Ride
FlexLoc
®
Owner's Handbook
Warranty Policy
Installation and Use Instructions
Warranty Policy
This Limited Warranty is effective for 24 months from the date of delivery
to the original purchaser. If any defect in material or workmanship is found,
Ride Designs
limited warranty does not cover daily wear and tear or damage due to
accidents, neglect, misuse, operation beyond capacity, parts damaged by
improper installation, substitution of parts not approved by Ride Designs, not
following these care and maintenance instructions, or any alteration or repair
by others that, in Ride Designs' judgment, materially or adversely affects your
FlexLoc
hardware.
™
Claims and repairs should be processed through your nearest authorized
Ride Designs rehab technology supplier. A copy of the Bill of Sale issued
to the purchaser of the product may be required prior to processing a
warranty claim.
Maximum client weight capacity is 250 pounds for Ride Custom Backs
attached to wheelchair using the FlexLoc hardware.
Maximum client weight capacity is 300 pounds for Ride Custom Backs
attached to wheelchair using two (2) FlexLoc hardware kits.
M
Ride Designs
a branch of Aspen Seating, LLC
8100 SouthPark Way, C400
Littleton, Colorado 80120 USA
™
will repair or replace the component, at our discretion. This
®
®
®
toll-free: 866.781.1633
phone: 303.781.1633
www.ridedesigns.com
Advertisement
Table of Contents
Related Manuals for Ride FlexLoc FL-MS
Summary of Contents for Ride FlexLoc FL-MS
- Page 1 ™ Claims and repairs should be processed through your nearest authorized Ride Designs rehab technology supplier. A copy of the Bill of Sale issued to the purchaser of the product may be required prior to processing a warranty claim.
- Page 2 NOTE: Ride Designs is not liable for damage to property or personal injury arising out of unsafe use of this product. Ride Designs is also not liable for any property damage or personal injury arising out of the failure of any person and/or user to...
- Page 3 For more complete instruction, refer to web-based instructions at www.ridedesigns.com. WARNING: Improper attachment of the Ride Custom Back to your wheelchair may result in serious injury. Your Ride Custom Back must be attached with Ride Designs approved interface hardware and mounts. I. Tools and Hardware The following tools are included to install and adjust the FlexLoc hardware.
- Page 4 Attach FlexLoc to wheelchair back canes 1. Use the 4mm allen wrench to loosen width adjustment set screws (A) and pivot screws (B) so that the FlexLoc hardware can be adjusted in width to match wheelchair width. CAUTION: Only loosen pivot screws until teeth are disengaged.
- Page 5 Figure 4 Wedge Block Flange 5. Use the 4mm allen wrench to tighten all fasteners. a. Clamp screws (2) b. Pivot screws (2) c. Back angle screws (4) d. Back height set screws (3) e. Back rotation bolts, 10mm (4) f.
- Page 6 III. Adjusting FlexLoc for back fit 1. Adjust back height. a. Use the 4mm allen wrench to loosen clamp screws and slide FlexLoc up/down on back canes, and/or b. Use the 4mm allen wrench to loosen back height set screws and slide back up/down on track.
- Page 7 3. Adjust seat depth and vertical rotation. a. Loosening of pivot screws and width adjustment set screws allows for seat depth and vertical rotation adjustment as shown. NOTE: Pivot screws must be loosened sufficiently to separate teeth to allow movement. CAUTION: Only loosen pivot screws until teeth are disengaged.
- Page 8 For people at higher risk for skin breakdown, and/or more challenging postural control needs, the Ride Custom Cushion 2 is the ultimate in postural support and skin care. It is specifically contoured to support a person’s unique size, shape, posture and functional requirements.
