- Page 1 SXC-1180 CDMA 1x USB MODEM Wherever you are. Wherever you need 참고사항 노트북에 제품(SXC-1180)을 직접 연결하여 사용하는 경우, LCD모니터에서 발생하 는 전자파에 의해 수신 감도가 저하되는 경우가 있습니다. 이 경우 제품과 함께 동봉된 USB연장 케이블을 연결해 사용하시기를 권장합니다.
- Page 2 Introduction Congratulations on your purchase of the advanced and compact SXC- 1180 USB Modem, designed to operate with the latest digital mobile communication technology. This user’s guide contains important information on the use and operation of this phone. Please read all the information carefully for optimal performance and ro prevent any damage to or misuse of the USB Modem.
-
Page 3: Usb Connector
1. Part of the USB Modem USB Cover Indicator LED R-UIM Socket USB CONNECTOR Neck Strap... -
Page 4: Product Specification
2. Product Specification Function SXC-1180 Remarks Main Operation Chip MSM6025,RFR6122, RFT6122 TIA/EIA/IS-2000, IS-98D, CDMA Standard Backwards compatibility with IS-95 A/B Cellular 800 Single Band Support Frequency Band Band Class 0 of Operation TX: 824 ~ 849 MHz RX: 869 ~ 894 MHz... - Page 5 3-1 Program install guide 1. The install program insert at CD-ROM drive 2. If waited, Auto run program start for install 3. If do not started install program, Use window search to install “Setup.exe” of CD-ROM 4. The picture is install start program screen . Click “Next” 5.
- Page 6 6. Start the Dialer Client install program 7. The picture is install program finished...
- Page 7 8-1. SIT_1x_usbmodem Device install(1). - After installation process completing. Connect the PC and the modem. And then the new hardware wizard is executed. Click “Install the software automatically ” and “Next ”, And then modem driver is installed automatically. 8-2. SIT_1x_usbmodem Device install(2). .
- Page 8 8-3. SIT_1x_usbmodem Device install (3). - The picture is SIT_1x_usbmodem Device install finished.
- Page 9 9-1. SIT_1x_usbmodem install (1). - After SIT_1x_usbmodem Device drive install finished. The new hardware wizard is executed.. Click “Install the software automatically ” and “Next ”, And then modem driver is installed automatically. 9-2. SIT _1x_usbmodem install (2). - “Continue Anyway” Click...
- Page 10 9-3. SIT _1x_usbmodem install(3). - The picture is SIT_1x_usbmodem drive install finished.
- Page 11 10-1. SIT_1x_usbmodem Port install(1). - After SIT_1x_usbmodem drive install finished. The new hardware wizard is executed.. Click “Install the software automatically ” and “Next ”, And then modem driver is installed automatically. 10-2. SIT_1x_usbmodem Port install(2). - “Continue Anyway” Click.
- Page 12 10-3. SIT_1x_usbmodem Port install (3). - The picture is SIT_1x_usbmodem Port install finished.
- Page 13 3-3. PC Client Manual Run application and then below window is active. Below window has 6 function menu.
- Page 14 1) Connect Connect wireless internet via Dial connection network. Click Connect menu to be showed below pop-up window User name : fill in user ID, password and Dial number provided by service provider, and then click connect button to connect wireless network.(If you want to save this information, click square box next to “...
- Page 15 2) Address Book - Manage phone book. 2.1) If you want to call or send SMS to member in the list, select the member and click the right mouse button. You see pop-up menu and just click Send or Call. 2.2) You can use Find function to find registered name or phone number you want in the list.
- Page 16 2.4) If you want to synchronize phone book between PC and Modem, click “Phone Book” button to be showed below phone book window. (Refer to below picture) - Use left, right arrow button to select phone number and use copy/move option to synchronize the selected number.
- Page 17 3) Setup - Setup various information in application. 3.1) Window Set up the window display function. A) Always on top : Display window on top always. B) Tray icon blink : When application receives messages, tray icon blinks on working bar. C) Auto Pop-up : when application receives messages, Message Box window Shows automatically.
- Page 18 3.2) Network - Register ID, password and Dial number to connect the wireless network. 3.3) Setup Info - Show the application version.
- Page 19 3.4) Activation - Choose Activation tab of Setup menu. - Press "Send" button after inputting the "1st HCC Number". - "OK" message is displayed on the screen if succeed. And then the "2nd Step" will be activated. 3.5) Recharge - Choose Recharge tab of Setup menu. - Press "Send"...
- Page 20 4) SMS Write/Send Send SMS. 4.1) Fill in the number you want to send in blank box, “To : __________” and click send button. 4.2) Delivery Ack : Ack Function enable. 4.3) To move to SMS manager screen, click the envelope button...
- Page 21 5) SMS Inbox - Manage received and sent SMS history. 5.1) Select the number you want to send to and click right mouse button. You see the SMS sending screen. 5.2) To copy SMS to Modem, Select the number you want to copy and Click “...
- Page 22 6.1) Select the number you want to forward to and click right mouse button. You see the SMS sending screen. 6.2) To copy SMS to Modem, Select the number you want to copy and Click “ Copy to Modem” , To move Click “ Move to Modem.”...
- Page 23 4. Mechanical Specifications Figure 3.1 Gift box Design Figure 3.2 USB Extension Cable 32mm 11.5mm 94.4mm Figure 3.4 Mechanical dimension Figure 3.3 Install CD...
-
Page 24: Rf Exposure Information
RF EXPOSURE INFORMATION THIS CDMA USB DONGLE MEETS THE GOVERNMENT ’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your CDMA USB DONGLE is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S.Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. - Page 25 Figure 3.5 Gift box Design...
