Summary of Contents for ShinewayTech OTS-20A
- Page 1 OTS-20 Series Optical Talk Sets User’s Manual Shineway Technologies, Inc. All rights reserved.
- Page 2 OTS-20 Optical Talk Sets...
-
Page 3: Safety Instructions
User’s Manual for OTS-20 Safety Instructions Safety Terms Used in This Manual “WARNING” identifies any procedure or practice that if not followed could result in serious injury. “CAUTION” identifies any procedure or practice that if not followed could result in damage to the instrument or serious injury. “NOTE”... - Page 4 User’s Manual for OTS-20 batteries. Avoid touching the electrolyte in the batteries, which is corrosive and may cause injuries to eyes, skin or damage to clothes. External Power: All hand-held instruments from our company support external power. Power requirements: DC 13.8V/1.2A. Laser Radiation: To avoid serious eye injury, never look directly into the optic outputs of fiber optic network equipment, test equipment, patch cords, or test jumpers.
-
Page 5: Table Of Contents
User’s Manual for OTS-20 Table of Contents SAFETY INSTRUCTIONS ........................ I 1. GENERAL INFORMATION ......................1 1.1 S ......................1 COPE OF THIS ANUAL 1.2 U ....................1 NPACKING AND NSPECTION 1.3 I .......................... 2 NTRODUCTION 2. TECHNICAL SPECIFICATIONS ....................3 3. -
Page 6: General Information
Shineway Technologies, Inc. If necessary, you may contact the Representative of Shineway Technologies for Mainland directly or contact Shineway Technologies, Inc via this email: support@shinewaytech.com. To return the instrument in the case of repair, calibration or other maintenance,... -
Page 7: Introduction
Be sure to ship to your representative or the agent of the Company in a reliable way. 1.3 Introduction ShinewayTech OTS-20 Series is an advanced tool for optical fiber networks field operations, which features by quality voice transmission, laser inspection and handling technology, digital voice coding and decoding, full duplex and hands-free operation, field portable, intelligentized, multi-functional and dual-way powering system. -
Page 8: Technical Specifications
User’s Manual for OTS-20 2. Technical Specifications Model OTS-20A OTS-20B Wavelength (± 20nm) 1310 1550 ≤ 5 nm Spectral Width (nm) Optical Talk Sets Module ≥ 40 dB Dynamic Range (SM) Maxi. Transmission Range 110 Km 160 Km 130 Km... -
Page 9: Basic Operation
3. Basic Operation 3.1 Foreword This part introduces the basic operations of the ShinewayTech series hand-held optical testing instruments. Specific operations of each type are elaborated in “Specific Functions and Operations”, chapter 4 of this manual. Please read this manual carefully for optimal operation. Should you encounter any problems during operation, you are welcome to contact the technical staff of our company or agents. -
Page 10: Maintenance Of Batteries
User’s Manual for OTS-20 3.3 Maintenance of Batteries Battery for ShinewayTech series optical talk sets is rechargeable NiMH battery. All the NiMH batteries have been correctly installed and gone thorough precise debugging. Please do not open the instrument to replace batteries at discretion. -
Page 11: Specific Functions And Operations
User’s Manual for OTS-20 4. Specific Functions and Operations 4.1 Functions Besides the basic function of voice communication, OTS-20 series optical talk sets also provide pager function, stabilized laser source and identification of optical fiber by transmitting 2 KHz modulation frequency. Detailed introductions are as follows: Voice Communication: For easy use of operators and fast establishment of voice communication, when a pair of optical talk sets are connected with the chosen optical fiber，the sets will be prompt for use after a short reminding... -
Page 12: Keypad Functions
User’s Manual for OTS-20 4.2 Keypad Functions On/Off Power on or off the instrument, there is short reminding tone after power on. [2KHz] Press it once, the instrument will be switched to laser source state, and the output is 2KHz modulation frequency with indicator light green;... -
Page 13: Typical Application
User’s Manual for OTS-20 4.4 Typical Application 4.4.1 Full Duplex Communication Figure 4.2 Sketch Map of Full Duplex Communication Local End: Choose the optical fiber for communication and clean its ends, interfaces and tie-ins Connect optical talk sets properly with the chosen optical fiber ... -
Page 14: Multiparty Communication
User’s Manual for OTS-20 4.4.2 Multiparty Communication For each optical fiber, a pair of optical talk sets need to be connected. Conference call can be realized by connecting two optical talk sets of the intermediate station, as shown in the figure below. Anyone at a connecting end can talk and hear others’... -
Page 15: Set Reference Power Value
User’s Manual for OTS-20 Connect optical jumper to optical talk sets Connect optical jumper to optical fiber to be tested. Power on the talk sets, and press key 2KHz Use our company’s optical fiber recognizer to search for the tested optical fiber at distance end. -
Page 16: Optical Fiber Attenuation Measurement
User’s Manual for OTS-20 4.4.5 Optical Fiber Attenuation Measurement Tested Optical fiber emitting optical jumper Receiving tie-in Tie-in Tie-in Do not alter this tie-in RS232 Ring/Talk Low Battery 1310 nm Charge/Charge Full Continue Wave/2KHz -20.6 ShineW a yTech ShineW a yTech On/Off 2KHz Recall... -
Page 17: Together With Optical Clip-On Coupler To Perform Online Communication
User’s Manual for OTS-20 4.4.6 Together with Optical Clip-on Coupler to Perform Online Communication Ring/Talk Ring/Talk Low Battery Low Battery Charge/Charge Full Charge/Charge Full Continue Wave/2KHz Continue Wave/2KHz Shi neW a yTech ® Shi neW a yTech ® On/Off 2KHz On/Off 2KHz Talk... -
Page 18: Maintenance And Calibration
5.3 Calibration Requirements Calibration of the instrument is recommended every two years. Please contact ShinewayTech , Inc. or our agent for proper calibration. -
Page 19: Warranty Information
6. Warranty Information 6.1 Terms of Warranty All ShinewayTech products are warranted against defective material and workmanship for a period of one (1) year from the date of shipment to the original customer. Any product found to be defective within the warranty period would be repaired or replaced by Shineway Technologies Inc. -
Page 20: Contacting Customer Service
User’s Manual for OTS-20 6.5 Contacting Customer Service Please check our web site (www.shinewaytech.com) for updates to this manual and additional application information. If you need technical or sales support, please contact local Shineway Technologies Customer Service. Shineway Technologies (China), Inc.: Address: Fl.7, Zhongtai Plaza, No.3 Shuangqing Rd, Haidian District, Beijing, China... - Page 21 DOC. P/N: MAN-OTS-020.V100.10/03...
