Summary of Contents for finskasauna S1212CH
- Page 1 S1212CH, S1515CH, S1515RCH, S1812CH, S2015CH, S2015RCH, S2020CH, S2020RCH Assembly Instructions for Sauna 16042015...
-
Page 2: Content Of Delivery
16–36 pcs. screw 4,5 x 45 mm, for wall elements 4 pcs screw 4,5 x 45 mm, for benches 2 pcs screw 4,5 x 45 mm, for heater guard board (S1212CH, S1812CH) 2 pc plastic plug for heater guard board (S1212CH, S1812CH) 4 pc... - Page 3 S1212CH h=1970 1200 S1515CH h=1970 1535...
- Page 4 S1515RCH h=1970 1535 S1812CH h=1970 1200...
- Page 5 S2015CH h=1970 1535 S2015RCH h=1970 1535...
- Page 6 S2020CH h=1970 1975 S2020CH h=1970 1975...
- Page 7 Start installation with elements A2 and B1. There are 4 pilot holes for screws in the elements for fastening the elements together. Screw size is 4.5 x 45 mm. Fasten screws by using a battery-operated screwdriver or a screwdriver with PZ tip, as shown in picture 2. Continue installation in clockwise direction.
- Page 8 Lock the corner elements together also from foot. Use 5.0 x 80 mm screws for this purpose. Place the ceiling elements. Fasten the ceiling elements using 4.5 x 60 mm screws. Fasten the fascia boards. Install the loose cover panel boards. Fasten the boards with nails.
- Page 9 Measure and mark places for bench A mm L mm supports. 1212CH Fasten the bench 1812CH 1515CH supports with 1515RCH 5 x 80 mm screws 2015CH (8 pcs). 2015RCH 2020CH 2020RCH Bench support 44 x 70 x L Floor Install the lamp according to separate instructions.
- Page 10 INSTALLATION OF THE SAUNA LAMP Your sauna is equipped with a sauna lamp. Installation of the sauna lamp is preferable, but not obligatory since the glass door of the sauna allows light into the cabin. Note! Only a professional electrician is allowed to do the installation. Use only light sources and rated wattages as marked in the luminaire.
