- Page 2 This Supplement describes the procedure for using the COMFORT-MATIC electronically controlled manual gearbox on the Fiat Ducato. For the correct use of the gearbox, it is essential to read this Supplement in full to find out at the outset which operations are correct and permissible.
-
Page 3: Table Of Contents
CONTENTS COMFORT-MATIC GEARBOX ..................................READY TO START ....................................... OPERATING PROCEDURE ....................................WARNING LIGHTS AND MESSAGES ................................10 IF THE VEHICLE NEEDS TO BE TOWED ..............................13 IF A FUSE BLOWS ......................................... 13 SERVICE SCHEDULE......................................14 CHECKING FLUID LEVELS ....................................14 AIR CLEANER ........................................ -
Page 4: Comfort-Matic Gearbox
IMPORTANT For correct use of the sys- tronically controlled manual gearbox tem, it is advisable to use your right foot known as the “COMFORT-MATIC” that only to operate the pedal. is able to operate in two modes: MAN- UAL and AUTO. -
Page 5: Operating Procedure
OPERATING MODE The gearbox can operate in two operat- ing modes: ❒ the first is manual (MANUAL), where the driver decides directly when to shift gear; ❒ the second fully automatic (AUTO), where the system decides when to shift fig. 3 F0N0352m fig. - Page 6 The system is returned to manual mode MANUAL OPERATION by returning the lever to A/M position. (MANUAL) With the vehicle at a standstill and the key In this operating mode, the driver is re- out, the lever may be moved with/without sponsible for choosing the best gear ra- the brake pedal pressed.
- Page 7 In AUTO mode, the system will shift Automatic operation INFORMATION ON DISPLAY gears on the basis of vehicle speed, engine (AUTO with UP function engaged) When the ignition key is turned to MAR, rpm and the pressure applied to the ac- after one second, the reconfigurable mul- The UP can only be activated with auto- celerator pedal.
- Page 8 3 , Auto mode not available). ❒ the reconfigurable multifunction display multifunction display. If the engine does not start, contact a Fiat shows the message (N) and an acoustic dealership. IMPORTANT If the display does not show signal indicates any inconsistency be- the gear engaged after 10 seconds with the IMPORTANT When the driver’s door is...
- Page 9 DRIVING OFF IN THE VEHICLE To engage 2 gear BUZZER WARNINGS ❒ press the brake pedal; Driving off in the vehicle, take-off, is per- For safety reasons, a buzzer warning mitted in 1 gear, 2 gear (recommend- sounds when the vehicle is parked with ❒...
- Page 10 ❒ although very inadvisable, if the vehi- PARKING THE VEHICLE GENERAL WARNINGS cle is unexpectedly allowed to roll ❒ With the vehicle at a standstill and a To park safely, it is essential to engage 1 downhill with the gearbox in neutral gear or reverse (R) gear with your foot gear engaged, keep the brake pedal (N) the system will automatically en-...
-
Page 11: Warning Lights And Messages
(together with a display. display. message on the reconfigurable multifunc- tion display and a buzzer) to indicate that the gearbox is faulty. If a fault is present, contact a Fiat Dealership as soon as possible to check the sys- tem. - Page 12 Contact a Fiat Dealership if In this situation, keep the key on AVV for the message remains on the at least 7 seconds with the brake pressed:...
- Page 13 1 (1), 2 (2), 3 (3) or reverse (R). The message appears on the reconfig- Contact a Fiat Dealership if urable multifunction display accompanied, the message remains on the in some cases, by a warning buzzer for reconfigurable multifunction safety reasons if you attempt to change display.
-
Page 14: If The Vehicle Needs To Be Towed
TOWING THE VEHICLE IF A FUSE BLOWS Ensure the gearbox is in neutral (N) (by The COMFORT-MATIC system components are protected by specific fuses. checking that the vehicle moves when Contact a Fiat Dealership if a fuse needs replacing. pushed) and tow in the same way as a nor- mal vehicle with a manual gearbox (see in- structions in Owner Handbook). -
Page 15: Service Schedule
CHECKING FLUID LEVELS COMFORT-MATIC GEARBOX HYDRAULIC OPERATING SYSTEM FLUID To check the gear oil and check/replace the hydraulic clutch operating system fluid, contact only a Fiat dealership. Used gear oil contains substances that are hazardous for the environment. It is ad-... -
Page 16: Engine Codes - Bodywork Versions
ENGINE CODES - BODYWORK VERSIONS 3000 kg 3300 kg 3500 kg 3500 kg MAXI Version Engine code 4005/4250 kg 2800 kg 130 Multijet FIAE348ID 3650 kg TRANSMISSION 150 Multijet FIAE348IE Manual gearbox Automatic transmission 180 Multijet Power FICE348IE ENGINE 130 Multijet 150 Multijet The following body version code and key is an example that may be applied to all 180 Multijet Power... -
Page 17: Performance
PERFORMANCE For top speeds, see “Performance” in the “Technical Data” section of the Owner Handbook. TRASMISSION Six speeds plus reverse Gearbox with electronically-controlled hydraulic system Single dry plate with Clutch hydraulic engagement Drive Front... -
Page 18: Capacities
CAPACITIES Specified fuels litres Recommended products COMFORT-MATIC 0.59 TUTELA CAR CS SPEED - gearbox hydraulic operating system Specific fluid with“ATF DEXRON III” additive Clutch hydraulic operating system TUTELA TOP4 0.050 – Synthetic fluid FMVSS n° 116 DOT 4, ISO 4925 SAE JI704, CUNA NC... -
Page 19: Fuel Consumption Co
FUEL CONSUMPTION AND CO EMISSIONS Fuel consumption according to Directive 1999/100/EC (litres x 100 km) emissions according to 1999/100/CE Directive (g/km). 130 Multijet/150 Multijet Combi versions Gross vehicle weight Fuel consumption emissions Urban Extraurban Combined Combined 130 Multijet/150 Multijet Panorama versions Gross vehicle weight Fuel consumption emissions... - Page 20 Goods transport 130 Multijet/150 Multijet versions (*) Versions Gross vehicle weight Fuel consumption emissions Urban Extraurban Combined Combined Van CH1/Box truck CH1 MH1/ Cab chassis and double cab (*)/ 3000, 3300, 3500 Flatbed cab (*)/Chassis cowl (*) Van CH1 MH1/box truck MH1 3000, 3300, 3500, MLH1 LH1/ double cab MH1 3500 Maxi, 4005,...
- Page 21 Double cab MH1 LH1 (*) Fuel consumption figures apply to pre-conversion vehicles Fiat Group Automobiles S.p.A. - Parts & Services - Technical Services - Service Engineering Largo Senatore G. Agnelli, 3 - 10040 Volvera - Torino (Italia) Print n. 603.95.838 - 10/2011 - 1 edition...
- Page 22 ENGLISH The data contained in this publication is intended merely as a guide. FIAT reserves the right to modify the models and versions described in this booklet at any time for technical and commercial reasons. If you have any further questions please consult your FIAT dealer.
