauthorised change. WARNING ! The SA-TX1 portable device’s box is sealed and meets IP67 (immersion to a depth of 1 m for 30 minutes). However, the portable device’s waterproofing can no longer be warranted after a fall on account of, among others, resulting box cracks or seal damages. -
Page 5: Precaution In The Use Of The Sa-Tx1 Battery
Discard used batteries following the instructions. SA-TX1 portable device batteries can only be changed by a PST after-sales service technician or an approved dealer. Use and charge only the PST specified battery pack with portable devices or the PST chargers. -
Page 6: Technical Characteristics Of The Sa-Tx1
SA-TX1 Oct 2015 VI Technical characteristics of the SA-TX1 Pedestrian collision avoidance portable device : SA-TX1 (Equipment for each pedestrian) Function : permanently transmits a radio signal to the receiver which allows calculating the distance with the machine. Location : carried by each pedestrian Main specifications : Autonomy >... -
Page 7: Sa-Tx1 Portable Device Display Led Indicators
USER MANUAL Version 1.3 SA-TX1 Oct 2015 SA-TX1 portable device display led indicators Led indicators Meaning display Goes on as soon as the portable device is taken out of its charge base (continuous display of the (Power On) and DEFAULT... -
Page 8: Sa-Tx1 Portable Device Detected Faults
USER MANUAL Version 1.3 SA-TX1 Oct 2015 SA-TX1 portable device detected faults Led indicators Meaning Corrective action display The led indicators are off - Check your battery level by placing your portable device in The portable device is in the battery...
