Programmable Digital Thermostats
With Modulating FAN control
Index
Mode of Operation
Fan Speed
Temperature Set
Set Time, Date, Schedules
On / Off
Pro-V Series
OPERATION MANUAL
Phoenix Manufacturing Inc.
3655 E. Roeser Rd. - Phoenix, AZ 85040
602-437-1034 -
info@evapcool.com
01-999-2578
Page
Advertisement
Table of Contents
Summary of Contents for Phoenix Pro-V Series
-
Page 1: Table Of Contents
......................4 PERATION ………………………………………………………………………. 7 ETTING LOCK ………………………………………………………. 7 ETTING ROGRAM UNCTION Mode of Operation Fan Speed Temperature Set Set Time, Date, Schedules On / Off Phoenix Manufacturing Inc. 3655 E. Roeser Rd. – Phoenix, AZ 85040 602-437-1034 - info@evapcool.com 01-999-2578... -
Page 2: Front View
Front view Back view Item Description Display temperature and working status. MODE button Access to user and engineer menu and for setting confirmation or change ℃/℉ unit if press for over 3 sec. FAN button Toggle to change Fan mode: Auto or cont. Low/ Hi UP &... -
Page 3: Installation
Installation Note: This unit requires at least 6 conductor thermostat wire. 18-6 is recommended. Mounting on electric box 1. Separate back plate from the controller by loosing the cover screw; 2. Align the mounting holes on the screw holes of the electric box(applicable to 65x65 or US standard box); 3. -
Page 4: Operation
Operation User Mode Operation The first tier of operation includes the following settings as Figure 2. To operate: Power switch “ON” or “OFF” to start/ stop the System; After switching “ON”, press any button to start the User Mode operation. Press “MODE”... - Page 5 Fig. 2 User Mode operation sequence...
- Page 6 1. Detailed State Diagram for Clock Setting...
-
Page 7: Setting Clock
2. Detailed State Diagram for Schedule Setting Press “Mode” button to select (day shows steadily) / deselect (day flash). - Press Up/Down button to other day for multiple choice. - Page 8 Example of Setting Table for Schedules Table of Set-point temperature for each Schedule will be like this (Ex.: if wants 6:00 79.0℉, 8:00 85.0℉, 18:00 79.0℉, and 22:00 79.0℉ every day): Sch. 1 6:00 6:00 6:00 6:00 6:00 6:00 6:00 Cool:79.0℉...
- Page 9 Control Action 1. Cooler and Fan Controls: When cooler is on, a “Running ( Gear) ( ” icon will be shown on the LCD. Fan Control for Cooling Mode Fan Output Proportional Band Cooler Output 100% Fan High Fan Med Fan Low Current SP –...
- Page 10 4. Fan Controls: (1) Vent Mode: Press FAN push button to set AUTO/ LOW/ MED/ HIGH fan speed. The respective modulating output can be set for each manual speed. (2) Cool Mode: Press FAN push button to set AUTO/ LOW/ MED/ HIGH fan speed. The respective modulating output can be set for each manual speed.
